STERILIZATION
308
Bacteriological filter
Door gasket
Door opening block
with electromagnet
Electronic printer
Digital control
Stainless steel chamber, uniformly
heated by a band heating element
Twin tanks for pure and used water: by using always pure water,
the internal components are protected, with benefits in mainte-
nance and service costs
Andromeda Vacuum
is supplied with
printer built into the
drive board. The
printer document
certifies the steriliza-
tion by indicating all
the data related to
the cycle.
0434
CHAMBER TEST
MICROBIOLOGIC
CERTIFICATION
Completely computerized monitoring of all automatic
functions, and auto-diagnosis of each component. The total
automation of each phase of the cycle prevents any possible
human error, also from inexperienced personnel
Timed start, with positioning
in “Stand-by” at 80°C and automatic switch off
after one hour not in use.
Automatic filling up
of the water: a pump
allows the filling up, and
stops automatically
when the maximum level
is reached.
Cycles
Program 1
Unwrapped instruments
Program 2
Wrapped instruments
Program 3
Unwrapped instruments
Program 4
Wrapped instruments
Program 5
Flash
Temperature
134° C
134° C
121° C
121° C
134° C
Max load
2.8 kg
2.8 kg
2.8 kg
2.8 kg
2.8 kg
Pressure
2.2
2.2
1.2
1.2
2.2
Total time*
33
38
42
46
16
TECHNICAL SPECIFICATIONS
External size: 45 x 39 x 54 cm (35651, 35661), 45x39x66 cm (35662)
Chamber dimension: Ø 24.5x32 cm depth (35651, 35661),
Ø 24.5x43 cm depth (35662)
Weight: 50 kg
Operating Voltage: 230 V - 50/60 Hz
Power consumption: 2000 Watt
Made in Italy Class S
Cycles
Andromeda Vacuum is provided with 5 cycles of sterilization: 121° C and 134° C for
unwrapped and wrapped instruments, and a “Flash” cycle for the fast sterilizations.
Diagram of the cycle
* pre-heating - vacuum - cycle - drying in vacuum
User manual available in English, French, Spanish, Italian, German
• 35651 ANDROMEDA VACUUM XP - 15 litres - 230 V
• 35662 ANDROMEDA VACUUM XP - 21 litres - 230 V
Pre-and post-vacuum:
Andromeda Vacuum is provided with
powerful vacuum pump which, at the beginning of the cycle,
ejects the airpockets from the sterilization chamber, and at the
end of the sterilization phase ensures a very good drying.
Rapid preheating:
A very new method of preheating, through
a special band heating element, gives a high reduction of the
preheating times.
Guaranteed sterilization:
A sophisticated electronic device
gives a constant monitoring of pressure, temperature and
time. In case of anomalies there will be an electronic lock of
the autoclave and the display will indicate the anomaly.
“Night” cycle with anti-condensate device
Andromeda Vacuum can work also without the
operator presence as all functions are automatic.
At the end of each cycle a special device eliminates the
backwater of condensate, afterwards there is the automatic
sign off, but with electronic storage.
Safety of the operator:
Andromeda Vacuum has an
electromagnetic block device on the door. The door opens only
with atmospheric pressure into the chamber, and after having
pressed the push button.
• 35671 SEALING GASKET - for Andromeda and Europa
• 35672 BACTERIAL FILTER - for Andromeda and Europa
• 35673 VAPOR LINE STERILIZATION INTEGRATOR
- for Andromeda and Europa
• 35652 THERMAL PAPER 60 mm x 25 m
CLASS S
ANDROMEDAVACUUMXPAUTOCLAVEWITHPRINTER15-21LITRES
• 35690 WATER DISTILLER
The autoclaves must run with distilled or demineralised water to
avoid problems on electrovalves and on internal mechanism and
white traces of limestone on the sterilized tools and devices.
Distiller produces 100% distilled water in a cheap and safe way.
It produces 4 litres in about 7 hours.
It is equipped with an automatic control thermostat with block
system at the end of operation.
Supplied with 6 active coal filters, 1 detergent, 1 container for
produced distilled water. Operating Voltage: 220V - 50-60Hz.
• 35691 COAL FILTERS FOR DISTILLER - box of 12
• 35692 DETERGENT FOR DISTILLER
Size Ø 20 cm x h 36 cm
DISTILLER: SYSTEM OF WATER DISTILLATION
35690
93/42/EEC
73/23/EEC
93/336/EEC
Medical device
Low tension
Electromagnetic
Compatibility
