ELECTROSURGERY
157
• 30690 DIATERMO MB 240
• 30692 DIATERMO MB 380
These HF electrosurgical units can be used to execute
monopolar and bipolar surgery when high precision and
reliability are essential, as in the endoscopic surgery.
EASY TO USE
Graphic icons allow an easy selection of the operation mode.
All operating conditions and selected output controls are
represented by bright digital indications.
CUT
The monopolar cut can be performed by pure sine current to
obtain an incision with a minimum damage for the adjacent
tissues and sure recovery for first intention.
Two different modes of modulation allow to reduce
bleeding during monopolar cut. In the bipolar mode
the cut can be effected by pure sine current.
HEMOSTASIS
When the surgical action requires the obliteration of a blood
vessel the availability of currents with different coagulative
powers enables this type of work both with monopolar and
bipolar surgery.
FULGURATION
When it is necessary to cause a superficial necrosis of wide
areas, protecting the deeper tissues, a special coagulant
current that dehydrates the superficial layer of the tissue and
reduces the possibility to damage those beneath is available
for the operation.
OUTPUT CONTROL
Output power levels are adjustable through incremental
STANDARD ACCESSORIES
1 - Power supply cord SIEM-CEE 5 m
1 - Two-button handle (autoclavable code 30547)
5 - Two-button handle (cold sterilizable)
1 - Cable for disposable plate
5 - Disposable plate
1 - Water proof double foot switch
3 - Short, general surgery blade electrode
3 - Long, general surgery blade electrode
3 - Short, general surgery needle electrode
3 - Short, general surgery ball electrode
1 - User manual (Italian, English, Spanish)
1 - Service manual (Italian, English)
0051
encoders that allow the exact pre-sets and repetition of the
values. The output function is linearized and controlled by
ultra-modern electronic micro-controllers which will interrupt
power if any alarm condition happens.
SAFETY OF USE
Circuits dedicated to the safety of operator and patient are
the priority. This ensure the leakage current is kept well
under the international requirements values, whatever the
output condition. Monopolar and bipolar output circuits are
completely floating and the use of the defibrillator is allowed
while the reference plate patient is connected.
RELIABILITY
DIATERMO MB uses all solid state electronic circuits and is
made with interchangeable units for a fast and effective
maintenance. Automatic control circuits protect the units from
damage also in case of repeated improper use.
30690
30692
CONTEMPORARY DUAL MODE MB 240 and 380 can
be used in the same time in monopolar
mode (by handle) and bipolar mode (by footswitch)
A special electronic circuit (Skin Plate Electronic Control) continuously warns
the plate to patient contact safety and unwanted short circuit in the connec-
ting cable
Activation devices
Bipolar: footswitch
Dual: bipolar - footswitch
monopolar - manual
Monopolar: footswitch
manual
Mains: 115/230 Vac 50-60 Hz
Absorption: 800 VA
Class I CF
Weight: 15 kg
Size: 370x470xh 150 mm
Warranty: 12 months
(accessories not included)
Norms: IEC 601-2-2 - IEC 601-1
CE, 93/42/EEC
TECHNICAL SPECIFICATIONS DIATERMO MB 240/DIATERMO MB 380
Working
Max power
Peak to peak
Load
frequency
240/MB 380
voltage resistance
Monopolar output
475 kHz
Cut output
250W/375W
1,4 kV
300 Ohm
Cut/coag 1 output
225W/340W
1,4 kV
300 Ohm
Cut/coag 2 output
200W/300W
1,4 kV
300 Ohm
Coag 1 output
150W/225W
1,4 kV
300 Ohm
Coag 2 output
100W/150W
1,4 kV
300 Ohm
Coag 3 output (spray)
80W
4,2 kV 2000 Ohm
Bipolar output
525 kHz
Cut output
90W
0,5 kV
100 Ohm
Coag output
80W
0,5 kV
100 Ohm
LAPAROSCOPIC ELECTRODES
HOSPITAL HF ELECTROSURGICAL UNITS 240 AND 380 WATT
30605
L-Hook electrode - 36 cm
30606
J-Hook electrode - 36 cm
30607
Spatula electrode - 36 cm
30609
Monopolar cable - 4 mm - M - F
LAPAROSCOPIC ELECTRODES
GIMA
code
30605
30606
30607
Laparoscopic electrodes
without suction for
use with Diatermo MB
240/250/300/380/400
with connecting cable
4 mm (30609)
30605
To generator
