ELECTROSURGERY
154
MONO-BIPOLAR ELECTROSURGICAL UNITS 120WAND 160W
0051
0051
MONOPOLAR ELECTROSURGERY UNITS 50W AND 80W
TECHNICAL SPECIFICATIONS
MB 120D
MB 160D
Max output power CUT
120 W-250 Ω
160 W-250 Ω
Max output power BLEND
90 W-200 Ω
120 W-200 Ω
Max output power FORCED COAG
80 W-150 Ω
100 W-150 Ω
Max output power SOFT COAG
60 W-100 Ω
80 W-100 Ω
Max output power BIPOLAR
40 W-100 Ω
60 W-100 Ω
Working frequency
600 kHz
600 kHz
Patient circuit
F
F
Selectable input voltage
115 - 230 Vac
115 - 230 Vac
Mains frequency
50 - 60 Hz
50 - 60 Hz
Electrical input power
300 VA
350 VA
Size WxHxD mm
254x104x288
254x104x288
Weight
5 kgs
5 kgs
Controls: Patient/Plate circuit monitoring, Output power monitoring,
Self check control
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical Class: I CF,
MDD 93/42/EC Class: II b
TECHNICAL SPECIFICATIONS
50
80
Max output power CUT
50 W-400 Ω 80 W-400 Ω
Max output power CUT/COAG1 45 W-400 Ω -
Max output power CUT/COAG2 40 W-400 Ω -
Max output power BLEND
-
60 W-400 Ω
Max output power COAG
40 W-400 Ω 50 W-400 Ω
Max output power MICRO
-
20 W-600 Ω
Working frequency
600 kHz
700 kHz
Patient circuit
F
F
Selectable input voltage
115 - 230 Vac 115 - 230 Vac
Mains frequency
50 - 60 Hz
50 - 60 Hz
Electrical input power
200 VA
230 VA
Size WxHxD mm
190x85x239 190x85x239
Weight
2.5 kg
2.5 kg
Controls: Patient/Plate circuit monitoring, Output power monitoring,
Self check control
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical Class: I CF,
MDD 93/42/EC Class: II b
• 30628 DIATERMO MB 120D - mono-bipolar - 120 W
• 30629 DIATERMO MB 160D - mono-bipolar - 160 W
MB 120D and MB 160D are high frequency electrosurgical
units suitable for minor and medium surgery.
MB allow pure CUT, cut-coagulation BLEND, superficial
coagulation FORCED COAG, deep coagulation in absence of
necrosis SOFT COAG and, with forceps, BIPOLAR coagulation.
The digital reading of delivered power and the monitoring
of operative function by microcontroller guarantees absolute
reliability of working conditions.
MB allow a highly professional surgery through ergonomic
and safety features. The connection of neutral electrode is
constantly monitored. Safety control of patient/plate contact
using split neutral electrode.
Possibility to control the output functions and the delivery of
output power by the handle, allows the surgical operation
without diverting attention from the surgical field.
Features:
- minimum invasive surgery
- possibility to use bipolar forceps
- possibility to use split neutral electrodes
- memorization of the last used settings
- power activation by pedal and/or handle
- digital adjustment and indication of the output power
- adjustment of the acoustic indicator intensity.
STANDARD ACCESSORIES
MB single use two button handle
Waterproof foot-switch 30577 (usable as alternative to handle)
MB flat neutral plate (30566) and cable (30559)
Kit of 10 short autoclavable electrodes, diam. 2.4 mm. Power cable: 2 m
User manual:
English, Italian,
available on request French, Spanish, Polish
STANDARD ACCESSORIES
Single use handle
Waterproof foot-switch (30577)
Metal plate (30566) + cable (30559)
Kit of 6 short autoclavable electrodes, Ø 2.4 mm, length 5 cm
(30501/2/4/7/9/10) see page 159
Power cable 2 m - Shuko plug
User manual: English, Italian,
available on request French, Spanish
CASUALTY SURGERY
PEDIATRIC SURGERY
*
PLASTIC SURGERY
*
VASCULAR SURGERY
DERMATOLOGY
FIRST AID
OTORHINOLARYNGOLOGY
UROLOGY
*
GYNAECOLOGY
VETERINARY
DENTISTRY
**
DENTISTRY
DERMATOLOGY
OUT PATIENT SURGERY
FIRST AID
VETERINARY
*
VASCULAR SURGERY
*
• 30625 DIATERMO 50 - monopolar
• 30626 DIATERMO 80 - monopolar
DIATERMO 50 and 80 are radiofrequency electrosurgical units
suitable for minor monopolar surgery.
Diatermo 50 through the function selection makes pure cut,
cut coagulation (CUT 1 - CUT 2) and pure coagulation possible.
Diatermo 80 has a multifunction selector which makes cutting
(CUT), cut coagulation (BLEND), coagulation (COAG) and micro-
coagulation (MICRO) possible. The one-board microcontroller
and digital display guarantee high safety and reliability under
any conditions. They offer outstanding professional surgical
results due to their ergonomic and superior safety features.
*
Diatermo MB160 only
* *
Diatermo MB120 only
*
Diatermo 80 only
