STERILIZATION
304
• 35621 GIMETTE 21 - hot air sterilizer
• 35628 GIMETTE 28 - hot air sterilizer
• 35629 GIMETTE 50 - hot air sterilizer
Fully automatic hot air sterilizer, with adjustable temperature
from 0°C to 200°C, kills off even particularly resistant micro-
organisms.
Stainless steel structure is powder painted, except for the door,
to assure maximum heat and shock resistance over time.
Four perforated, anodized aluminium trays make hot air
circulation easier. Capacity approximately 20 l, 28 l and 50 l.
A second safety thermostat triggers in case temperature should
exceed 230°C.
Red LED indicates any anomaly in thermoregulation and
consequent starting of safety thermostat.
• 35610 TRAY FOR GIMETTE 21 - spare
• 35611 TRAY FOR GIMETTE 28 - spare
35601
35607
35621
GIMETTE 28
GIMETTE 7
GIMETTE 21
35628
TECHNICAL SPECIFICATIONS
GIMETTE 21 GIMETTE 28 GIMETTE 50
Inside dimensions mm:
300x250x260
380x250x260
405x340x350
Approx. volume
20 dm
3
28 dm
3
50 dm
3
Outside dimensions mm:
440x340x400
550x340x400
605x460x480
Weight:
13 kg
17 kg
24.5 kg
Power consumption:
600 Watt
500 Watt
1200 Watt
Same specifications for 3 models:
Operating Voltage: 230 V. - 50 Hz.
Fuses: 2 x 4 A (35621, 35628) 2 x 8 A (35629)
Timer: manual from 0 to 120 minutes Thermostat: automatic
Thermometer: high precision with capillary bulb
2° Thermostat: bi-metallic certified
Green LED: timer, orange LED: heating, red LED: alarm
Made in Italy - Warranty 1 year
User/Service manual in Italian, English, Spanish
• 35601 GIMETTE 1.5 - hot air sterilizer
• 35607 GIMETTE 7 - hot air sterilizer
Automatic Gimette are compact and high quality hot air
sterilizers with the same reliability and efficiency as larger
models.
Outside structure is made of painted plate with anti-scratch
epoxy powder.
Stainless steel lid and sterilization chamber
with approx. Capacity of 1.5 l and 7 l.
Removable, perforated for air circulation, tray with pliers.
All components certified by most important European brands,
assembling in compliance with EN-61010.
A second safety thermostat triggers in case temperature should
exceed 220°C.
Red LED indicates any anomaly in thermoregulation and
consequent starting of safety thermostat.
TECHNICAL SPECIFICATIONS
GIMETTE 1.5
Inside dimensions: 245x120x50 mm = vol. 1.5 dm
3
Outside dimensions: 310x180x180 mm
Weight: 4.3 kg
Power consumption: 250 Watt
Fuse: 1 A
GIMETTE 7
Inside dimensions: 410x180x90 mm = vol. 7 dm
3
Outside dimensions: 490x310x180 mm
Weight: 8 kg
Power consumption: 400 Watt
Fuses: 2 x 2.5 A
Thermometer: high precision with capillary bulb
Same specifications for both models:
Operating Voltage: 230 V - 50 Hz
Thermostat: automatic, adjustable 0-200 °C
Timer: manual from 0 to 120 minutes
2° Thermostat: bi-metallic certified
Green LED: timer, orange LED: heating, red LED: alarm
Made in Italy - Warranty 1 year
0425
0425
HOT AIR STERILIZERS: GIMETTE
1.5, 7, 21, 28 AND 50 LITRES
GIMETTE 1,5
