ELECTROMEDICAL DEVICES
134
28206
0123
30 l/min.
Cable to
recharge batteries from car
Cable to recharge battery
from power supply
Disposable suction
liner
Autoclavable jar
Aspirator
Carryng bag
28259 28258
• 28206 MINI ASPEED BATTERY PRO - metal case - 30 l/min
High vacuum portable medical device for professional surgical
aspiration.
- it can operate at 12 V (car.) power supply, rechargeable
batteries or directly by mains supply
- its two cylinders electro-compressor ensures high
performances and long life
- up to 45 min. of autonomy with fully charged battery
- with 99% antibacterial hydrophobic filter
- equipped with autoclavable jar with safety valve, disposable
suction liner and carryng case.
• 25480 SILICONE TUBE 6x12 mm - roll of 30 m
• 28254 ADAPTOR FOR CATHETER
• 28255 HYDROPHOBIC 99% BACTERIAL FILTER
• 28258 AUTOCLAVABLE JAR 1000 ml (with cover)
• 28259 DISPOSABLE SUCTION LINER
TECHNICAL SPECIFICATIONS SUPER VEGA
Operating Voltage: 220-230 V - 50/60 Hz AC - 12 V DC (28243)
100-240 V - 50/60 Hz (28190)
Size: 350x210x180 mm Weight: 4.9 kg
Max suction -0.75 bar (563 mm/Hg)
Suction power: 16 air litres/min (28243), 36 air litres/min (28190)
Norms: IEC 601-1 - Class II Type B. Made in Italy
TECHNICAL SPECIFICATIONS MINI ASPEED
Operating Voltage: 100-240 V 50/60 Hz AC - 14 V DC 4.28 A
Size: 370x100x240 mm Weight: 5.8 kg (include kit)
Max suction: - 0.85 bar
Suction power: 30 air litres/min.
Sound level: 65 db
Norms: MDD 93/42/ECC (class IIa - annex IX)
IEC 60601-1, UNI ENISO 10079-1 Made in Italy
1 l jar with overflow safety valve
STANDARD ACCESSORIES
Autoclavable jar 1000 cc
with safety valve
Silicone tubing set Ø 6x12 mm
Disposable suction liner
Sterile cannula
Anti-bacterial hydrophobic filter
Multivoltage battery charger
Cigarette lighter power cord.
Shoulder carrying bag
User manual (English and Italian)
Disposable suction
liner inside
autoclavable jar
0476
28190
28243
• 28243 SUPER VEGA BATTERY - plastic case - 16 l/min.
• 28190 SUPER VEGA BATTERY - plastic case - 36 l/min.
• 28213 TROLLEY FOR SUPER VEGA
• 28242 BATTERY FOR SUPER VEGA/TOBI (28243/28240) - spare
• 28251 BATTERY FOR SUPER VEGA (28190) - spare
With incorporated rechargeable batteries.
It can operate at 12 V power supply at
rechargeable batteries and, thanks
to an electronic system, at 230 V while
recharging batteries.
Autonomy: approx 45-50 minutes.
Recharging time: 120-150 minutes.
Max suction: -75 bar.
Suction power: 16 or 36 air litres/min
It has unbreakable 1,000 ml standard bottle
(2,000 ml optional) autoclavable at 120°C with
safety float control valve to prevent overflow.
BATTERY SUCTION ASPIRATORS
36 l/min.
28258 +
28259
2 l jar
TECHNICAL SPECIFICATIONS
Size: 32x30x90 h cm Weight 6.2 kg
Operating voltage: 220-230 V - 50/60 Hz; other on request
Power consumption: 110 VA
Maximum suction: -0.80 bar (600 mm Hg)
Flow: 40 air litres/minute
Temporary use: 120 on - 60 off
Norms CEI 62-5 (IEC 601-1) - 93/42 EEC
User manual (English, French, German, Italian, Spanish)
Made in Italy
Vacuum indicator
Max suction:
600 mm Hg - 0.80 bar
Silicone tubing
8x14 mm
Adjustable
suction knob
Fixed height
75 cm
SUPERVEGA SUCTION ASPIRATOR ON TROLLEY
• 28191 SUPER VEGA on trolley - suction 2x2 l jar
• 28192 SUPER VEGA on trolley - suction 2x2 l jar with footswitch
Continuously adjustable vacuum, with indicator.
Silicone connection tube. 2 jars 2 litres, made of
sterilizable polycarbonate (autoclavable at 120°C).
Working time: 120 min ON, 60 min. OFF.
Suction power: 40 air litres/min.
Steel painted frame, fitted with 5 star base.
Norms CEI 62-5 (IEC 601-1) - Class II - Type B
• 28239 HYDROPHOBIC 99% BACTERIAL FILTER
• 25482 SILICONE TUBE - 8x14 mm - roll of 30 m
Supervega
on trolley
with
disposable
jars 28272/3
and 28274/5.
See page 99
28191
0476
STANDARD ACCESSORIES
Bottle 1 l - autoclavable at 120°C
Silicone tubing set
Suction catheter
Anti-bacterial filter
Cable to recharge batteries from power supply
Cable to recharge batteries from car
User manual (GB, IT, FR, DE, ES)
