STERILIZATION
310
TECHNICAL SPECIFICATIONS
Flat sealing 12 mm
Sealing length 300 mm
Thermo controlled continuous heat sealing
Built-in cutting device
Fixed sealing temperature and sealing time
Manual actuation
Power 230 V / 50-60 Hz, single phase
Electrical input: 900 W
Protection degree IP 20
Sealer dimensions 452x248x146 mm
Roll-holder dimensions 458x412x242 mm
Easy
: by the pressure of only one finger, without using levers,
the bars close automatically. The electro-magnet guarantees a
steady sealing pressure for the whole set period. The sealing
bar opens automatically at the end of the cycle, requiring no
action by the operator.
Quick:
the electro-magnetic system allows a substantial saving
of the packing time. Quick foil feeding.
Safe:
the machine does not start the sealing cycle if there is an
object with a thickness over 3 mm between the bars.
The electronic temperature control through a NTC probe
provides a perfect temperature accuracy from seal to seal.
The electronic alarm function avoids any overheating.
Made in Italy.
• 35902 TEFLON - spare
• 35903 RESISTOR - spare
35900
• 35900 D-351 IMPULSE SEALING MACHINE
Compact impulsemedical sealers, conform to DIN 58953 P.7 rules,
specially designed to be used inmedical, dental, oculistic surgeries and
test laboratories.
Main features:
sealing and cutting length 35 cm - Safety check with
alarm. Main board with temperature control to avoid overheating
of the sealing wire - Sealing bars closed by electromagnet.
Complete with foil-roll dispenser and built-in cutting device.
Electromagnet closing
• 35930 D-301 SEALING MACHINE - machine only
• 35931 D-301 SEALING MACHINE - complete
Manual heat sealer for medical pouches and reels according to
DIN 58953-7:2008.
Available in 2 versions: compact without accessories (35930) or
with sealer roll holder, cutter and plane (35931)
User friendly and reliable, with superior technical features.
Extremely compact, ideal in dentistry, medical and veterinary
laboratories. Sealing bar 300 mm manually actuated by a lever.
Thermo controlled continuous heat sealing, to save
consumables. Compact vertical design to reduce space at the
minimum. Integrated, removable roll-holder, can stand alone
apart from the sealer.
Usable only with polypropylene film coupled to medical grade
paper and/or plastic envelopes suitable for steam sterilization.
• 35934 HEATING
• 35935 BLADES - kit of 5 - spare
D-351 SEALINGMACHINE: ELECTRO-MAGNETE OPERATION
D-301 SEALING MACHINE
FOR CONTINUOUS HEAT SEALING
35931
35930
TECHNICAL SPECIFICATIONS
Sealed materials: paper/polyethylene/polyester
Sealing length: 350 mm
Sealing width: 8 mm as per DIN 58953 P. 7 rules
Electronically controlled sealing time: 0.5 sec.
Cutting length: 350 mm
Foil-roll dispenser 350 mm
Power: 230V- 50/60 Hz single - phase
Max absorption: 700W, only during the sealing time
Dimensions: 44x17.5x31 cm
Weight: 18 kg
Built in accordance with CEI EN 60204- 1 rules
• 35849 "STEAM STAR" INDICATOR - autoclave
Indicator for sterilization by autoclave with
pressure 1 to 2 bar 120°C/135°C. No special stocking
requirements. Safety and reliability. Made in Japan
minimun order: 1,000 pcs.
Notice "Sterilisé" and three stars drawing change colour
from pink to brown
to show effectiveness of 121°C - 15 minutes or 134°C
- 3 minutes and 30" sterilization and
to black
to show safety margin of 121°C - 20 minutes and 134°C - 5 minutes sterilization
CLASS D
EN 867
• 35853 UPSTAR - "BOWIE & DICK" - test
Bowie & Dick test ready for use
Stability of colour change
High sensibility, detect any anomaly
CLASS B
EN 867
Satisfactory:
green uniform
colour
Not Satisfactory: Central red colour
Time and/or temperature and/or steam
pressure uncorrect
35853
TESTS FOR AUTOCLAVE
BOWIE & DICK TEST READY FOR USE
