STERILIZATION
302
FREE AND BASIC ULTRASONIC CLEANERS
GENERAL PURPOSE CLEANER
• 35640 GIMA QUICK - hot bead sterilizer
• 35642 GIMA QUICK PLUS with thermometer
GIMA QUICK hot bead sterilizer has been designed and
developed specifically for medical use. Also recommended for
dentistry, podology, veterinary, tattoo and beauty studios.
It ensures a quick and effective sterilization.
It sterilizes files and mirrors in 2 minutes, surgical instruments
in 2 minutes, curettes and forceps in 3 minutes.
Its constant temperature over 230°C ensures the total
destruction of micro-organisms and spores in few seconds.
GIMA QUICK has epoxydic powders painted steel casing; the
inside cylinder is completely isolated by fibres and glass, which
prevents heat from being transmitted to the external casing.
It can work continuously for the whole day.
Supplied with a pack of glass beads (220 g).
Made in Italy.
• 35645 PYREX BASIN
• 35646
PACK OF GLASS BEADS
0425
• 35549 GIMA 50 ULTRASONIC CLEANER 0.6 l
This ultra-compact cleaner is very easy to use, efficient
and economic. Ideal to clean small objects. Electronic, non
adjustable timer with plastic cover and basket. No heating.
Internal size: 168x89x55 mm.
Supersonic wave 46,000 cycles per second.
CHEMICAL SPECIFICATIONS
Concentration: 10-12%
Biodegradability: yes
Phosphate free
Concentration PH: 13.5
Rinsability: good
• 35544 BRANSON GENERAL PURPOSE
CLEANER - bottle 1 l concentrate
BRANSON PURPOSE is a cleaning solution
developed for use with ultrasonic cleaners.
Removes general soils, fingerprints, dust,
light oils and greases.
Branson cleaning liquid has been specially
developed to provide optimal transfer of
acoustic energy.
Mainly used in: dentistry, medical and
optical applications, laboratory, electronics,
gold and silver works.
ULTRASONIC CLEANERS
The ultrasonic tub is designed to wash instruments used in the
medical, dental, cosmetic, veterinary fields. The ultrasound
cleaning (cavitation) allows to thoroughly clean instruments
difficult to clean manually.
Heating - FREE only
The device heats the detergent and stops automatically when
the preset temperature is reached.
Degassing (degas) - FREE and BASIC
This process reduces the gas dissolved in the liquid, thus
improving the efficiency of the subsequent washing.
Ultrasonic cleaning - FREE and BASIC
Washing phase through ultrasonic cavitation.
Sweep - FREE and BASIC
Ultrasounds are modulated in frequency, thus reducing
the negative effects of stationary waves, increasing the
distribution of ultrasonic energy within the washing liquid.
Discharge - FREE only
Tub of Basic has to be manually emptied, tub of Free can be
emptied by opening the appropriate valve.
All ultrasonic cleaners are supplied with basket and lid.
TECHNICAL SPECIFICATIONS
Outer structure in white painted steel
Size: 130x130x190 mm
Copper plated basket: diameter 5.5 cm
depth 7.5 cm
Weight: 2.8 kg
Power consumption: 150 W
Operating voltage: 220 V - 50 Hz.
Warranty: 12 months
Made in Italy
35640
35642
GIMA QUICK: STERILIZATION IN 2 MINUTES
ULTRASONIC CLEANERS
BASIC FREE
BASIC FREE
3 l
3 l
9 l
9 l
Tank size mm
235x100x135
332x120x227
Overall size mm
315x248x168
438x268x259
Weight kg
3.7
4
7.1
7.4
Ultrasonic power W
150
150
300
300
FREE AND BASIC ULTRASONIC CLEANERS
Basic ultrasonic cleaner 3 l
Free ultrasonic cleaner 3 l - with heating and discharge
Basic ultrasonic cleaner 9 l
Free ultrasonic cleaner 9 l - with heating and discharge
GIMA
code
35550
35551
35552
35553
35553
35550
ULTRASONIC CLEANER
