30840
• 30801 GIMA LIGHT SOURCE 150 Watt
Compact, lightweight, powerful light source for endoscopic
use. Equipped with a 150 watt halogen bulb.
It has a small opening on the upper side for easy and quick
replacement. A low noise fan positioned behind the halogen
bulb provides the necessary cooling inside the metallic
structure of the light source. A variable-intensity regulator
enables selection 50 to 150 W. User manual in English, Spanish,
French, Italian, Greek, Portuguese.
• 30802 GIMA DOUBLE LIGHT SOURCE
150 Watt x 2
Similar to 30801, but with 2
independent bulbs, to illuminate at
the same time 2 instruments or to
quickly change if one bulb burns out.
30801
Thanks to connectors it can be used
with STORZ, WOLF, OLYMPUS,
PENTAX, FUJI cables
Adjustable intensity knob
Opening for quick bulb
replacement
Low noise fan
• 30817 FIBRE OPTIC CABLE 3.5 x 1,800 mm
• 30818 FIBRE OPTIC CABLE 4.8 x 1,800 mm
• 30822 FIBRE OPTIC CABLE 3.5 x 2,300 mm
• 30823 FIBRE OPTIC CABLE 4.8 x 2,300 mm
• 30826 FIBRE OPTIC CABLE 4.8 x 3,000 mm
High transmission surgical light cables, armoured but highly
flexible with unique features:
- no burn outs
- strain relieved and protected by
silicone hose
- steam autoclavable
with warranty (12 months)
- light source end temperature resistant up to 300°C
- kink resistant
- no electrical interferences with endoscopic surgery units
- surgical stainless steel end fittings resist
wear and corrosion
- stainless steel adaptors enables our cables
to be used with other manufacturers
halogen light sources/instruments
• 29975 FIBRE OPTIC CLAMP
ENDOSCOPE ADAPTORS - on the endoscope
to connect endoscopes to GIMA F.O. cables
• 30844 STORZ/LUT ENDOSCOPE ADAPTORS
• 30845 WOLF ENDOSCOPE ADAPTORS
LIGHT SOURCE ADAPTORS
to connect GIMA F.O. cables to light sources
• 30830 GIMA light source adaptor
• 30831 STORZ - AESCULAP-
MARTIN light source adaptor
• 30832 WOLF - HENKE SASS - DYONICS -
MEDICON - COMEG
light source adaptor
• 30833 OLYMPUS light source ad.
• 30834 ACMI light source adaptor
• 30835 HEINE light source adaptor
• 30836 FUJINON light source adaptor
• 30837 PENTAX light source adaptor
Autoclavable silicone cable
Endoscope adaptors
(on the cable)
Light source adaptors
Endoscopes Adaptors
Olympus fitting
Wolf fitting
code 30845
Storz/Lut fitting
code 30844
on the endoscope
30810
STORZ cable connector
30811
WOLF cable connector
30812
OLYMPUS cable connector
30815
PENTAX cable connector
30816
FUJINON cable connector
30808
Spare lamp for GIMA
light source
• 30850 WIDA FIBRE OPTIC HEAD LIGHT
• 30854 WIDA PLUS FIBRE OPTIC HEAD LIGHT
fibre optic cable complete with head light system
WIDA illumination systems are available in two versions: one
with simple headband and standard illumination head, the other
with professional headband, easily adjustable, and thin head.
Both include F.O. cable with adaptor for connection to GIMA
light sources (30801-30802).
Here below are available connectors
to other light sources.
Light beam can be focused through
a focusing ring.
• 30852 FOCUS DEVICE for 30850
(since lot 14 - may 2012)
It reduces light in a very luminous
spot Ø 10 mm.
DISTANCE
20 cm
30 cm
50 cm
30850
7-15 cm
10-22 cm
16-35 cm
30854
6-10 cm
9-15 cm
14-20 cm
Diameter focus:
Headband is padded and
fully adjustable in
circumference and height.
3.5mm fibre bundle cable
length 2.3 meter
An exceptionally bright
headlight with an
illumination head for
coaxial, shadow-free
illumination of the
viewing area.
lllumination axis
adjustable over
a wide range
30850
Thin
illumination head
30854
Professional and comfortable
headband easily adjustable in
circumference and height
through two knobs
150 W HALOGEN
LIGHTSOURCES
GIMA
code
CONNECTORS FOR GIMA
LIGHT SOURCE TO
DIFFERENT CABLES
TECHNICAL SPECIFICATIONS
Input for GIMA, SCHOLLY and
LUT cables
Dimension:21x20x h 11 cm /
29x20.7x h 13.5 cm
Max power absoption: 170 Watt /
340 Watt
Two protection fuses: 1.6 A.T.
Power supply: 230V-50 Hz
Norms: IEC 601-1 - 93/42/EEC
(Class: I - Type: BF)
Made in Italy: GIMA S.p.a.
SURGICAL FIBRE OPTIC LIGHT CABLES AND ADAPTORS
Knob for easy
adjustment
1
1
3
3
2
2
29975
30818
or other
cable
ENDOSCOPE ADAPTORS - on the cables
to connect endoscopes to GIMA F.O. cables
• 30840 ENDO STORZ adaptor
• 30841 ENDO WOLF adaptor
• 30842 ENDO ACM,
OLYMPUS-STRYKER adaptor
F. O. HEAD LIGHTS
