ELECTROSURGERY
156
TECHNICAL SPECIFICATIONS
MB 120F
MB 200F
Max output power CUT
120 W-250 Ω 200 W-250 Ω
Max output power BLEND
90 W-200 Ω 120 W-200 Ω
Max output power ENHANCED
90 W-250 Ω 120 W-250 Ω
Max output power FORCED COAG
80 W-150 Ω 150 W-150 Ω
Max output power SOFT COAG
60 W-100 Ω 90 W-100 Ω
Max output power BIPOLAR COAG
60 W-50 Ω
80 W-50 Ω
Working frequency
600 kHz
600 kHz
RF power pulse emission time
10ms - 30sec 10ms - 30sec
RF power pulse interval
1 - 9
1 - 9
Patient circuit
F
F
Selectable input voltage
115 - 230 Vac 115 - 230 Vac
Mains frequency
50 - 60 Hz
50 - 60 Hz
Electrical input power
300 VA
350 VA
Size WxHxD mm
370x144x319 370x144x319
Weight
6 kg
6 kg
Controls: Patient/Plate circuit monitoring, Output power monitoring,
Self check control
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical Class: I CF,
MDD 93/42/EC Class: II b
MONOPOLARANDBIPOLARELECTROSURGICALUNITS120WAND200W
OUTPATIENT SURGERY
DERMATOLOGY
VASCULAR SURGERY
GYNECOLOGY
DENTAL*
OTORHINOLARYNGOLOGY
PEDIATRIC SURGERY**
FIRST AID
PLASTIC SURGERY**
ENDOSCOPY
OPHTHALMOLOGY
NEUROSURGERY**
PODIATRY**
PNEUMOLOGY**
UROLOGY**
VETERINARY
GASTROENTEROLOGY
ORTHOPEDICS**
STANDARD ACCESSORIES
MB two-button autoclave handle
Waterproof MB footswitch (30577)
MB metal plate (neutral electrode 30566) and cable (30559)
2 disposable ground pads (30562)
Kit 10 short standard electrodes Ø 2.4 mm
3 needle + 3 blade + 3 ball electrodes 7 cm
Power cable 5m
Microsurgery handle (30552)
Microsurgery needles 10 pieces
Manual: English, Italian
30631
30633
0051
• 30631 DIATERMO MB 120 FLASH
• 30633 DIATERMO MB 200 FLASH
MB FLASH are a High Frequency ElectroSurgical
equipment suitable for precision monopolar and bipolar
surgery and micro-surgery without tissue alterations.
MB FLASH allow surgical treatments with programmable timer
operations up to milliseconds or with traditional mode.
MB FLASH allow pure CUT, cut-coagulation BLEND, incision
with reduced production of eschar ENHANCED, superficial
coagulation FORCED COAG, deep coagulation in absence
of necrosis SOFT COAG and BIPOLAR coagulation. Digital
reading of delivered power and the surveillance through
microcontroller of the operational functions, assure absolute
reliability of the working conditions.
MB FLASH allow a highly professional surgery through
ergonomic and safety features.
Connection of neutral electrode is
constantly monitored.
Safety control of patient/plate
contact using split neutral electrode. Possibility to control the
output functions and the delivery of output power by handle,
allows surgical operation without diverting attention from the
surgical field.
Features:
- patient to plate contact control
- split return electrode use allowed
- minimally invasive surgical treatment allowed
- Monopolar and Bipolar indipendent output
- auto Start/Stop in Bipolar Coag
- working condition planning
- power delivery by pedal and/or handle
- digital regulation and indication of the output power
- sound level control
- adjustable power increment
- RF power pulse emission time setting
- RF power pulse interval setting
• 28340 ELECTRO-DEPILATOR 400
This device ensures a definitive depilation with thermolitic
method. It delivers a current of radiofrequency to cause the
heating and consequent coagulation of the papilla, reached
through the introduction of a needle into the follicle of the hair.
Provided with highly reliable electronic integrated
components, with RF intensity adjustable with continuity and
luminous working signal.
It comes complete with footswitch, handpiece for depilation,
depilation needle and power cable (2 m).
TECHNICAL SPECIFICATIONS
RF output frequency: 1.9 ±10% MHz
Modulation: sinusoidal
Maximum output power: 7 ±2Watt
Size: 260x265xh 110 mm
Weight: 4 kg
Operating voltage: 115/230 V - 50/60 Hz switchable
Norms: CEI 62-39 Class: I-BF
• 30552 HANDPIECE FOR DEPILATION
• 30560 DEPILATION OR MICROSURGERY NEEDLES
• 30577 FOOTSWITCH
ELECTRODEPILATOR
* Diatermo MB 120 only
**Diatermo MB 200 only
