ELECTROSURGERY
158
STANDARD ACCESSORIES
1 - Power supply cord 5 m
1 - Two-button handle (autoclavable code 30539)
5 - Two-button handle (cold sterilizable code 30551)
1 - Cable for flat plate (30559)
5 - Rem disposable ground pads (30565)
2 - HP double Water proof foot switch
3 - Short, general surgery blade electrode 7 cm
3 - Long, general surgery blade electrode 16 cm
3 - Short, general surgery ball electrode Ø 4 mm, 6 cm
1 - Electrode brush
1 - User manual (Italian, English)
1 - Service manual (Italian, English)
• 30634 DIATERMO MB 300D
• 30635 DIATERMO MB 400D
DIATERMO MB300 and MB400 are high frequency electro-
surgical equipments suitable to deliver current for monopolar
cut and coagulated cut (with different levels of coagulation),
bipolar cut and coagulation.
TWIN OPERATIVE ACTIVITY
- two output channels for monopolar cutting
- two independent setting and output channels for the most
frequent monopolar coagulation
CONTROLLED CUTTING PROCEDURES
- enhanced cutting current for eschar free incision
- cutting current with selectable coagulating property for
bleeding controlled dissection
- low capacitive coupling by slow BLEND current for endoscopic
procedures
TWIN CONTROLLED COAGULATION PROCEDURES
- SPEEDY coagulation and DEEP coagulation available to two
operators
- SPRAY coagulation by hand switch or foot switch controls
EXTENSIVE BIPOLAR FEATURES
- bipolar cutting current with selectable bleeding control
- slow BLEND cutting current
- automatic Start/Stop coagulation functions
SURGEON AND PATIENT TOTAL SAFETY·
- acceptability of contact impedance between patient body
and return electrode continuously monitored by Skin Plate
Electronic Control (SPEC)
- H.F. Leakage currents continuously monitored
- mains fluctuation automatically compensated before delivery
of HF power
PERSONALIZED PROCEDURES
- independent choice of coagulation currents and power levels
by each of two operators
- up to 10 procedures can be configured and re-called
EXTENSION DRIVER AND INTERLOCK SIGNALS
- driven output connection to external Argon Plasma unit and
Smoke Evacuator unit
AUTOMATIC SELF DIAGNOSIS
- automatic diagnostic control of the complete functionality of
electronic unit and connected accessories with coded report of
failures
SUITABLE IN:
OUTPATIENT SURGERY
GENERAL SURGERY
PAEDIATRIC SURGERY
PLASTIC SURGERY
THORAX SURGERY
VASCULAR SURGERY
DERMATOLOGY
ENDOSCOPY
GASTROENTEROLOGY
GYNAECOLOGY
NEUROSURGERY
ORTHOPEDICS
OTORHINOLARINGOLOGY
PNEUMOLOGY
UROLOGY
VETERINARY
TECHNICAL SPECIFICATIONS MB300/MB400
HIGH POWER ELECTROSURGICAL UNITS 300 AND 400 WATT
MB 300
MB 400
Maximum out power monopolar pure CUT
300 W - 300 Ω
400 W - 300 Ω
Maximum out power monopolar cut-coag CUT80%
250 W - 300 Ω
350 W - 300 Ω
Maximum out power monopolar cut-coag CUT60%
200 W - 300 Ω
250 W - 300 Ω
Maximum out power monopolar cut-coag CUT40%
150 W - 300 Ω
200 W - 300 Ω
Maximum out power monopolar cut ENHANCED
200 W - 500 Ω
250 W - 500 Ω
Maximum out power monopolar cut-coag BLEND
200 W - 300 Ω
250 W - 300 Ω
Maximum out power monopolar coag SPEEDY
100 W - 500 Ω
120 W - 500 Ω
Maximum out power monopolar coag DEEP
100 W - 200 Ω
120 W - 200 Ω
Maximum out power monopolar coag SPRAY
70 W - 2000 Ω
100 W - 2000 Ω
Maximum out power monopolar coag SPRAY ARGON
70 W - 2000 Ω
100 W - 2000 Ω
Maximum out power bipolar CUT
95 W - 150 Ω
95 W - 150 Ω
Maximum out power bipolar cut-coag CUT80%
95 W - 150 Ω
95 W - 150 Ω
Maximum out power bipolar cut-coag CUT60%
95 W - 150 Ω
95 W - 150
ΩMaximum out power bipolar cut-coag CUT40%
60 W - 150 Ω
60 W - 150 Ω
Maximum out power bipolar cut-coag BLEND
90 W - 150 Ω
90 W - 150 Ω
Maximum out power bipolar cut-coag BLEND
70 W - 100 Ω
70 W - 100 Ω
Working frequency monopolar / bipolar
425 kHz / 525 kHz
425 kHz / 525 kHz
Patient circuit
F
F
Selectable input voltage
115-230 Vac
115-230 Vac
Mains frequency
50-60 Hz
50-60 Hz
Electrical input voltage
1000 VA
1000 VA
Size WxHxD mm
470x150x400
470x150x400
Weight
17.5 Kgs
17.5 Kgs
Controls: Patient/Plate circuit monitoring, Output power monitoring, Self check control
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical Class: I CF, MDD 93/42/EC Class: II b
30634
30635
0051
