STERILIZATION
306
• 35658 HYDRA EVO AUTOCLAVE - 15 litres - 230 V
• 35659 HYDRA EVO PLUS AUTOCLAVE - 18 litres - 230 V
Automatic steam autoclaves for the sterilization
of unwrapped instruments. Closure system with an
operator safety pivot. Thermodynamic system for the
ejecting of the "cool" air locks.
Two sterilization cycles: 121°C and 134°C
Automatic phases of pre-heating, sterilization cycle and
drying.
Pre-set, non-modificable cycles
All cycles are pre-set at the factory and guarantee
perfect and safe sterilization of treated materials.
There is no way the operator can manipulate or alter
the cycles, and this safeguards against risks deriving
from human error.
Pre-set temperatures
The temperatures set for our autoclave cycles are 134°C
and 121°C. The 134°C cycles are normally used for the
sterilization of solid and ferrous materials. 121°C cycles
are normally used for sterilization of thermoplastic and
delicate materials.
Water tank
Hydra EVO only has one water tank. This tank must be filled
with distilled or demineralized water and acts as a container
for collecting the used water which is then re-utilized for new
cycles.
Safety on the door
Each door is equipped with 2 locks:
- a mechanical one which does not open when pressure is
exerted
- a dynamic one, that operates thanks to a special form of door
seal
Safety devices installed
- Certified safety valve
- PED on sterilization chambers
- Insulation of the chamber with certified ceramic material.
Cycles
Not
wrapped
121° C
Not
wrapped
134° C
Materials
•Fragile solids
•Rubber solids
•Glass
•Turbines if
indicated by
producer
•Stainless metal
solids
•Turbines if
indicated by
producer
Sterilization time Drying time
Max load
Working
pressure
93/42/EEC
73/23/EEC
93/336/EEC
Medical device
Low tension
Electromagnetic
Compatibility
HYDRA EVO ELECTRONIC 15 OR 18 L STEAMAUTOCLAVE - N
0434
CHAMBERTEST
MICROBIOLOGIC
CERTIFICATION
TECHNICAL SPECIFICATIONS
Stainless steel chamber: Ø 24.5 x 32 cm Ø 24.5 x 40 cm (Plus)
External size: 44 x 38 x 50 cm (W x H x D)
Net weight: 35 kg
2 sterilization cycles: 121°C and 134°C
Operating Voltage: 230 V±10% - 50/60 Hz
Power consumption: 1700W
Class N
Made in Italy - Warranty: 1 year
Controls on the Autoclave
- Control of the water that enters into the chamber
- Safety Thermostat
- Time Control
The sterilization chamber is completely stainless steel AISI
304 and it is heated by a band shaped heating element which
grants uniformity of the heat. Supplied with four aluminium
trays and one key for their extraction.
User manual available in English, French, Italian, Spanish.
• 35671 Sealing GASKET - spare
• 35669
*
HEATING BAND DHY A035 for 35650, 35654
• 35670
*
HEATING BAND DXB A835 for 35658, 35659
*
Need serial number of autoclave
35658
Cycles
Not
wrapped
121° C
Not
wrapped
134° C
Materials
•Fragile solids
•Rubber solids
•Glass
•Turbines if
indicated by
producer
•Stainless metal
solids
•Turbines if
indicated by
producer
Sterilization time
18 min.
6 min.
Drying time
5 min. short dry
or
15 min long dry
5 min. short dry
or
15 min long dry
Max load
2.1 kg
700 g load in
any tray
2.1 kg
700 g load in
any tray
Working
pressure
1.1÷1.2 bars
2.1÷2.2 bars
NUBYRA 6 LITRES STEAM AUTOCLAVE -
CLASS N
• 35647 NUBYRA AUTOCLAVE - 6 litres - 230 V
Electronic steam autoclave for the sterilization of unwrapped
instruments. 2 fully automatic, microprocessor controlled,
sterilization cycles: at 134°C or 121°C with automatic drying.
LCD display with visualization of temperature and pressure
for total control of sterilization cycle. Easy closure system with
double safety sensor. Air pockets automatic ejection system:
thermodynamic system for the ejection of “cold” air pockets.
Anodized aluminium chamber, 2 electronic temperature
sensors (1 inside chamber and 1 outside) and electronic
transducer for better control of pressure.
Supplied with 3 aluminium trays.
Available on request 110 V.
Minimum 10 pieces
• 35648 GASKET - spare
93/42/EEC
73/23/EEC
89/336/EEC
EN 13060
Medical device
Low tension
Electromagnetic
Compatibility
Anodized aluminium chamber:
Ø 17x27 cm - 6.1l
External size: 44x45xh 35 cm
Trays size: 1 large 15x24x2 cm
2 small 11x24x2 cm
2 sterilization cycles: 121°C and 134°C
Maximum load: 2 kg
Operating voltage: 230V - 50/60 Hz
Max absorbed power: 1,300 Watt
Net weight: 27 kg Class N
Made in Italy - Warranty: 1 year
User manual:
English, Italian,
(French, Spanish on request).
0051
TECHNICAL SPECIFICATIONS
35647
20 min.
1.2÷1.3 bars
2.8 kg
700 g load in
any tray
5 min.
10 min.
2.1÷2.2 bars
2.8 kg
700 g load in
any tray
5 min.
