• 30795 FLYER HALOGEN HANDLE 2.5 V
- light source for endoscopes
• 31478 BULB for 30795
• 30794 FLYER LED HANDLE 2.5 V - light source
Powerful handheld light source for
endoscopes 60,000 lux.
Both flyer handles need 2xAAA batteries.
• 71680 TELE-PHARYNGO LARYNGOSCOPE Ø 10x153 mm - 70°
• 71681 PHARYNGO-LARYNGOSCOPE Ø 8x164 mm - 70°
• 71682 PHARYNGO-LARYNGOSCOPE Ø 6x164 mm - 70°
Sharp image, significant depth of field
- high performance illumination, German quality
- two different degrees of magnification:
panoramic view and examination of details (only 71680)
- integrated air channel for prevention of misted objective (only 71680)
- soakable and designed for gas sterilization
- working distance 15 mm to ∞
TECHNICAL SPECIFICATIONS
LED high power lamp 20,000 lux
Color temperature: 5,500 Kelvin
Illumination period: approx. 45 min
Intensity infinitely adjustable
Light guide connection to Storz-adapter thread
Li-Ion, 950 mAh, rechargeable battery
Charging time: approx. 2 hours
TECHNICAL SPECIFICATIONS 71602
Working length: 300 mm Working Ø: 3.2 mm
Tip deflection: up 140°, down 140°
Length of tip deflection: 20 mm
Direction of view: 0°
Field of view: 70°
Depth of focus: 6 mm -
∞
Weight: 260 g
Made in Germany
71602
30801
30830
• 71610 ENDOSCOPY MOUTHPIECE - bag of 20 pcs
Disposable bite blocks
New: 3.2 mm
diameter
adaptor to Gima
light source
GERMAN FLEXIBLE NOSEPHARYNGOSCOPE
RIGID ENDOSCOPES
71621
Otoscope Ø 2.7 x 34 mm - 0° - soakable
71641
Endoscope Ø 2.7 x 110 mm - 0° - autoclavable
71643
Endoscope Ø 2.7 x 110 mm - 30°- autoclavable
71645
Endoscope Ø 2.7 x 110 mm - 70°- autoclavable
70012
Endoscope Ø 2.7 x 187 mm - 0°- autoclavable
70014
Endoscope Ø 2.7 x 187 mm - 30°- autoclavable
70016
Endoscope Ø 2.7 x 187 mm - 70°- autoclavable
71661
Endoscope Ø 4 x 175 mm - 0° - autoclavable
71665
Endoscope Ø 4 x 175 mm - 30° - autoclavable
71668
Endoscope Ø 4 x 175 mm - 45° - autoclavable
71667
Endoscope Ø 4 x 175 mm - 70° - autoclavable
GIMA
code
• 72515 VIDEO BRONCHOSCOPE
The LUT video bronchoscope includes
all standard features such as 2-way tip
deflection, working channel and suction valve.
Incorporates two innovations:
- CHOS Chip-in-the-Tip Video Technology
which delivers a full format Image
- a revolutionary integrated
DeepVu LED
Illumination System
which produces a new
dimension of illumination strength.
• 28243 SUPER VEGA BATTERY
(see page 134)
71680
PHARYNGO-LARYNGOSCOPES -
MADE IN GERMANY
Rigid case supplied
with code 71602
71610
• 71602 LUT FLEXIBLE NOSEPHARYNGOSCOPE with cable
It includes fibre optic cable and rigid case for transport,conventional image
guide system, 2 way deflection, one hand operation,
completely soakable. Resolution: 7,000 pixels.
71681
71621
0°
71645
Pharyngo-laryngoscopes and endoscopes can use as illumination system flyer handles (direct con-
nection) see below or light sources. For use with Gima light sources (30801-2) you need F.O. cable
(30818-30826) adaptor cable to light source (30830) adaptor pharyngo-laryngo to cable (30840).
Rigid endoscope
LIGHT SOURCES HANDLES
VIDEO BRONCHOSCOPE
LUT RIGID ENDOSCOPES MADE IN GERMANY
To be used for ENT and ARTHROSCOPY applications
STANDARD ACCESSORIES
Video Bronchoscope VB100
Controller EC100 (plug and play)
Biopsy forceps with thorn
Biopsy forcepts without thorn
Bite block
Cleaning brushes
Leakage tester
Video connection cables
Carrying case
TECHNICAL SPECIFICATIONS
Image sensor: 1/18“ CMOS
Image resolution: 82.000 pixel
Distal and outer Ø: 5.9 mm
Deflection: up 210°
down 130°
Working length: 600 mm
Working channel: 2,2 mm
Direction of view: 0°
Field of view: 120°
MEDICAL CERTIFIED CAMERA
• 72509 COMPACT PAL CAMERA
C1, + smartbox - SVHS
• 72511 DIGITAL COMPACT
PAL CAMERA C1, Anti-Moiree,
+ smartbox - CVBS/USB 2.0
Camera electronics integrated
in camera head, small
smartbox as connection unit.
Camera head with two buttons:
white balance and window
function. Made in Germany.
• 72708 SONY LMD - LCD
MONITOR 15" - 1.280x768 dots
TECHNICAL SPECIFICATIONS
72511
Smartbox
Digital camera
with anti-
Moiree filter
Outputs: 1x S-Video (Y/C),
1x Video (CVBS)
1x USB 2.0 (only for 72511)
Image sensor: 1/3" CCD
Image resolution: 470x420 (PAL)
Endocoupler: f=23
Norms: 93/42 EWG Class 1,
EN 60601-1; BF/CE mark
Power: 100-250 VAC, 50/60 Hz, 2 VA
Sizes:
Smartbox: 80x34x170 mm
Camera head: 135x Ø 50 mm
Camera cable: 3m
Size 89x24
Weight: 90g
71621+30795
71690
• 71690 LUT LED LIGHT SOURCES
Ultra-bright LED light source. Highest light efficiency by
optimized light coupling to endoscope. Adjustable intensity,
roll-off protection, small, handy, for all LUT endoscopes.
Supplied with battery and charger. Made in Germany, LUT.
