ELECTROMEDICAL DEVICES
132
BREAST PUMP - MAMILAT GIMA
HAND/FOOT/KNEE
SUCTIONPUMP
HAND
SUCTION PUMP
RES-Q-VAC
FILTERED HAND SUCTION
28220
• 28220 TOBI MANUALE - manual suction aspirator
Independent of any power source, Tobi Manuale is simple
to operate pressing pedal by foot, hand or knee.
It is used to clear patient’s airways safely and
efficiently, anytime, anywhere. Precision
and solidly built to assure long service
life. Polycarbonate suction
bottle with capacity 400 cc,
autoclavable at 120°C and
spill-over protection.
Bacterial filter included.
• 28219 BOTTLE 0.4 l -
spare
• 28229 HYDROPHOBIC
ANTIBACTERIAL FILTER
- spare
• 28148 MAMILAT - BREAST PUMP - 230V-50Hz
Easily transportable from one maternity ward to another, or for use at home.
To be used for mother’s milk suction. Made of highly heat-resistant, electrically
insulated plastic material in conformity with the latest European safety standards.
Supplied with 2 polycarbonate milk bottles (150 cc and 250 cc) antibacterial and
hydrofobic filter, set of tubes 6x10 mm, breast shield, PVC air tube. Suction
adjustment knob. Working time: 20 minutes ON, 40 minutes OFF.
• 28149 SPARE KIT
Includes two plastic bottles (125 cc and 250 cc) nipple shield,
filter and tubes.
• 28229 HYDROPHOBIC ANTIBACTERIAL FILTER - spare
TECHNICAL SPECIFICATIONS
Regulator for suction intensity - max suction -0.33 bar
Operating voltage: 220-230 V - 50/60 Hz - available on request 110 V - 60 Hz
Max flow (air litres/min): 14 l/min
Power consumption: 184 VA
Size: 235x190x165 mm Weight: 2.2 kg
Norms: CEI 62-5 (IEC601-1). Made in Italy
Supplied with
anti-bacterial filter
28148
5 languages manual:
Italian, English,
Spanish, French,
German.
TECHNICAL SPECIFICATIONS
Weight: 143 g
Size: 114x180x55 mm
Max vacuum: > 600 mmHg
Min. vacuum after 2 activations: > 400 mmHg
Volume per stroke: 30 ml
Capacity before full: 290 ml
Inner Ø of adult catheter: 9.53 mm
Length of adult catheter: 272 mm
Pump is suitable for cold or ETO sterilization
0470
0.22 micron filter
0476
28129
28128
Jar 300 ml
TECHNICAL SPECIFICATIONS
Weight: 1.2 kg
Size: 225x165x85 mm
Max suction -0.40 bar
Suction power: 22 l/min
Bottle capacity: 400 cc
Made in Italy
TECHNICAL SPECIFICATIONS
Max vacuum: -450 mmHg
Peak free airflow: >20 l/min
External diameter of catheter connection: 13.35 and 8.67 mm
Weight: 260 g
Size: 185x70x168 mm
Jar 400 ml
Jar 250 ml
28124
MEET OSHA
regulations
• 28180 HAND SUCTION UNIT
Designed to provide quick and effective pharyngeal and
tracheal suction for emergency use.
The adjustable stroke knob provides different suction pressure.
Supplied with 250 ml bottle and 2 sterile adult
cannulas 26 and 40 cm
• 28181 SPARE ADULT KIT
Includes 250 ml bottle and
2 sterile adult cannulas
26 and 40 cm.
• 28124 RES-Q-VAC (FILTERED) SUCTION
This lightweight and hand held suction unit requires no batteries or
electricity and yet provides powerful suction whenever and wherever
you need it.
It offers ultimate safety and ease of use for the professional and fits
easily into any emergency bag or ambulance.
Key Features:
- portable Hand Powered Suction - one hand operation
- hospital suction level performance >600mmHg
- always ready to go, no set up required, no batteries to recharge
- patented 0.22 equivalent micron filter for ultimate infection control
- full stop protection filter prevent fluid overflow
- easy snap on replacement canister sets with Adult and Child catheters
- each unit 100% tested for reliability
Kit includes: Res-q-Vac pump, canister 300ml with
filter, soft cannula Ø 12.7 mm x 20.3 cm lenght
• 28128 SPARE ADULT KIT - with filter
Includes canister 300 ml and wide soft adult
style yankauer. Disposable.
• 28129 SPARE PEDIATRIC KIT - with filter
Includes canister 300 ml and 2 pediatric
catheters with different length: 356 mm for
paediatric and 88.9 mm for neonatal
applications. Disposable.
