AUDIOMETRY & SPIROMETRY
222
AUDIOMETRIC BOOTHS -
CONFORM TO 93/42/CEE - 2007/47/CE - class I
•
33660 PRO 45S - 216x216x245
**
cm
•
33661 PRO 45S - 318x216x245
**
cm
•
33662 PRO 45S - size on request
available any size from 1x1 to 6x6
•
33651 TABLE 79x50 cm
•
33652 RAMPS couple for disabled
people
Top of the range, with 11 selection
of sizes, up to 6x6 m, with excellent
noise reduction (-45 dB) and internal
ventilation system. Made in aluminium
and laminate with interior in white,
washable, fire-proof fabric. Large door
75 cm and module for cable connection.
Conform to ISO 8253-1. Made in Italy.
•
33650 PRO 25 - 97x97x192 cm
• 33651 TABLE - 79x50 cm
Portable, compact model, easy to install
in few minutes. Made in plastic laminate,
with internal autoextinguishing,
polyurethane, insulating panels. External
fireproof covering Euroclass B.s2, d 0
Module for cable connection.
Hertz
125 250 500 1000 2000 4000
PRO 25
dB 18,0 16,0 26,7 30,8 28,8 30,9
PRO 30
dB 23,4 24,1 27,8 34,5 31,3 36,4
PRO 45
dB 20,0 33,5 36,3 42,5 42,1 50,4
STANDARD ACCESSORIES
- Module for silent audiometer
cable connection
- Internal illumination
- Ventilation system
(PRO 30, PRO 45 only)
- Wooden box for transport
- Manual: English, Italian
•
33654 PRO 30 - 106x106x245
**
cm
•
33655 PRO 30 - 209x106x245
**
cm
•
33656 PRO 30 - 209x209x245
**
cm
•
33657 PRO 30 - size on request
available any size from 1x1 to 3x3
•
33651 TABLE 79x50 cm
Range with different sizes, with
high noise reduction and internal
ventilation system. Made in
aluminium and laminate with internal
autoextinguishing, polyurethane
insulating panels.
Available with 60 or 90 cm doors.
Module for cable connection.
Made in Italy.
TECHNICAL SPECIFICATIONS
33650
33654
33655
33656
33660
33661
External size (cm):
97x97xh 192
106x106xh 245 209x106xh 245 209x209xh 245
216x216xh 245
**
318x216xh 245
**
Internal size (cm):
85x85xh 186
92x92xh 202
194x92xh 202 194x194xh 202
195x195xh 200 297x195xh 200
Door
size cm:
55xh 168
60xh 200
90xh 200
90xh 200
75xh 186
75xh 186
opening:
Left/Right
Right
*
Right
*
Windows size cm:
58,5xh 58,5
60xh 87
60xh 85
material:
2 - crystal insulating safety glass
4 - crystal insulating safety glass
Wall thickness cm:
7.5
7.5
7.5
7.5
11.6
11.6
Weight (kg):
175
230
364
540
935
1229
Ventilation:
no
yes
yes
yes
yes
yes
Tested noise reduction dB:
28
32
32
32
45
45
Internal illumination power V: 220
220
220
220
220
220
Norms:
Class Medical Devices European Directive 93/42 CEE
*
Left opening available on request
**
Height includes air ventilation system (25 cm)
33650 +
33651
33654 +
33651
33660
Cable connection module
ACOUSTIC INSULATION
45 dB
28 dB
32 dB
TECHNICAL SPECIFICATIONS
Measurement type
OtoAcoustic Emissions.
Frequency range DPOAE
1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 8, 10, 12 kHz.
Frequency range TEOAE
0.7, 1, 1.4, 1.5, 2, 2.5, 2.8, 3.5, 4 kHz.
Stimulus intensity
40 to 70 dB SPL (DPOAE). 83 dB SPL (TEOAE).
Maximum output
90 dB SPL.
(Protection)
(This level is well within OSHA permissible
limits of 90 dBA for 8 hours).
Microphone system noise
-20 dB SPL @ 2 kHz (1 Hz bandwidth).
-13 dB SPL @ 1 kHz (1 Hz bandwidth).
Battery life
Approximately 300 tests.
Display
LCD-display 4 line x 10 character.
Weight
300 g/ 10.6 oz. including batteries.
Internal software languages English, German, French, Spanish, Russian.
DPOAE AND TEOAE
OTOREAD
™
- PORTABLE OAE WITH PRINTER
• 33607 OTOREAD SCREENER TE
• 33608 OTOREAD COMBO DP+TE
The OtoRead™ is a fast, automatic handheld OAE instrument for testing newborn
babies, children and adults. A fast and quiet thermal printer is included with the
OtoRead™. A simple interface from the cradle to the printer will transfer all of
the test data within seconds.
Probe cables
30 cm
Full printout of
both ears
in 7 seconds
16 languages manual:
GB, DE, F, S, GR, I, P,
DK, FI, E; PL, EE, N,
RO, LT, NL,
100-240 V, 50-60 Hz
power supply
TE
Screener
6 bands
(1 fixed protocol)
1.5-4 kHz
DP+TE
Combo
6 bands
6 bands
(2 fixed +2 customizable protocols for DP and TE - a total of 4 protocols) 1.5-12 kHz 700-4 kHz
STANDARD ACCESSORIES
Handheld unit (OtoRead™) including probe cord and Cradle
Printer including power supply and power cable, Printer Cable, Carrying Bag,
Probe cord for extension (100 cm/39 inches), 2 Thermal printer paper rolls
Box of 146 eartips (10 sizes; 3, 4, 6, 7, 8, 9, 10, 11, 12, 13 mm), 4 probe tips
4 AA/UW3/R6 Alkaline Batteries, Operation / CE manual
Weight: 300 g
