AUDIOMETRY & SPIROMETRY
224
PEAK FLOW METERS: DIGITAL AND MECHANICAL
• 33431 POCKET PEAK - standard 60-800 l/min - cream
• 33433 POCKET PEAK - low 50-400 l/min - yellow
The Pocketpeak Peak Flow Meter is designed to provide simple
and reliable home asthma management.
Lightweight and easy to use, it provides accurate and reliable
measurements time and time again.
It is easy to clean and features a universal mouthpiece.
The EU/ATS Scale Pocket peaks will not only comply with the
new European Standards but also with ATS (American Thoracic
Society) Standards.
Standards range pocket peak will cover 60-800 litres/min, low
range will cover 50/400 litres/min.
Package includes multilingual directions for use and peak flow
diary, all packed in a cardboard box. Made in USA.
Size 86x81x30 mm.
Weight 45 g. Standards: EN 13826:2003
• 33432 UNIVERSAL MOUTHPIECES - re-usable
In plastic, sterilizable, suitable both for adults and children.
• 33410 DISPOSABLE MOUTHPIECES - box of 500
Calibrated and graduated scale
from 60 to 800 l/min BTPS
Comply with
EU/ATS
• 33438 POCKET CHAMBER
Now you can manage your asthma
conveniently and effectively with a truly
pocket-sized device, proven as effective
as MDI chambers nearly twice its size.
The Pocket Chamber delivers a high
concentration of respirable aerosol, to
help provide relief from asthma symptoms while capturing
large particles and reducing unwanted side-effects.
- Whistle alerts patients if inspiratory rate is exceeded
- Effective, affordable alternative to expensive aerosol delivery
- Flexible port accepts virtually any MDI's mouthpiece
TECHNICAL SPECIFICATION
Size: 108 x 47.5 mm
Volume: 110 ml
Mouthpiece: 22mm OD
Weight: 33 g
Materials: All Latex Free Silicone
Warranty: One year
User Manual: in English, Spanish, French,
Made in USA
German, Italian, Dutch, Portuguese, Turkish and Greek.
• 33442 RESPIPROGRAM
Device to exercise the respiration through inspiration.
The respiratory-exerciser Respiprogram helps the patient to
recover the normal respiration after a chest or abdominal
surgery. The device is composed of: 1 base, 3 small balls
different in dimension and colours, 1 transparent central part,
divided into 3 rooms, 1 tube and mouthpiece. Each unit packed
in single box. Made in Italy. User manual: English, Italian.
• 33445 TRI-BALL
®
- respiratory exerciser
The respiratory-exerciser Tri-Ball
®
helps the patient to recover the
normal respiration after a chest or
abdominal surgery.
User manual in English, French,
German, Italian, Spanish.
TECHNICAL SPECIFICATION
PEF:
Range 15 - 999 L/min (1 L/min resolution)
FEV
1
FEV
6
:
Range 0.15 - 9.99 Litre (0.01 Litre resolution)
Accuracy:
PEF: ±5% or 20 L/min (whichever is greater)
FEV
1
: ±3.5% or 0.1 Litre (whichever is greater)
FEV
6
: ±4% or 0.1 Litre (whichever is greater)
Sensor:
Pressure/flow sensor technology (patented)
Non-volatile Memory: 96 patient test scores
Colour zone:
3 colour zone (green, yellow, red)
Reference values:
User settable
Quality factor:
Warning & indicator for cough or abnormal blow
Communication:
Bi-directional IR port (RS232 format)
Dimensions-Weight: 75x35x20 mm - 35 g
Plastic mouthpiece suitable
both for adults and children
LUNG EXERCISE DEVICE AEROSOL HOLDING CHAMBER
33438
Designed to bring you the
most effective drug delivery at
the lowest cost of operation
• 33435 PIKO-1 - digital peak flow meter
• 33444 PIKO-6 - digital peak flow meter
• 33436 PC DOWNLOADDEVICE + software
Suitable only for 33435
• 33437 MOUTHPIECES - box of 10 pcs
PiKo-1™ is the world's first pocket sized
electronic peak flow and
FEV
1
meter.
The new PIKO-6™ in addition to FEV
1
, measures
FEV
6
and
FEV
1
/ FEV
6
. Sophisticated features include automatic test
quality alerts and electronic data storage of 96 tests. Data
can be reviewed via a single operating button, eliminating
the errors associated with paper diaries. Prices compare to
mechanical peak flow meters.
PiKoNET software
. All tests can be easily downloaded for
tracking and trending. Results can be saved in pdf format.
Multilanguage
manual
0473
33431
33442
33445
Base and small balls made
in non-toxic polypropylene.
Central part made in copoly-
mere/non-toxic polystyrene.
Tube and mouthpiece made
in polyethylene.
