GYNAECOLOGY
143
SONOTRAX DOPPLERS
29502
29493
29503
• 29503 GIMA FOETAL DOPPLER D2003 with display
Pocket foetal doppler with same specification as code 29502 but
with built-in foetal heart rate processing. Foetal heart rate (FHR)
is displayed on a large LCD display whilst internal signal process
minimises noise artefacts.
• 29505 GIMA FOETAL DOPPLER D2005 with display and water-
proof probe
Same as code 29503 but
waterproof probe and sealed
electronics.
All units are supplied in a nice
bag with a tube of coupling gel
and user manual in English,
Spanish, French, German,
Italian, Greek, Portuguese.
• 29512 ON/OFF MEMBRANE SWITCH for codes 29503, 29505
Volume control
Easy to clean
unit probe
Lightweight:
only 350 g
Foetal heart rate display
Foetal pulse icone
0120
0123
TECHNICAL SPECIFICATION (CODES 29502 - 29503 - 29505)
Ultrasound
Frequency: 2 MHz continuous wave
Transducer: 2 crystal narrow beam
Output power: <10mW/mm
2
SATA
Audio Response 300Hz -1 KHz
autocorrelator (only code 29503 and 29505)
FHR (Fetal heart rate): 50-210 bpm (25903, 29505) 60-210 bpm (29502)
resolution ± 1 bpm, accuracy ± 2 bpm
Unit Controls Keys: 1 Key (for unit on/off)
Controls: rotary volume
Indicators:
3 digit FHR LCD display (codes 25903, 29505)
FHR pulse icon (codes 25903, 29505), Battery low icon
Power supply Battery 9 V Alkaline Manganese
Expected battery life: 8 hours
Output
Headset: Audio output to optional headset
Serial: RS232 interface (codes 29503, 29505)-jack 35 mm
Material: ABS / Noryl
Size: 150 mm by 75 mm Weight: 295 g (with transducer)
Classification: Class I Type B - IEC 60601-I 0120
Warranty: 2 years (probe and cable included)
Made in UK
• 29502 GIMA FOETAL DOPPLER G2002
Small, lightweight, high sensitivity pocket Doppler, with 2 MHz
foetal probe, ideal for General Practitioner's or Midwife's use for
routine antenatal foetal detection.
Pocket Doppler can be used to detect the beating foetal heart
from about 10th week of gestation. It may be used to locate the
position of the placenta, thus aiding in the early diagnosis of
placenta praevia, to survey blood flow of the umbilical cord and
to diagnose multiple pregnancies. Foetal signals are easily located
using the lightweight narrow beam transducer while internal signal
processing minimizes noise artefacts. Audio foetal heart signals are
available to the user via the built-in loudspeaker or option headset,
with output level controlled by rotary volume control.
• 29511 ON/OFF MEMBRANE SWITCH for code 29502
Headset connector
FHR 50-210 bpm
GIMA FOETAL POCKET DOPPLERS - MADE IN U.K.
BABYSOUNDGIMADOPPLER
• 29506 BABY SOUND GIMA FO-
ETAL DOPPLER with display and
interchangeable 1MHz probe
- portable and lightweight
- built-inspeakertohearfetalheartbeats
- numeric and trend curve
display for FHR
- automatic power-off function
- backlight LCD display
- date, time, battery status display
- audible & visual FHR alarm
- 8-hour data storage
- audio-out interface
- fetal monitor DSP technology
- high-sensitivity probe
- 1MHz or 2/2.5working frequency
- store and recall FHR, up to 16
hours of FHR date storage
- recording function
It allows hearing regularly the
heartbeat of a foetus since 20
TECHNICAL SPECIFICATION
Ultrasound working frequency:
1MHz ± 5%
Fetal heart rate:
range:
50-210 bpm
resolution:
1 bpm
accuracy:
± 2 bpm
Alarm:
high limit:
160 bpm
low limit:
120 bpm
Ultrasound intensity:
< 5 mm/cm
2
Dimension:
145x74x29 mm
Weight:
350 g
Power supply:
3 AA Batteries
Large backlight
LCD display
(29493 only)
Up to 4 hours
continuous use
Interchangeable,
water proof
probes
TECHNICAL SPECIFICATIONS
Size: 32x85x138 mm
Weight: 290 g (including battery)
Heart rate range: 50-210 bpm
Resolution: 1 bpm
LCD display: 45x25 mm (only code 29491-93)
Auto average and manual mode
Recording length: 480 s / 240 s
Auto power-off to save power
Manual: GB, IT - on request: DE, ES, FR, PT.
SUPPORT
2MHz, 3MHz, 4MHz, 8 MHz
WATERPROOF PROBES
SOFTWARE TO SAVE
DATA ON PC
GIMA
code
DOPPLERS AND INTERCHANGEABLE PROBES -
LATEX FREE
SONOTRAX LITE DOPPLER - without probe - with bag
SONOTRAX BASIC DOPPLER - with display - without
probe - with carrying bag
SONOTRAX PRO II DOPPLER with backlighted
display built-in audio recorder and rechargeable
batteries with battery charger -
without probe - with carrying bag
2MHz waterproof probe - gynaecology
3MHz waterproof probe - gynaecology
4MHz waterproof probe - vascular
8MHz waterproof probe - vascular
29490
29491
29493
29496
29497
29498
29499
29508
weeks, and warns in case of serious problems of the fetus (can mo-
nitor FHR during 10-12 weeks not regularly). For home and hospi-
tal use. Supplied with gel bottle, 3 AA batteries and user manual.
• 29507 2.0/2.5 MHz DOPPLER PROBE
• 29508 1 MHz FOETAL MONITOR PROBE
The Fetal Doppler can be used as a portable Fetal Monitor if it
works with 1MHz Fetal Monitor probe. It is suitable
for long-term monitoring and will be more
accurate than with the Doppler probe.
29496
29499
