GYNAECOLOGY
144
DISPOSABLE RECTOSCOPE AND ANOSCOPE
• 25953 F.O. ILLUMINATION HEAD
This head perfectly fits and illuminates the disposable anoscopes,
rectoscopes, proctoscopes for GIMA, HEINE, WELCH ALLYN, GPS. It can be
connected to a light source by a F.O. cable or to a LED illumination system.
See at page 164 - 165.
• 25947 DISPOSABLE ANOSCOPE - sterilized - box of 60
Length 10 cm, with stylet diameter of 17 mm, suitable for treatment of
haemorrhoids.
• 25949 DISPOSABLE RECTOSCOPE - sterilized - box of 50
Length 25 cm, with stylet diameter of 17 mm, scale in cm, illumination in
distal exit thanks to the opaque black tube placed inside the transparent
body which enables the light to shine without shadow.
Disposable proctoscope see at page 152.
LIGHTING SYSTEMS
All products in this page are supplied with Acmi/Wolf light connection. To bring the light to
these connection it is necessary to buy a Wolf adaptor (30841) a F.O. cable (30818-30826) a
light source adaptor (30830) and a light source (30801-30802). See page 164-5.
To better hang the instruments during the use we suggest below handle that can be placed
between the instrument and F.O. cable.
• 30798 HANDLE
for Ano/Procto/Rectoscope and Sigmoidoscopes. Need light source
Alternatively you can choose a more economic solution, for illumination, inclusive of handle
• 30799 ILLUMINATED HANDLE 6.0 VOLT - HALOGEN BULB
Works as an indipendent light source for F.O. instruments. Direct connection to all F.O.
instruments in this page.
• 30800 HALOGEN BULB - spare for 30799
instrument side
F.O. side
25947
- anoscope - 10 cm
Wolf / ACMI
connection
Insufflator adaptor 1.8 x lens
25953
30798
The disposable anoscope and rectoscope
are sold in a paper and nylon/polyethyle-
ne envelope sterilized in ethylene oxide.
• 29418 LLOYD - DAVIES SIGMOIDOSCOPES SET
Sigmoidoscope set is composed by one light chamber, with
Acmi/Wolf/Storz adaptor, one adult tube Ø 20x300 mm, one
boy tube Ø 16x250 mm, and one child tube Ø 10x75 mm, in a
soft pouch.
To light set you can use illuminated handle (code 30799) or
Gima light source (30801), light source adapter (30830), F.O.
cable (30818) and adapter (30840).
Handle for Biopsy forceps
Biopsy forceps 3.5x8 mm Cup Jaws - 420 mm
Biopsy forceps 4 mm - Cutting Jaws - 420 mm
Sponge Holding forceps - 400 mm
Suction Tube - 400 mm
Twin Bellow Insufflator
29420
29421
29422
29425
29426
29427
GIMA
code
S/S ACCESSORIES FOR F.O.
ANOSCOPES, PROCTOSCOPES, SIGMOIDOSCOPES
29427
29425
29426
29420+29421
Light chamber
Child tube
Same connections as beside sigmoidoscope. See other adaptors at page 165
Adult tube
LIGHTING SYSTEMS:
LIGHT SOURCE OR ILLUMINATED HANDLE
25949
- rectoscope - 25 cm
25 cm
10 cm
30799
F.O. ANOSCOPES
F.O. PROCTOSCOPE
With 2.0X
magnifying lens
To connect sigmoidoscope to Gima light source (30801, 30802) you need: F.O. cable
(30818-30826), adaptor (30830) to connect cable to light source, 2 adaptors (30840,
30844) to connect sigmoidoscope to F.O. cable.
29405
F.O. ANOSCOPES, PROCTOSCOPES F.O. SIGMOIDOSCOPES
GIMA
code
F.O. ANOSCOPES - PROCTOSCOPES
ADAPTOR
included
29400
29401
29402
F.O. Anoscope Ø15x70 mm - with obturator
F.O. Anoscope Ø20x70 mm - with obturator
F.O. Anoscope Ø25x70 mm - with obturator
Wolf/Acmi/Storz
Wolf/Acmi/Storz
Wolf/Acmi/Storz
29403
29405
30840
Set of 3 F.O. anoscopes with Wolf and Storz
connector in a case
F.O. Proctoscope Ø20x130 mm - with obturator with
2.0X and Wolf, Acmi, Storz adaptors
ENDO STORZ ADAPTOR - to connect with Gima F.O. cable
GIMA
code
F.O. SIGMOIDOSCOPES WITH 2.0X
MAGNIFICATION SWIVEL LENS
ADAPTOR
included
29410
29411
29412
29413
29414
F.O. Sigmoidoscope - 12x200 mm
F.O. Sigmoidoscope - 16x250 mm
F.O. Sigmoidoscope - 21x200 mm
F.O. Sigmoidoscope - 21x250 mm
F.O. Sigmoidoscope - 21x300 mm
Wolf/Acmi/Storz
Wolf/Acmi/Storz
Wolf/Acmi/Storz
Wolf/Acmi/Storz
Wolf/Acmi/Storz
30840
ENDO STORZ ADAPTOR - to connect with Gima F.O. cable
