Foetal monitoring:
Ultrasonic probe
Ultrasonic working frequency: 1 MHz tolerance: ±5%
ISATA: ≤10 mW/cm
2
Foetal heart rate measuring range: 65~210 bpm
Accuracy of foetal heart rate: ±2 bpm
FHR alarm: when the FHR value exceeds the preset value, the monitor
will send an alarm for 30 s that will stop by pressing alarm key
TOCO transducer
Zero setting mode: manual
TOCO measuring range: 0%~100% tolerance: ±10%
Marker mode
Mode: Manual and AUTO
ECG/RESP Monitoring:
ECG amplification bandwidth:
Monitoring mode: 1 Hz~25Hz (+0.4 db -3 db)
Diagnostic mode: 1 Hz~75Hz (+0.4 db -3 db)
ECG measuring range: 20~250bpm (±2% or ±2 bpm, whichever is greater)
Common-mode rejection ratio: CMRR≥80 dB
ECG noise level: ≤30 μVP-P
ECG input loop current: ≤0.1 μA
Input impedance: ≥5 MΩ
Time constant:
Monitoring mode: ≥0.3 s
Diagnostic mode: ≥3.2 s
ECG gain:
X1/2 5 mm/mV ±5%
X1 10 mm/mV ±5%
X2 20 mm/mV ±5%
RESP monitoring range: 0~100rpm (±5% or ±2 rpm, whichever is greater)
NIBP Monitoring:
Measuring technology: Automatic measurement by smart oscillating method
Initial cuff inflation pressure: adult mode 180 mmHg
Max. inflation pressure allowed: adult: 300 mmHg
Accuracy: ±10% or ±10mmHg, whichever is greater
Factory-set measuring mode: manual, auto mode
Measuring intervals: 1-240 minutes adjustable, interval tolerance: <10s
Monitoring range: Systolic pressure: 50~240 mmHg
Mean arterial pressure: 25~200 mmHg
Diastolic pressure:15~180 mmHg
Measurement accuracy ±8 mmHg
SpO
2
/Temperature Monitoring:
SpO
2
sensor: dual-wavelength LED
Pulse oxygen saturation range: 0~99%
Accuracy of pulse oxygen saturation: 75~99% ±2%
50~74% ±3%
< 50% not defined
Pulse range: 30 ~ 240 times/minute
Accuracy: ±2% or ±2 bpm, whichever is greater.
Temperature response time: ≤150s
Other Technical Information and Parameters:
Mains power supply: 100~250 VAC, 50/60 Hz
Power consumption: <100 VA
Internal power supply: Li-ion, rechargeable battery
4 hours to full recharge during monitoring
6 hours to full recharge when monitor is off
Display mode: TFT display
Alarm mode: Audible & visible alarm
Networking interface: Net port
Printing paper Z-Fold, 112 mm x 90 mm
Protection against electric shock: Class I
Protection against electric shock: with Type BF, CF applied part
Size: 36x30xh 12 cm
Weight: 4 kg
Built in thermal printer
1/2/3 cm/min real time printing speed, fast print speed (stored traces)
Paper Z-fold, thermosensitive
Record message ID, name, age, date, time, print speed etc.
America standard/international standard
TECHNICAL SPECIFICATIONS
• 29550 PC-8000 PRO SINGLE FOETAL MONITOR
• 29551 PC-8000 PRO TWINS FOETAL MONITOR
Maternal foetal monitor suitable for hospital use.
Main features:
- 12.1” High-brightness TFT display (800x600 pixel)
- parameters: ECG, SpO
2
, NIBP, TEMP, RESP, PR, FHR, TOCO & FM
- rotatable screen viewed from different directions and 5 diffe-
rent styles of operation display
- equipped with reliable, high sensitivity,12-element pulse
doppler transducer
- FHR and TOCO trend review
- store and view of 48-hour monitoring data
- built-in Linux operation system
- built-in high-speed thermal printer
- internal rechargeable Li-ion battery
- visual and audible alarms
- internal software in English
PC-8000 PRO HOSPITAL FOETAL MONITOR
Ultrasonic probe
1
Uterine contraction probe 1
Fetal movement probe 1
Abdominal belt
2
Ultrasonic coupling gel
1
ECG cable
1
Blood pressure cuff
1
Blood oxygen probe
1
Body temperature probe
1
Power cable
1
Grounding wire
1
Disposable electrode
10
User Manual (English, Italian) 1
STANDARD ACCESSORIES
Doppler ultrasound transducer - spare
UC/TOCO transducer - spare
Event marker (foetal movement probe) - spare
Abdominal belt - spare
Z-fold paper 112x100 mm for 29550 - 20 box of 150 sheets
Z-fold paper 150x100 mm for 29551 - 25 box of 150 sheets
3M RED DOT
™
electrodes Ø 6 cm - box of 1,000
29552
29553
29554
29555
29556
29557
33297
GIMA
code
PC 8000 PRO ACCESSORIES
