GYNAECOLOGY
140
29624
K061306
TECHNICAL SPECIFICATIONS
Measurement site: Calcaneus (Heel bone)
Scan Time:
15 seconds
Measurement:
Estimated heel BMD and Bone Quality Index (BQI)
Obtained from measured Broad band Ultrasound
Attenuation (BUA) and Speed of Sound (SOS)
Estimated Index:
SOS (C.V.%)
BUA (C.V.%)
BQI (C.V.%)
In Vivo:
0.2
1.5
1.5
Transducer:
25 mm - 100 mm
Separation range:
Automatic adjustment
Storage capacity:
10,000 patient information
Coupling method: coupling gel (water not used)
Display:
6.4 inch TFT LCD (65536 colour)
User Interface:
Touch screen
USB for connection to mouse or keyboard
Printer:
Thermal Printer
Operating voltage: AC 100V~240V - 50/60Hz - 130W
Dimension:
30x62x39 cm
Weight:
12 kg
Total magnification 3.75X, 7.5X, 15X
300mm focal length
Field of View: Ø 79 mm, 39 mm, 19 mm
Depth of Field: 4.5 mm, 1.13 mm,
0.76mm
Light intensity >25,000 LUX
Individually adjustable eyepiece 16.7X
Right eyepiece with built-in two
circles to measure the size of the
problem you see
Built-in rheostat for brightness
adjustment
User-selectable built-in green filter
for enhanced contrast
LED bulb is easily changeable
Working height: 950 mm to 1,250 mm
Fine focus adjustment handles
Two (Gross/Fine) height adjustment
handles
Main power supply: 100 V to 230 V
Colour
touch screen
monitor
Foot
support
Easy to use
Multilanguage
software
(GB, FR, IT,
ES, DE)
No radiation hazard
Integrated printer
Integrated printer
• 33996 SONOST 3000 with integrated software
Waterless Ultrasound Bone Densitometer (BMD).
Sonost 3000 is a portable, economic solution for evaluating the
risk of osteoporotic fracture. Its high accuracy assists in the first
diagnosis of osteoporosis monitoring bone changes.
It provides fast, convenient and easy-to-use informations
on bone quality and fracture risk.
It can be connected to a keyboard to a monitor for data
reading and to an external printer for A4 printing
Main features:
- superior precision
- full dry and stand alone system
- fast measurement (only 15 seconds)
- auto positioning probe
- permanent coupling pad
- over 10,000 memories
• 33250 THERMAL PAPER 57 mm x 25 m (pack of 5 rolls)
SONOST 3000 - ULTRASOUND BONE DENSITOMETER
AC-2311 LED VIDEO COLPOSCOPE WITH CAMERA
• 29624 AC-2311 LED VIDEO COLPOSCOPE WITH CAMERA
- Superb optical features:
The excellent optical design allows:
1 - high resolution
2 - real 3-dimensional precise image reproduction
3 - large depth of field
4 - wide field of view
5 - good contrast
Apochromatic optics design can correct the chromatic
aberration of three types of coloured light effectively.
It ensures the reduction and saturation of image colour and
improves resolution, contrast and view depth of image.
- 3-step magnification:
3-step magnification (3.75X - 7.5X - 15X) provides larger
magnifying range and more selection from lowest
magnification for an overview to high magnification for
precise and close inspection and treatment.
- Two optical circles for quick measuring size or tissue
- Integrated green filter
It can help to recognize blood vessels
- LED illumination
LED coaxial illuminator provides pure white colour light similar
to sunlight to show real colour. Bulb life over 10,000 hours/10
years for long lasting performance. It saves your cost for the
spare bulbs & electric charge.
- Integrated camera
The images from integrated video camera can be transferred
directly into a monitor or a TV, into a computer with USB
adapter or stored into a hard disk recorder.
- Ergonomic design for comfortably long time precision operation
It is supplied completely assembled and ready for use
• 29621 COLPOSCOPY SOFTWARE - see page 139
TECHNICAL SPECIFICATIONS
Compact, light weight base with
3 wheels for easily move.
Colposcope weight only 11 kg.
Fine focus
handle
Fine height
adjustment
handle
Diopters knob
Rheostat knob
Eyecups
LED lamp
cover
Green filter
knob
3 step
magnification
knob
Two circles for
measuring size
of tissue
Locking knob
of head body
