STERILIZATION
305
PRESTIGE AUTOCLAVES - class N
Prestige is one of the world’s largest selling and most cost
effective automatic autoclave available, with an enviable
reputation for reliability, durability, safety and quality.
- Lifetime warranty on heating element
- Method recommended by healthcare professional worldwide
including the World Health Organisation (WHO).
- Each autoclave is computer tested and issued with a unique
Performance Test Certificate.
- At only 4.5 kg net weight, offers full device portability.
- Supplied with basket, tray, lifting fork.
Recommended for infection control not only in hospital and
general medical and dental surgeries, but also in veterinary,
chiropody, professional beauty, tattooists, acupuncture,
laboratories and schools. Multilingual user manual. Comply
with: IEC 601, DIN 58946, EMC, UL 544, BS3970 part 4, ESCHLE
35709
35712
35720
35722
Prestige autoclave 9 litres
Prestige autoclave 12 litres
Silicone sealing gasket
Depressurization valve
0086
340 mm
Only
335 mm
35709
• 35746 H100 GIMA AUTOCLAVE - 9 litres - 230 V
• 35656 H100 GIMA AUTOCLAVE - 9 litres - 110 V
This autoclave is safe and easy to use. It is used to sterilize surgical
instruments and hand-pieces which can be sterilized up to 125°C.
All this with a sterilization cycle of 15 minutes. It is composed
of an external frame of painted steel and a stainless-steel 18/10
body without any welding, with three safety valves. Made in Italy.
Safety systems
- Safety lock to prevent opening of the door during the
sterilization cycle; the door can only be opened when pressure
inside the chamber is levelled to the ambient one
- Safety valve for vapour exhaust in case of damage with inside
overpressure > 2.5 bar
- Safety thermostat which occurs if the inner temperature of
the chamber rises over 135°C
- Thermodynamic vacuum
• 35747 SEALING GASKET for H100
TECHNICAL SPECIFICATIONS
35709
35712
Capacity :
9 l
12 l
Chamber internal dimensions (D/H)
210/236
210/328
Maximum instrument length (diagonal): 228 mm
290 mm
Maximum loading weight:
3 kg
4 kg
Width/height:
340/335
340/420
Same specifications for 2 models:
Sterilizing time: 11 minutes
Cycle time (nominal) minutes: 22 minutes
Operating pressure: 1.40 bar
Sterilizing temperature: 126 °C
Operating voltage: 230 V - 50-60 Hz - Power 1.500 Watt
Made in UK - Warranty: 1 year
TECHNICAL SPECIFICATIONS
External size: 258x300xh 370 mm
Size of the sterilizing chamber:
Ø 220 mm - h 215 mm
Removable basket: Ø 210 mm - h 215 mm
Sterilizing liquid: distilled water
Absorbed power: 1500 Watts
Operating voltage:
110 V or 230 V - 50/60 Hz
Fuses: type 6.3 x 32 mm - 8A
Operating temperature: 125 °C
Sterilizing time: 15 minutes
Operational pressure:
1.6/1.7 bars (170/180 KPa)
Net weight: 12.2 kg Warranty: 1 year
STANDARD ACCESSORIES
Stainless steel basket
Rauclair tube
Distilled water bottle 1 l
Electric cable
User manual in English, French, German, Italian, Spanish
0068
ISO 9001
GIMA
code
PRESTIGE MEDICAL AUTOCLAVES
35712
PRESTIGE CLINICAL AUTOCLAVES:
EXCELLENCE THROUGH DESIGN
GIMA VERTICAL AUTOCLAVE H 100 - 9 LITRES -
CLASS N
Safety bolt and valve
indicating pressure
Starting cycle knob
35746
GERMY GIMA PLUS: ULTRA VIOLET LAMPS
These instruments incorporate a germicidal ultra-violet lamp
which rapidly destroys every micro-organism hit by its rays.
Recommended to keep the instruments stored inside sterile.
Instruments previously sterilized can be preserved for a long
time and they are always ready for use (UV treatments do not
generate heat).
An inside supporting grate keeps instruments raised from
reflecting surface which enables both surfaces to be uniformly
irradiated, improving the UV germicidal action.
Operator safety is guaranteed by a micro switch which
extinguishes the lamp if door is opened.
Solid construction, painted steel outside and reflecting
stainless steel inside.
Installation on table or wall.
Operating voltage: 230 V - 50/60 Hz - 1 A
Made in Italy
AVAILABLE IN 3 SIZES
• 35750 GERMY GIMA PLUS 8 W - 38x20xh 17 cm
• 35751 GERMY GIMA PLUS 15 W - 50x24xh 20 cm
• 35752 GERMY GIMA PLUS 30 W - 96x24xh 20 cm
• 35754 SPARE NEON LAMP - 8 Watt
• 35755 SPARE NEON LAMP - 15 Watt
• 35756 SPARE NEON LAMP - 30 Watt
35751
GERMY GIMA PLUS: GERMICIDAL ULTRAVIOLET LAMPS
