ELECTROSURGERY
160
Valleylab connector HANDLES with 2 “click” push-buttons
GIMA autoclavable electrosurgery pencils with CUT-COAG switch
have been studied and tested to offer maximum reliability and
functionality to the operator. MB handles are provided with a 3
Pin plug Valleylab type fitting all Gima mono-bipolar Diatermo
MB (120, 122, 132, 160, 200, 202, 240, 250, 380, 400) and most
of bipolar electrosurgical units: Aspen Lab, ES Generator, EMC
Statome, Danieli, Braun, Berchtold, Ohmeda, Ritter, Conmed,
Eschmann, Bovie, Martin, Kontron, Bard, Birtcher 771, Cobi,
Valleylab, Led, Erbe...
• 30554 MB AUTOCLAVABLE HANDLE - 100 times
Autoclavable handle
with 2 large “click” push-buttons
, provided
with a 3 meter long silicone cable and a blade electrode.
It can be autoclaved up to 100 times (electrode 20 times).
For electrodes Ø 2.4 mm
• 30545 MB AUTOCLAVABLE HANDLE - 100 times
Same as code 30554 but with a 5 m long silicone cable
• 30550 PRIMA MB AUTOCLAVABLE HANDLE - 60 times
Autoclavable handle
with 2 large “click” push-button
, provided
with a 3 meter long silicone cable and a blade electrode.
It can be autoclaved up to 60 times.
For electrodes Ø 2.4 mm
• 30548 STAR AUTOCLAVABLE HANDLE - 30 times
Same as code 30554 but autoclavable up to 30 times (electrode is
autoclavable up to 20 times).
For electrodes Ø 2.4 mm
• 30539 ORION PLUS AUTOCLAVABLE HANDLE - 100 times
Same as 30554, but with a screw clamp locking system ensuring a
safe contact and adapting to different electrode diameters. High
insulation to prevent liquid damage.
For electrodes Ø 2.4 mm
• 30551 KIRKY SINGLE-USE HANDLE - STERILE
Single-use handle
with “click” push-buttons
for cut and coag.
Includes blade electrode.
minimum order: 10 pcs.
• 30553 GIMA SINGLE-USE HANDLE - STERILE
Same as 30551
minimum order: 10 pcs.
1 pin plug HANDLES for diatermo 50, 80, 106, 108
These handles are provided with a 1 Pin socket (4 mm) fitting all
Gima Diatermo and most of electrosurgical units in the market.
These handles
do not have push-buttons.
• 30519 AUTOCLAVABLE 50-80-106-108 HANDLE
Autoclavable handle
without buttons
, provided with
a 3 meter long cable and a blade electrode.
It can be autoclaved up to 50 times.
• 30518 KIRKY SINGLE-USE 50-80-106-108 HANDLE - STERILE
Single-use handle without button with blade electrode
with 4 mm PIN connection.
minimum order: 10 pcs.
MICROSURGERY
Microsurgery accessories for all GIMA Diatermo and electro-depilators
• 30552 MICROSURGERY HANDLE
• 30560 MICROSURGERY NEEDLE
ELECTRODE BRUSH
• 30537 ELECTRODE BRUSH - 50x50 mm
Disposable sterile radiopaque abrasive tip cleaner pad. Box of 100
MONOPOLAR HANDLES FOR ELECTRODES WITH Ø 2.4 mm
30552
30537
“MB HANDLES”
“106 HANDLES”
30554
(autoclavable up to 100 times)
30539 screw type
30550
(autoclavable up to 100 times)
(autoclavable up to 60 times)
30548
(autoclavable up to 30 times)
30551
(single use)
30519
(autoclavable)
30518
(single use)
1 pin (Ø 4mm)
plug for above handles
Tripolar universal Valleylab
type connector
for all above handles
30553
(single use)
0120
0086
0086
30612
30613
30611
30610
tip 2 mm
tip 2 mm
30610
Monopolar cable - 4 mm pin
30611
Mc INDOE straight monopolar forceps 15 cm (6“)
30612
Bayonet monopolar forceps - 20 cm (7 1/2”)
30613
Monopolar scissors - straight - 18 cm (7”)
30614
Metzenbaummonopolar scissors - straight - 18 cm (7”)
30615
Metzenbaum monopolar scissors - curved - 18 cm (7”)
GIMA
code
INSULATED MONOPOLAR INSTRUMENTS
Monopolar forceps are provided
with a 4 mm connection for standard
monopolar cables.
These can be used with all Gima, LED,
Erbe and many other electrosurgical
units in the market.
30614
Metzenbaum
0120
MONOPOLAR FORCEPS, SCISSORS AND CABLES
