ELECTROSURGERY
155
• 30542 DIATERMO MB 200 - 200 Watts
DIATERMO MB200 is a HF electrosurgical unit suitable to
perform middle monopolar or bipolar electrosurgery. The
available waveforms and peak voltage value, as well as the
accurate HF leakage current operation for polypectomy, TURP,
intrauterine resections, endometriosis excision, etc. The units
allow the accurate preset of the output power with as low as
1 Watt resolution and to perform coagulation by high crest
factor current, to get an elevated thermal effect, as well as
with low voltage low crest factor current, to get coagulation
in absence of carbonization. Ten different programs related to
ten different operative conditions could be stored and easily
recalled by the surgeon. The use of either split or normal
neutral plates are allowed. A special electronic circuit (Skin
Plate Electronic Control) continuously checks if the plate is
safely connected to the patient and detects unwanted short
circuit in the connecting cable. An over time warning (OVT) is
provided to prevent excessive heating of the tissue around the
surgical target due to too long current delivery time.
30542
DIATERMO MB 200 - STANDARD ACCESSORIES
MB two-button handle (autoclavable code 30547) handle in beside picture is
not correct
MB waterproof foot-switch 30577 (usable in alternative to handle)
MB flat neutral metal plate with cable
Kit 10 short standard electrodes, diam. 2.4 mm
Power cable 2 m
Manual: available in English, Italian
Crest factor
Maximum output power CUT (W)
200
250Ω
1.5
Maximum output power CUT 90% (W)
200
250Ω
1.6
Maximum output power CUT 80% (W)
200
250Ω
1.7
Maximum output power CUT 70% (W)
200
250Ω
1.8
Maximum output power BLEND (W)
120
200Ω
2.1
Maximum output power COAG FORCED (W) 150
150Ω
2.0
Maximum output power COAG SOFT (W) 90
100Ω
1.7
Maximum output power BIPOLAR COAG (W) 100
100Ω
1.5
Maximum output power BIPOLAR CUT (W) 120
250Ω
1.5
Working frequency
600 kHz
Weight kg
8
Size LxHxD mm
360x150x265
Selectable mains power(Vac)
115 -230
Mains frequency (Hz)
50-60
Fuses 115Vac - 230Vac (5x20) TIMED
2x 6.3A - 2x 3.15A
Power accuracy output warning system
•
Split or not split patient plate allowed
•
Electrical Class (EN60601 - 1)
I CF
MDD 93/42/EEC Class
II b
Patient circuit
F
Duty cycle (action/pause) in seconds
10/30
TECHNICAL SPECIFICATIONS
Maximum output power CUT
200W - 250Ω
Maximum output power ENHANCED
120W - 250Ω
Maximum output power BLEND
120W - 200Ω
Maximum output power FORCED COAG
150W - 150Ω
Maximum output power SOFT COAG
90W - 100Ω
Maximum output power BIPOLAR COAG
80W - 50Ω
Working frequency
600 kHz
Patient circuit
F
Mains voltage
115-230 Vac
Mains frequency
50-60 Hz
Electrical input power
350 VA
Size WxHxD mm
370x144x319
Weight
6 kgs
Controls: Patient/Plate circuit monitoring, Output power monitoring,
Self check control
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical Class: I CF,
MDD 93/42/EC Class: II b
MONO-BIPOLAR ELECTROSURGICAL UNIT 200W
DIATERMO MB 200 - MONO-BIPOLAR - 200W
• 30630 DIATERMO MB 200D - 200 Watt
MB 200 is a high frequency electrosurgical equipment suitable for light
and medium surgery, allows minimally invasive surgical procedure of
resection, evaporation and coagulation.
MB 200 allows pure CUT, Cut-Coagulation BLEND, incision with
reduced production of eschar ENHANCED, superficial coagulation
FORCED COAG, deep coagulation in absence of necrosis SOFT COAG
and BIPOLAR coagulation. Digital reading of delivered power and
surveillance through microcontroller of the operational functions,
assure absolute reliability of working conditions.
MB 200 allows a highly professional surgery through ergonomic and
safety features. The connection of neutral electrode is constantly
monitored. Safety control of patient/plate contact using split neutral
electrode. Possibility to control the output functions and the delivery
of output power by the handle, allows the surgical operation without
diverting attention from the surgical field.
- patient-to-plate contact control
- split return electrode use
- minimally invasive surgical
treatment allowed
- monopolar and Bipolar indipendent output
- auto Start/Stop in Bipolar Coag
- working condition planning
- power delivery by pedal and/or handle
- digital regulation and indication of the output power
- sound level control
- adjustable power increment
TECHNICAL SPECIFICATIONS
OUTPATIENT SURGERY
ENDOSCOPY
FIRST AID
GASTROENTEROLOGY
GENERAL SURGERY
GYNAECOLOGY
NEUROSURGERY
ORTHOPEDICS
OTORHINOLARYNGOLOGY
PEDIATRIC SURGERY
PLASTIC SURGERY
PNEUMOLOGY
UROLOGY
VASCULAR SURGERY
VETERINARY
STANDARD ACCESSORIES
MB two-button handle (autoclavable code 30547)
Waterproof MB foot-switch (30577)
MB flat neutral metal plate (30566) with cable (30559)
Kit 10 short standard electrodes, diam. 2.4 mm
3 needle + 3 blade + 3 ball electrodes 7 cm
Power cable 5 m
Manual: available in English, Italian
