STERILIZATION
303
TECHNICAL SPECIFICATIONS
Thermoventilated:
Timer 0-120 minutes that switches off the oven at the end of the planned time
Probe thermometer from 0° to 200°
Probe thermoregulator from 0° to 200°
Safety thermostat
Ventilator for forced ventilation
Double check up light bulb
Digital:
Electronic running C.P.S.
Use modality: continuous (stand by) or timed
Timer from 0 to 250 minutes
Optimum heat distribution
Automatic indication for possible problems of feeding (in case of mains tension
lack, the program will start again from the beginning)
Operating voltage: 230 V - 50/60 Hz (110 V on request with surcharge for 35583-5)
0426
• 35600 TAU STERIL 1.6 - automatic hot air sterilizer
• 35606 TAU STERIL 6 - automatic hot air sterilizer
• 35619 TAU STERIL 18 - automatic hot air sterilizer
TAU sterilizers have been designed to satisfy all daily medical
requirements in the field of sterilization.
Extremely robust, totally automatic, guarantee complete
working safety.
TAU 1.6 and 6
have double wall and inner insulation, outside
is made of stove-enamelled sheet steel, inside of stainless
steel 18/8 (double cover, sterilization chamber and removable
perforated tray).
TAU 18
comes complete with safety fuses, neon warning lights
to control timer and thermostat, power cable, 3 itallumac
treated shelves (375x200 mm), shelf extracting tongs.
35600
35619
TECHNICAL SPECIFICATIONS TAU 1.6
TAU 6
TAU 18
Inside dimensions (mm):
245x115xh 55 385x270xh 90 375x230xh 200
Outside dimensions (mm): 310x180xh 180 495x320xh 220 440x310xh 380
Weight:
5 kg
8 kg
14 kg
Operating voltage:
220 V
220 V
220 V
110V available on request
Power consumption:
250 W
400 W
600 W
Fuses:
3.15 A
Thermostat:
Automatic capillary bulb type with self registration
from 90° to 200°
Timer:
from 0 to 120 minutes
Thermometer:
high precision with capillary bulb
Made in Italy
Front door completely made in
satin stainless steel
Side and
back
in epoxy
powder
painted
TAU STERIL AUTOMATIC DRY HEAT STERILIZERS 1.6, 6,18
LITRES
DIGITAL OR THERMOVENTILATED DRY HEAT STERILIZERS
TITANOX dry heat sterilizers 20, 60, 120 litres.
Inner structure and height adjustable inner shelves completely
made of stainless steel. Door with lock and key.
Thermoventilated unit
: to guarantee the uniformity of the
temperature in the heating room and to allow the circulation
of the air, the device is provided with a ventilation motor that
results always in operation, both during the cycle of heating
and during the pauses of cooling.
Digital unit:
adjustable aeration tunnels, placed on the bottom
of the right side and on the top of the left side for hot air
adjustment and circulation, which is useful for a quick cooling
of the device.
GIMA code
Thermoventilated
GIMA code
Digital
35583
35584
35585
35586
35587
35588
20 l
60 l
120 l
565x350x345
695x475x430
855x560x585
400x220x220
535x365x325
670x430x420
Capacity
Outside
dimensions (mm)
Inside
dimensions (mm)
Outer case and front completely
made of stainless steel, included the drummed
door strongly insulated with non-conducting material
Outer case made of steel, hinged door completely made of stainless steel
Supplied with manual in: GB, FR, IT, ES and 2 height adjustable
trays. Made in Italy.
35586
35586
35584
Shining 18/8 stainless steel non corrosive, almost
indestructible sterilization chamber which reflects the
heat to reach rapidly desired temperature.
