ELECTROMEDICAL DEVICES
135
1 l policarbonate
autoclavable jar
with overflow
safety valve
28209
TECHNICAL SPECIFICATIONS
28209 VEGA UNO
28210 VEGA
28211 SUPERVEGA
Operating Voltage: 220-230 V - 50/60 Hz
220-230 V - 50/60 Hz
220-230 V - 50/60 Hz
110 V - 60 Hz (on request) 110 V - 60 Hz (on request) or 110 V - 60 Hz
Power consumption: 184 W
184 W
106 W
Bottle capacity:
1,000 ml
1,000 ml
1,000 ml or 2,000 ml
Flow (air litres/min): 15 l/min
16 l/min
40 l/min
Max suction:
-0.75 bar (563 mm/Hg)
-0.75 bar (563mm/Hg)
-0.80 bar (600mm/Hg)
Temporary use:
20/40 min on/off
30/30 min on/off
120/60 min on/off
Size:
25x19x16.5 cm
35x21x18 cm
35x21x18 cm
Weight:
2.2 kg
2.5 kg
3.6 kg
Norms:
93/42/ECC
93/42/ECC
93/42/ECC
Origin:
Italy
Italy
Italy
VEGA SUCTION UNITS,
HIGH VACUUM, LOW AND HIGH FLOW
0476
HIGH VACUUM
HIGH FLOW
STANDARD ACCESSORIES
Autoclavable jar (1 or 2 l) with overflow valve system
Antibacterial and hydrophobic filter
Set of silicone tubes 6x10 mm
Conical connector for probes
5 languages user manual (GB, FR, IT, DE, ES)
GIMA
code
VEGA SUCTION ASPIRATOR
28209
Vega Uno
220-230 V - 50/60 Hz 15 l/m
28210
Vega
220-230 V - 50/60 Hz 16 l/m
28211
Super Vega 1l
220-230 V - 50/60 Hz 40 l/m
28212
Super Vega 2l
220-230 V - 50/60 Hz 40 l/m
28189
Super Vega 1l
110 V - 60 Hz
40 l/m
Operating
power
Flow
GIMA
code
SPARE ACCESSORIES FOR VEGA AND TOBI LINE
• VEGA SUCTION UNITS
A line of stylish, compact and reliable
aspirators for small surgery. Silent, high flow
and maintenance - free pumps allow long
product life and durability.
Recommended for nasal aspiration, oral
aspiration, tracheal aspiration of body liquids
(mucus, catarrh or blood) in adults or children.
Equipped with vacuum regulator continuously
adjustable, vacuum indicator, unbreakable
1,000 ml or 2,000 ml bottle, autoclavable
at 121°C, with safety float control valve to
prevent overflow. Optional bottle autoclavable
at 134°C. Manufactured in electric and thermal
insulated plastic body.
Autoclavable and disposable collection
system:
In addition to standard autoclavable
jar is available a disposable collection system
composed by a rigid reusable container
and a polyethylene disposable liner with
cover, hermetically sealed, and hydrophobic,
antireflux, bacterial filter operating as an
overflow valve.
28210
28211
28229
28252
Adaptor to
connect
catheter
to silicone
tube
28229
Hydrophobic, 99% antibacterial filter
28226
121°C autoclavable jar 1 l with cover and overflow system
28236
121°C autoclavable jar 2 l with cover and overflow system
28227
Cover and overflow valve system for 28226 and 28236
28185
134°C autoclavable jar 1 l with cover and overflow system
28186
134°C autoclavable jar 2 l with cover and overflow system
28271
Disposable liner 1 l (cover+bag)
28270
Container for disposable liner 1 l
28273
Disposable liner 2 l (cover + bag)
28272
Container for disposable liner 2 l Ø 13 cm top, 9.5 cm bottom
25468
Silicone tube 6x10 mm - roll of 30 m
28252
Adaptor to connect catheter to silicone tube
Suction catheter - see at page 133
28213
Trolley for Vega and Super Vega (not for Vega Uno)
28276
Vacuum indicator for Vega and Super Vega (not for Vega Uno)
28211
+
28213
28272
28270
+
28271
28273
28273
+
28272
28236
28226
28227
