AUDIOMETRY & SPIROMETRY
223
TECHNICAL SPECIFICATION
Flow sensor:
Bi-directional digital turbine
Flow range:
±16L/s - ±3% or 50 mL
Flow accuracy:±5% or 200 mL/s
Dynamic resistance: <0.5 cm H
2
O/L/s
Temperature sensor: Semiconductor (0-45°C)
Measured parameters:Reading on spirometer: FVC, FEV1, PEF, FEF 25/75
Reading on PC with Winspiro PRO: same parameters as Spirobank G
SpO
2
range:
0-100% ±2% (50-100% SpO
2
)
Pulse rate range: 20-254 BPM ±2BPM or 2%
Data transmission: USB 2.0 or Bluetooth
Memory capacity: Up to 10000 test - 300 hours oximetry (only with 33473)
Power supply:
Lithium-ion 3.7 V, 1100 mAh rechargeable, for 40 hours
measurements
Size: 74x88x38 mm - Weight: 151 g
• 33471 SPIROTEL with WINSPIROPRO software
• 33472 SPIROTEL with Bluetooth and WINSPIROPRO software
• 33473 SpO
2
PROBE - adult - optional
• 33469 GSM MODULE - optional
- suggested for 33471
For data transmisson via e-mail or FTP to a web server
• 33410 MOUTHPIECES int Ø 2,8 x ext Ø 3, h 6.5 cm
SPIROTEL SPIROMETERS - BLUETOOTH OPTION
• 33508 DISPOSABLE TURBINE WITH INTEGRATED MOUTHPIECE - box of 50
Single patient use. Low cost and high accuracy. Individually packed to guarantee maximum
hygiene. Easy to replace, no calibration needed.
Compatible with GIMA codes: 33509, 33511-14, 33518-22, 33527-29, 33530, 33532, 33534.
• 33526 RE-USABLE TURBINE - bayonet
Easy to replace, no calibration needed. Compatible with GIMA codes: 33511-14, 33518,
33520-22, 33528-32, 33534.
• 33492 MIR SPIROLAB PAPER - roll 112mm x 25m
Suitable also for SIBEL DATOSPIR 120 B, C, D, DATOSPIR Touch
and GIMASPIR 120 models B, C, D.
• 33893 COSMED PONY PAPER - roll 57mm x 10m - box of 5 rolls
• 33894 COSMED PONY FX PAPER - roll 112 mm x 13m - box of 25 rolls
Compatible also with Fukuda Spirosift.
• 33250 THERMAL PAPER - roll 58 mm
Suitable for SIBEL DATOSPIR 120 A and GIMASPIR 120-A.
SPIROMETRY PAPERS
MOUTHPIECES
FOR MOST SPIROMETER BRANDS
Paper mouthpieces (disposable) and plastic mouthpieces (re-usable
for most brands of spirometers and peak flow, as Cosmed,
Fukuda, Ferraris, Micromedical, Mir, Multispiro, Sibel, Vitalograph, ...
Paper mouthpieces are packed in individual transparent pouch
0476
Dispenser of 100
33508
DISPOSABLE AND RE-USABLE TURBINES
FOR MIR SPIROMETERS
• 33599 GIMA AUDIOTEST - pediatric audiology test for early detection of childhood deafness
The only screening tool available to assess the hearing abilities of young patients appears to
be the Boel test, a tool that tests the child's response to a sound stimulus, even at an early
age (between 6 to 10 months). GIMA audiotest is based on the BOEL test both for the
ergonomics (it is designed to be held in the palm of the hand not visible to the child)
and the standard sound of the bells of the Boel test. The two sound stimuli emitted by
the pediatric audiometer reproduce a dull low-frequency tone located around 125-
150 Hz and an acute high-frequency tone located at about 5.0-5.1 kHz in exactly
the same way as the bells of the Boel test (amplitude 86dBA; 96dBA). This means
the child's response to these highly significant thresholds can be tested. Easy to
use, with only two buttons for the selection of two frequencies, lightweight and
battery-powered. To perform original Boel test we suggest to use an optometric
pencil to capture child attention, see code 31319 at page 195.
NOSECLIP
BACTERIAL FILTER
• 33474 NOSE CLIP
• 33525 BACTERIAL FILTER - box of 50 for MIR, Medisoft spirometers
• 33557 SPIROGUARD BACTERIAL FILTER - box of 50
33474
BOEL STYLE PEDIATRIC AUDIOLOGY TEST
GIMA MOUTHPIECES
GIMA
code
Package Material
Sizes - cm
Ø int x ext x h
To be used
with codes
Compatible
with
33410
box of 500
paper 2.8x3x6.5
adult
33431, 33433, 33471-2
33509-14,33518-22,
33528-32, 33534
Micromedical
Vitalograph, Mir
Ferraris (Koko legend)
Cardiette
(Pneumos 300)
33897
dispenser of 100
33411
box of 250
paper 2.0x2.2x6
paediatric
Micromedical
Vitalograph, Mir
33412
-
Plastic adapter
33411
Mir
33506
box of 100
paper 2.6x2.8x6.5 33480, 33484-7
Sibel
33494
box of 100
paper 1.9x2.1x7 33486, 33487
Sibel
33890
dispenser of 100
paper 2.5x2.7x7
-
Fukuda, Thor
33892
dispenser of 100
paper 2.8x3.05x7
-
Cosmed (Pony model)
33898
box of 500
paper 2.8x3.05x7
-
Cosmed (Pony model)
33432
-
plastic 1.7x2.1x5
2.7x3x5 33431, 33433
Ferraris
33691
box of 100
plastic
33682-4, 6, 8
Thor
33526
Class I medical device
according to 93/42/EEC.
Made in Italy.
33599
LCD backlit
touch screen
display
160x80 pixel
A pocket laboratory which integrates 4 devices in one:
- spirometer with touch screen display
- triaxial accelerometer with motion analysis for therapy monitoring
- intelligent 3D oximeter with on screen results (with 33473)
- e-diary for home care symptom control.
Compatible with Qualcomm Life 2 net Hub
0476
Manual and internal software
languages: GB, FR, IT, DE, ES.
Compatibility of Spiroguard
Erich Jaeger Gmbh
Masterlab and Masterscreen
Ferraris Medical - P.K. Morgan Autolink-Benchmark Transflo and USA Transfer System
Sensormedics
2200 - 2400 - 2450
Vitalograph
Wedge-Bellow-Alpha and Escort Spirometers
