AUDIOMETRY & SPIROMETRY
225
• 33512 SPIROBANK II + WINSPIROPRO SOFTWARE
Spirometer with 10.000 tests memory capacity, monochromatic
LCD display, 6 keys membrane keypad. Battery power supply
(3,7 V-1100 mA lithium) with an autonomy of approx. 50 hours
of continuous use, rechargeable with USB port.
- cable (USB 2.1) or wireless (Bluetooth 2.0) connection
- internal temperature sensor for automatic BTPS conversion
- high resolution graphic display
- automatic record of a whole spirometry session including best test
- USB cable, carrying case, CDmanual (GB, FR, IT, ES, DE, PT) and
software included. Selectable internal software (GB, FR, IT, ES, DE, PT)
• 33514 SPIROBANK II +WINSPIROPRO SOFTWARE + OXYMETER
Same as above with more than 300 hours of oxymetric test
records (SpO
2
% and pulse frequency tests).
Measured parameters: min, max and average SpO
2
%, min, max
and average pulse frequency, SpO
2
total events, test duration,
bradycardia events (<40 BPM), tachycardia events (>120 BPM), T90%
(time passed with SpO
2
≤89%), T89% (time passed with SpO
2
≤ 88%)
• 33525 ANTIBACTERIAL FILTER - box of 50 disposable
• 33508 DISPOSABLE TURBINE with mouthpiece - box of 50
• 33526 REUSABLE TURBINE
• 33410 MOUTHPIECES int. Ø 2.8 x ext. Ø 3, h 6.5 cm
Winspiropro software functions:
(GB, FR, IT, DE, ES, PT, PL, SE, NL, LV, CZ, TR, RU, CN, JP)
- on-line PC connection with icon interface
- real time Flow/Volume and Volume/time curves
- bronchial challenge with FEV1 dose-response
- paediatric incentive animations
- integration with EPR systems
- Lung Age Estimation
- data and graphs export
also via e-mail
Measured parameters FVC, FEV1, FEV1/FVC%,
DTPEF, FEV 0.5, FEV0.5/FVC%, FEV0.75, FEV0.75/
FVC%, FEV2, FEV2/FVC%, FEV3, FEV3/FVC%, FEV6,
FEV1/FEV6%, PEF, FEF25%, FEF50%, FEF75%,
FEF25-75%, FEF75-85%, FET, Vext, Lung Age,
EVOL, FIVC, FIV1, PIF, FIV1/FIVC%, FIF25%, FIF50%,
FIF75%, R50, PIF, IRV, VC, IVC, IC, ERV, FEV1/VC%,
VT, VE, Rf, ti, te, ti/t-tot, VT/ti, MVV
TECHNICAL SPECIFICATIONS - SPIROMETRY
Flow sensor bi-directional digital turbine
Flow range ±16L/s
Volume accuracy ±3% or 50 mL
Flow accuracy ±5% or 200 mL/s
Dynamic resistance <0.5 cm H
2
O/L/s
Available tests: FVC, VC, IVC, MVV, PRE - POST
Connectivity USB 2.0, Bluetooth
®
2.1
Power supply Lithium-Ion 3.7V, 1100 mAh
SPIROBANK
WITH SOFTWARE
• 33518 SPIROBANK G + WINSPIROPRO software
- stand alone spirometer with PC online operation
- 6000 spirometry in memory
- high legibility graphic display
- FVC, VC, IVC, MVV, PRE-POST BD
- advanced spirometry test interpretation
- Lung Age Estimation (ELA)
- ready for
Telemedicine
applications
- internal temperature sensor for automatic BTPS
- upgradable internal software via internet
Standard package includes USB cable, pouch, noseclip, battery
and Winspiro PRO software. Same accessories as Spirobank USB.
TECHNICAL SPECIFICATION
Power supply: 9V DC PP3 battery
Flow range: + 16 l/s
Flow accuracy: ± 5% or 200 ml/s whichever is greater
Max volume: 10 l - Volume accuracy: ± 3% or 50 ml whichever is greater
Made in Italy
Size: 162x49x32 mm
only 180 g including
battery
Graphic display
(128x48 pixels) with
friendly icons
Graphic display
(128x48 pixels) with user friendly icons
Weight 140 g
0476
0476
SPIROBANK G
WITH SOFTWARE
TECHNICAL SPECIFICATION
Measured parameters: FVC, FEV1, FEV1/FVC%, FEV3, FEV3/FVC%, FEV6, FEV1/FEV6%,
PEF, FEF25%, FEF50%, FEF75%, FEF25-75%, FET, Vext, Lung Age, FIVC, FIV1, FIV1/
FIVC%, PIF, VC, IVC, IC, ERV, FEV1/VC%, VT, VE, Rf, ti, te, ti/t-tot, VT/ti, MVV
Temperature sensor: semiconductor (0-45 °C)
Flow sensor: bi-directional digital turbine
Max volume: 10 l
Flow range: ± 16 l/s
Volume accuracy: ± 3% or 50 ml, whichever is greater
Flow accuracy: ± 5% or 200 ml/s, whichever is greater
Dynamic resistance at 12 l/s: <0.5 cm H
2
O/l/s
Power supply: 9V DC (PP3 battery)
Weight: 180 g (with battery)
Dimensions: 162x49x32 mm
Made in Italy
WinspiroPRO PC system requirements
(GB, FR, IT, DE, ES, PT,PL, SE, NL, LV, CZ, TR, RU, CN, JP)
- Microsoft Windows: Vista, 2000, XP, Me, Seven, 8
- Screen resolution: 1024x768
- Hard disk space: 160 MB
NEWSPIROBANK II - PORTABLE SPIROMETERWITH SPO
2
OPTION
33518
• 33509 SPIROBANK USB - single use turbine
Complete and rapid pocket spirometer for the General
Practitioner to carry out spirometry testing anywhere.
No calibration required, use disposable turbine with
integrated mouthpiece (33508).
- measures the most important spirometric parameters including
FVC, FEV1, FEV1%, PEF, FEF25-75, FET, VC, IVC, FEV6, ELA
- automatic interpretation with traffic light indication
- best test selected and saved in memory
- measured parameters compared to predicted values
- provided with USB cable and simple software Winspiro-
Express for data download and printing only
- selectable display language and CDmanual (GB, IT, ES, FR, DE, PT)
- Suppied in a carrying bag with spare mouthpiece.
• 33508 DISPOSABLE TURBINE with integrated
mouthpiece - box of 50
33514
Size 55x160x25 mm
160x80 pixel display
PC connection via
USB or Bluetooth
®
Health Canada
PC system
requirements:
XP, Seven, Vista, 8
Made in Italy
0476
510 (K)
Measurement method: red and infrared absorption
SpO
2
range: 0-99% ±2 % between 70-99% SpO
2
Pulse rate range: 18-300 BPM ±2 BPM or 2%
Signal quality indicator: 0-8 segments on display
Memory capacity: up to 300 hours oximetry
TECHNICAL SPECIFICATIONS - OXIMETRY (33514 only)
ATS STANDARD
System requirements:
Microsoft Windows Vista,
2000, XP, ME, Seven, 8
Winspiro express
(GB, FR, IT, DE, ES, PT, PL, SE,
NL, LV, CZ, TR, RU, CN, JP)
Supplied with CD manual
(GB, FR, IT, ES, DE, PT)
Internal software
(GB, FR, IT, ES, DE, PT, PL)
