STERILIZATION
301
Precision cleaning power
Ultrasonic cleaning is faster and safer than any other method.
It's powerful enough to remove heavy oils and waxes,
penetrating enough to deflux circuit boards, yet gentle
enough to clean tiny precision assemblies.
Ultrasonic sound waves moving through a cleaning solution
create an effect called cavitation, the rapid formation and
implosion of microscopic bubbles. Heat enhances the process.
The deep-cleaning action of ultrasonics removes even the most
stubborn dirt and contaminations.
Branson: pioneer in ultrasonic cleaning
We have selected Branson because their cleaners incorporate
years of experience in ultrasonic cleaning:
- easy to handle and safe to fill
- frequency higher than average for a deep cleaning
- less noise - longer lifetime.
All Branson cleaners are supplied with tank cover, and multi-
language manual (GB, FR, IT, ES, DE, PT, SE, NL, RU).
Recommended use with optional perforated tray.
BRANSON ULTRASONIC CLEANERS
Temperature can
be set for either
Fahrenheit or Celsius
up to 69 °C/156.2 °F
Degassing periods of up to 99
minutes also allow for various
sample prep applications.
High/low power control
provides safer cleaning of
delicate components. 100%
power for normal or 70% for
delicate applications
4 SIZES: 2.8, 5.7, 9.5, 20.8 LITRES.
3 MODELS: MECHANICAL,
MECHANICAL + HEATER,
DIGITAL + HEATER
Digital timer allows
for continuous
ultrasonic operation
up to 99 minutes
Ultrasonic power
tracking maintains
steady, consistent
activity in the both
when condition change
CPX series is completely
programmable, so
engineers can choose
temperature, start, and
stop times for “set-it-
and-forget-it“ operation
BRANSON 2800
2.8 litres
BRANSON 3800
5.7 litres
BRANSON 5800
9.5 litres
BRANSON 8800
20.8 litres
ULTRASONIC CLEANERS
M Mechanical timer
35501
35510
35520
35531
MH Mechanical timer with heater
35502
35511
35521
35532
CPXH Digital timer with heater
35503
35512
35522
35533
ACCESSORIES
Branson 2800
Branson 3800
Branson 5800
Branson 8800
Tank cover, plastic
*
or stainless steel
**
35507
*
35517
*
35527
*
35537
**
Perforated tray
35508
35518
35528
35538
Tray
35505
35515
35525
35535
Beaker positioning cover
35506
2x 250 ml
35516
3x 250 ml
-
-
Beaker positioning cover 600 ml
35509
2x 600ml
35519
2x 600ml
35529
4x 600ml
35539
6x 600ml
Glass beaker 250 ml
35540
35540
-
-
Glass beaker 600 ml
35541
35541
35541
35541
Feature
M Series MH Series CPXH Series
Mechanical Mechanical
Digital
Timer
60 minutes 60 minutes
60 minutes
Cover
•
•
•
Continuous mode
•
•
•
Sweep frequency
•
•
•
Heater
•
•
Dual power
•
Power tracking
•
Degas wave modulation
•
°C or °F temp selection
•
Auto ultrasonic activation
•
High-temp alarm
•
Front panel auto
temp calibration
Operating parameters
stored and saved
M Series: M (Mechanical timer) or
MH (Mechanical timer with heater)
Includes 60-minute mechanical timer
and continuous operation with
heating capability (MH only).
CPXH Series (Digital control with heater)
Are the most technologically advanced
ultrasonic cleaners available. With pro-
grammable features, digital opera-
tion with power tracking capabilities
to adjust for light or heavy loads, high/Iow power control and
degassing. The CPXH is the most versatile system available.
35516+35540
35529
35501
35511
35533
35541
35540
35522
•
•
Branson 2800 Branson 3800 Branson 5800 Branson 8800
Tank size: mm
230x140x100 290x150x150 290x240x150 495x290x150
Overall size: mm
337x304x302 397x317x377 397x401x378 596x466x391
Tank capacity: litres (gal) 2.8 (0.75)
5.7 (1.5)
9.5 (2.5)
20.8 (5.5)
Drain and valve kit
No
Included
Included
Included
Weight: kg (lbs)
4.1 (9)
5.4 (12)
6.4 (14)
11.8 (26)
Frequency
40 KHz
40 KHz
40 KHz
40 KHz
Power supply
230-240 V
230-240 V
230-240 V
230-240 V
TECHNICAL SPECIFICATIONS
Perforated
tray
Tray
