AUDIOMETRY & SPIROMETRY
228
ULTRASONIC, DISINFECTABLE SPIROMETERS
• 33682 OTTHON SPIROMETER US (English) + SOFTWARE
• 33683 OTTHON SPIROMETER IT + SOFTWARE
• 33684 OTTHON SPIROMETER OTHER LANGUAGES + SOFTWARE
Pulmonary function diagnostics and monitoring spirometer
for use by general pratictioners, respiratory physicians and
patients. Compact, mobile, affordable solution for screening
COPD (Cronic Obstructive Pulmonary Disease) and asthma.
- automated diagnostic interpretation
- voice and video explain use of device and communicate results
- battery or USB charger
- touchscreen, bright colour high resolution LCD display QVGA
(320x240 px), 16 M colours
- external printer connectivity
- automatic internal calibration
- flow tube disinfectable by cold sterilization
- power supply: USB 5 V or built in rechargeable battery
Internal software languages: GB, FR, IT, DE, ES, HU.
Voice languages available: US (English), AU, FR, IT, DE, ES, AT, HU.
Please indicate requested language with order.
Made in Europe.
• 33686 SPIROTUBE MOBILE EDITION BLUETOOTH SPIROMETER
Pulmonary function diagnostics and monitoring spirometer
with Bluetooth communication interface and built in
rechargeable battery. Suitable for screening COPD and asthma.
- wireless connection to mobile phones, PDAs, android systems.
Real-time measurement with FVC curve visible on the mobile
screen
- plug & play USB connection to PC
- automatic internal calibration
- tele-medical connection via Bluetooth
- automated medical interpretation
- long-term monitoring for home care use
- pharmaceutical testing subsystem
- flow tube disinfectable by cold sterilization
- software can be downloaded free
from Google Play Store
Made in Europe.
THORSOFT - PULMONARY DIAGNOSTIC PC SOFTWARE
Standard medical interfaces (HL7, GDT, BDT, XML).
Automatic interpretation module.
Diagnostic decision support system (for general
practitioners and physicians)
Complete stress testing procedure
Languages: GB, IT, DE, ES, SE, TR, RO, HU, SL.
REGISTRATIONS
All spirometers are CE marked and registred in Indonesia,
Hong Kong, Australia, New Zeland, Korea, Argentine.
• 33688 SPIROTUBE PC SPIROMETER + SOFTWARE
PC based pulmonary function diagnostics and monitoring
spirometer with ultrasonic Idegen
™
respiratory sensor.
Suitable for screening COPD and asthma.
- automatic internal calibration
- tele-medical connection via internet
- plug & play USB PC connection detection
- easy upgrade, standard interfaces, XML, HL7
- long-term monitoring for life-long patient support
- pharmaceutical testing subsystem
- flow tube disinfectable by cold sterilization
Power supply: USB 5 V.
Made in Europe.
STANDARD ACCESSORIES
33682/3/4 33686 33688
Thorsoft software
•
•
Plastic muthpieces
•
•
•
Mini USB cable
•
•
Cups for disinfection
•
•
•
Battery charger
•
•
Bacterial filter
•
•
Carrying bag
•
Paper manual (GB)
•
•
•
CD manual (GB, IT, ES, DE, HU)
•
•
•
TECHNICAL SPECIFICATIONS
Flow measurement principle Idegen
™
multiple-path
Flow tube diameter
30 mm (OD)
Dead space
16.8 ml
Flow resolution
3 ml/s (33686), 8 mb/s (33682-4, 33688)
Flow precision
2% (33686, 33688), 3% (33682-4)
Flow range
±18 l/s
Connection to PC
USB
MEASURED PARAMETERS
FVC, -FEV*0.5, FEV*0.5/IVC, FEV*0.5/FVC,FEV*1.0/IVC, FEV*1.0/FVC, PEF,
FEF*25-75%, MEF*75%,MEF*50%, MEF*25%, FET, MTT, FIVC, FIV*0.5,
FEV1/FVC (Tiffeneau index) FIV*1.0, PIF, FIF*25-75%, IRV. ERV, TV, Breath rate value
- Insp./Expi ratio:
From 1:10 to 10:1
GIMA
code
ACCESSORIES
Minimum
order
33690
Instrumed disinfectant concentrate 1 l
(Bactericidal, fungidal, virucidal,
sporocidal , tubercolocidal)
33691
Plastic mouthpieces
box of 10
33890
Disposable mouthpieces
box of 100
33692
Loki Green single use bacterial filter
box of 50
33505
Calibration syringe 3 l
Size: 35x120x120 mm
Weight: 300 g
Size: 40x60x150 mm
Weight: 300 g
Size: 27x60x150 mm
Weight: 300 g
Spirotube mobile edition
connects to Android
based systems turning
these devices into
respiratory diagnostic
stations
33686
33688
33682/3/4
0120
0120
0120
