ELECTROMEDICAL DEVICES
133
TECHNICAL SPECIFICATIONS
Operating voltage: with battery DC 12 V
with power supply 100÷240 V ~ 50/60 Hz - 14 VDC 4,28A
Power consumption: max 50 W
Size:
134x378xh 263 mm Weight:4.7kg(5kgversionforambulance)
Bottle capacity:
1,000 or 2,000 ml
Flow:
30 air litres/min
Sound level:
65 dBA at 1 m
Operating cycles:
continuous (45 minutes battery autonomy)
MAX vacuum:
0 ± 85 kPa
Internal battery:
12 VDC 4A h lead hermetic
Battery autonomy: about 45 minutes, recharging time approx 6 hours
Norms:
MDD 93/42/EEC (Class lIa - annex IX)
EN60601-1(IEC 60601-1) / EN60601-1-2 (IEC 60601-1-2)
UNI EN ISO 10079-1/ UNI CEI EN ISO 14971
Degree of protections against ingress of liquids: IP34d (IEC 529)
Class II- Type B
STANDARD ACCESSORIES
Autoclavable 1 or 2 l jar with safety valve Power supply cord - 2 m
Sterile disposable cannula CH14
Shoulder carrying bag (28283 only)
Sterile disposable manual regulator
Courtesy lamp
Disposable silicone liner 1 l
Multivoltage battery charger
2 bacterial hydrophobic filter
Silicone tubing set Ø 6x12 mm
Cigarette lighter power cord
Support bracket for ambulance (28283 only)
User manual: GB, IT, FR, DE, ES
• 28282 MINIASPEED EVO BATTERY SUCTION - 1 l
• 28283 MINIASPEED EVO BATTERY SUCTION - 1 l for ambulance
• 28284 MINIASPEED EVO BATTERY SUCTION - 2 l
Professional portable high flow - high vacuum aspirators with
integrated rechargeable batteries. It works at 12 V power
supply with rechargeable batteries or directly by mains supply,
continuously at 110-230 V while recharging batteries. Up to 45
minutes of autonomy with fully charged battery. Made in Italy.
• 25480 SILICONE TUBE 6x12 mm - roll of 30 m
• 28254 ADAPTER FOR CATHETER
• 28255 HYDROPHOBIC 99% BACTERIAL FILTER
• 28258 AUTOCLAVABLE JAR 1000 ml (with cover)
• 28259 DISPOSABLE SUCTION LINER
• 28294 AUTOCLAVABLE JAR 2,000 ml (with cover)
MINIASPEED BATTERY EVO
PROFESSIONAL SUCTION ASPIRATORS
GIMA
code
STAINLESS STEEL CANNULA
Stainless steel Frazier suction cannula Ø 2 mm
Stainless steel Frazier suction cannula Ø 3 mm
Stainless steel Frazier suction cannula Ø 4 mm
Stainless steel Frazier suction cannula Ø 5 mm
Stainless steel Rosen suction cannula Ø 1.5 mm
with adaptor with Luer tip and thumb valve
Stainless steel Rosen suction cannula Ø 3 mm
with adaptor with Luer tip and thumb valve
Stainless steel Novak suction cannula for Gyn
Luer adaptor for 26807
26795
26796
26793
26794
26797
26798
26807
26799
GIMA
code
STAINLESS STEEL ASPIRATION TUBE
S/S Bierer Aspiration tube Ø 8 mm
S/S Bierer Aspiration tube Ø 12 mm
Supplied with removable connection cannula
Set of 7 uterine aspiration cannulas for abortion:
each set is composed of 4 cannulas with side
suction end (Ø 5, 6, 8, 9 mm), 3 cannulas with
front suction end (Ø 7,10,11 mm) and one handle
28262
28264
28260
26797
26798
26796
26807
26799
26795
28260
28262
LED for battery
status
Suction on/off Vacuum adjustment Vacuum
Lamp
on/off
Space for accessories
28282
Courtesy lamp
28247
Available on request other
sizes and
length 60 cm
Autoclavable
at 134 °C
up to 100 times
GIMA
code
SILICONE VACUUM SUCTION - AUTOCLAVABLE
Silicone vacuum suction Ø 60x210 mm
Silicone vacuum suction Ø 70x210 mm
29980
29981
Suction catheter CH 14 Ø 4.66 mm x 48 cm - green
Suction catheter CH 16 Ø 5.33 mm x 48 cm - orange
Suction catheter CH 18 Ø 6.0 mm x 48 cm - red
Suction catheter CH 20 Ø 6.6 mm x 48 cm - yellow
28247
28248
28249
28250
GIMA
code
SUCTION CATHETER-STERILE
ACCESSORIES FOR ANY SUCTION ASPIRATOR
SUPER VEGA BATTERY SUCTION ASPIRATOR ON TROLLEY
Size - Weight:
32x30xh 99 cm - 7.9 kg
Operating voltage: 100-240 V - 50/60 Hz
Internal rechargeable Pb battery: 12V - 4A
Battery autonomy: 60 min
Flow:
36 air litres/minute
User manual:
GB, FR, DE, IT, ES
Recharging: 120-150 min
Temporary use: 120 on - 60 off
Made in Italy
• 28193 SUPER VEGA BATTERY on trolley - suction 2x2 l
Portable suction unit for the aspiration of body liquids, oral, nasal and
tracheal aspiration in adults or children. For professional use and with a
powerful aspiration of max 36 l/min. It comes with double collection jars
and on a stand with five castors for easy transport.
Two different working options: AC/DC adapter, rechargeable battery
make it a versatile suction unit approved for NON-STOP operation
without overheating.
Provided with visual and acoustic alarm indicating low battery level,
vacuum-meter (bar & kPa) and vacuum regulator.
TECHNICAL SPECIFICATIONS
Silicone tubing
8x14 mm
2 l jar
