ELECTROMEDICAL DEVICES
136
STANDARD ACCESSORIES
Autoclavable policarbonate jar 1,000 cc
with safety valve (overflow protection)
Disposable suction liner 1 l
99% Antibacterial hydrophobic filter
Sterile disposable cannula
Sterile manual flow regulator
Set of atoxic sterilizable silicone tubes
Power Cable
User Manual GB, FR, IT, DE, ES
Autoclavable
Jar, h 19.2 cm
Ø 10 cm top,
9.7 cm base
Disposable
suction liner
28258 28259
Double pump type
Vacuum gauge
Overflow
regulation knob
PROFESSIONAL ASPIRATORS
- HIGH VACUUM
ASPEED PROFESSIONAL SURGICAL ASPIRATORS
Piston-type continuous cycle electric aspirators give high
performance and great durability. Equipped with a protective
thermal cut-out relay. They require no maintenance or
lubrication. A motor-protector cap totally prevents aspirated
liquids or secretions from reaching and damaging the vacuum
pump. Ideal for clinical use.
Made in Italy.
STANDARD ACCESSORIES
Bottle 1,000 ml with cover
Antibacterial Filter
Suction catheter
Silicon Tube set
User manual GB, FR, IT, DE, ES
Tobi
1
1
1
1
1
Super Tobi
1
1
1
1
1
Suction power: 30 l/m
Max suction: -0.80 bar
Silicone tube 6x10 mm (see page 131)
28224
28222
Suction power: 18 l/m
Max suction: -0.75 bar
HIGH VACUUM
HIGH FLOW
Adaptor for catheter (code 28252)
SUCTION ASPIRATORS
HIGH VACUUM, LOW AND HIGH FLOW
• 28222 TOBI - suction aspirator
220-230 V - 50/60 Hz
• 28224 SUPER TOBI - suction aspirator
220-230 V - 50/60 Hz
Portable suction aspirators, ideal for
tracheotomy and small surgery.
Vacuum continuously adjustable with
vacuum indicator. Have unbreakable 1,000 ml
standard bottle (2,000 ml optional) autoclavable
at 120°C with safety float control valve
to prevent overflow.
Silicone connection tube.
ABS plastic case.
Made in Italy
0476
28222 Tobi
220-230 V - 50/60 Hz
184 W
1,000 ml
18 l/min
-0.75 bar (563mm/Hg)
20 ON / 40 OFF
37x22xh 21 cm
3.5 kg
IEC 601-1
28224Super Tobi
220-230 V - 50/60 Hz
106 W
1,000 ml
40 l/min
-0.80 bar (600mm/Hg)
120 ON / 60 OFF
37x22xh 21 cm
5.25 kg
IEC 601-1
TECHNICAL SPECIFICATIONS
Operating voltage:
Power consumption:
Bottle capacity:
Flow (air litres/min):
Max suction:
Working time: minutes
Size (cm):
Weight:
Norms:
Anti-bacterial filter
EN ISO 10079-1
Class I
Type B
0434
1 l Autoclavable Jar
Aspeed 15 l
230 V
single
metal
Aspeed 22 l
230 V double metal
Aspeed 22 l
110 V double metal
Aspeed 2 15 l
230 V
single plastic
Aspeed 2 22 l
230 V double plastic
28244
28245
28246
28280
28281
GIMA
code
ASPEED ASPIRATORS
Hydrophobic 99% bacterial filter
Autoclavable jar 1l with cover - since 2007
Disposable suction liner
Silicone tube 6x12 mm - roll of 30 m
Adaptor to connect catheter to silicone tube
Adaptor kit to use jar 1l (28258)
with ASPEED manufactured before 2007
28255
28258
28259
25480
28254
28261
GIMA
code
ACCESSORIES AND SPARES FOR ASPEED
28244-6
Power
Pump
Case
28280-1
TECHNICAL SPECIFICATIONS
ASPEED
ASPEED 2
28244 28245/6
*
28280 28281
Operating voltage:
230 V-50 Hz
230V - 50/60Hz
*
110-60 Hz other voltage on request
Bottle capacity:
1 l
1 l
1 l
1 l
High vacuum:
low flow low flow low flow high flow
Air flow:
15 l/min 22 l/min 15 l/min 22 l/min
Adjustable vacuum level:
0÷ -0.85 bar (0÷ -85 kPa)
Weight:
3.5 kg 4.5 kg
2.5 kg 3.2 kg
Case material:
metal
plastic
Noise level:
55 dBA 65 dBA 55 dBA 55 dBA
