ELECTROSURGERY
162
Connector
to forceps
Connector to
electrosurgical unit
4 mm banana plug
GIMA (MB120F/200F/200D/
240/250/300D/380/400/400D)
VALLEY LAB
CONMED, CODMAN
OLYMPUS
GIMA MB122, MB 122 D,
MB132, MB160, MB 160D,
MB200, MB202
30644
30643
30637
30640
30638
US
US
30639
EU
EU
EU
EU
MARTIN
BERTHOLD
AESCULAP
WOLF
ERBE
SELECT
DOWN
SIEMENS
Quality highly flexible silicone
bipolar cables. Autoclavable
at 134°C up to 70 times, 3 m
long (10”). Suitable for most
generators, with connector for
European or US forceps.
• 30642 BIPOLAR
CABLE ADAPTOR
BIPOLAR CABLES FOR MAJOR BRANDS
Connector to EU or US forceps
Compatibility
list for brand and model
• 30450 SMOKE EVACUATOR
An aspiration and filtering system for the smokes produced
during the surgical procedures.
The smokes, generated during the surgical procedures, have
a bad, strong and persistent smell. These smokes consist of
water vapour, organic gas, visible or invisible solid particles
and viral parts. So a good aspiration and filtration eliminates
bad smells, reduce the bacteriological and/or viral risks, and
improves vision of the zone of the operation area during the
laparoscopic procedures.
Activation of the aspiration can be:
-
Automatic
, through the remote electronic system of
automatic survey of the activation of the high frequency
electrosurgical unit
- Manual
-
Through a foot switch (optional)
The aspiration flow can be adjusted to suit the specific needs.
For laparoscopic procedures there is a specific function L,
ELECTROSURGERY SMOKE EVACUATOR
STANDARD ACCESSORIES
ULPA filter (5 hours) blue
Aspiration kit (
Ⓐ
filter +
Ⓑ
pipe Ø 22 mm, length 2.4 m)
4 handle aspiration kit (
Ⓒ
adapter 10 mm / 22 mm
Ⓓ
, pipe Ø 10 mm, length 1.8 m,
Ⓔ
clip to fix the pipe to the handle,
Ⓕ
adapter to the handle)
Power cable
TECHNICAL SPECIFICATIONS
Mains voltage
230 V (115 V on request)
Mains frequency
50/60 Hz
Electrical input power
800 VA
Max vacuum flow rate
1000 LPM (35 CFM)
Max static suction
250 mbar (83 in H
2
O)
Filter type
ULPA with active carbons
Filter efficency
99,999%
Particles diameter
0.12 micron
Size
370x144x319 mm
Weight
4 kg
quickly selectable. Smoke evacuator has an electronic control
of the aspiration with the indication of the wearing status of
the filters. There are two different kinds of quickly replaceable
ULPA type filters, with active carbons: the BLUE filter is the
first filter and it is included with the unit for an initial time
of use (5 hours), the RED filter is an optional spare part,
developed for a long time use (20 hours).
They have connector of 7/8”.
• 30452 ULPA FILTER (20 hours) RED - spare
• 30453 ASPIRATION KIT - box of 6
• 30454 HANDLE ASPIRATION KIT - sterile - box of 12
• 30577 WATERPROOF MB FOOTSWITCH - 2 m
It allows selection from pedal of CUT and COAG functions
Antiexplosion and waterproof.
BIPOLAR CABLE
30577
Waterproof MB footswitch - 2m cable
30578
Waterproof MB footswitch - 3m cable
30602
Double antiexplosion, water proof MB footswitch
30603
Double antiexplosion, water proof footswitch - MB240-380
30604
Double antiexplosion, water proof footswitch - MB250-400-300D-400D
30557
Main board - specify model and serial number of diatermo with order
30558
Output board for MB 240, 250, 380, 400 - specify as above
ANTIEXPLOSION FOOTSWITCHES FORMB 240, 250, 300D, 380, 400, 400D
ANTIEXPLOSION FOOTSWITCH FOR MB 120, 122, 132, 160, 200, 202
MAIN BOARD
FOOTSWITCHES FOR 50, 80, 106, MB 120, 122, 132, 160, 200, 202
GIMA
code
FOOTSWITCHES AND BOARDS
30602-3-4
30577
30454
30453
Aspiration kit
Handle aspiration kit
Power cable
ULPA filter blue
30450
Ⓐ
Ⓕ
Ⓔ
Ⓑ
Ⓓ
Ⓒ
Pin distance 29 cm
30642
