ELECTROMEDICAL DEVICES
137
MAXI ASPEED HIGH FLOW ASPIRATOR FOR HOSPITAL USE
HIGH VACUUM, HIGH FLOWHOSPITAL SUCTION ASPIRATOR
GIMA
code
CLINIC PLUS /
HOSPI PLUS
28194
CLINIC PLUS aspirator 2x2 l 220-230 V
-
-
28196
CLINIC PLUS aspirator 2x4 l 220-230 V
-
-
28198
CLINIC PLUS aspirator 2x4 l 220-230 V yes
yes
28200
HOSPI PLUS aspirator 2x2 l 220-230 V
-
-
28199
HOSPI PLUS aspirator 2x2 l 110 V
-
-
28201
HOSPI PLUS aspirator 2x4 l 220-230 V
-
-
28203
HOSPI PLUS aspirator 2x2 l 220-230 V yes
yes
28204
HOSPI PLUS aspirator 2x4 l 220-230 V yes
yes
Jar
Power
Foot
switch
Flow
direction
regulator
TECHNICAL SPECIFICATIONS
Operating voltage:
Maximum suction:
Flow:
Power:
Norms:
TECHNICAL SPECIFICATIONS
Operating voltage:
230 V - 50/60 Hz. Available on request 110-60 Hz
Air flow:
60 or 90 l/min
Operating cycle:
continuous
Adjustable vacuum level: 0-0.90 bar (0-90 kPa)
Size:
470x580x560 mm
Weight:
15 kg (60 l), 17 kg (90 l)
MDD class:
IIa
Hospi plus
110 V or 230 V - 50/60 Hz
- 0.90 bar (675 mm/Hg)
90 l/min
300 VA
CEI 62-5 (IEC 601-1)
93/42 EEC. Made in Italy
Clinic plus
230 V - 50/60 Hz - 110 V on request
- 0,90 bar (675 mm/Hg)
60 l/min
230 VA
CEI 62-5 (IEC 601-1)
93/42 EEC. Made in Italy
Clinic Plus and Hospi Plus with foot switch and electronic flow direction regulator
New innovative range of high vacuum, high flow aspirator
ideal for hospitals. Pump piston type, lubrication and
maintenance free. Supplied with hydrophobic 99% bacterial
filter, vacuum gauge for control of vacuum and 2 autoclavable
jars (2 or 4 litres) made in makrolon with 200/400 ml
graduation and double security valve. Available on request 2
or 3 litre disposable liners. Range includes version with foot
switch and flow direction regulator, 110 and 230 V.
MAXI ASPEED SURGICAL ASPIRATORS
Surgical aspirators for aspiration of body liquids in operating
theatres and hospitals.
Easy to carry
Equipped with 4 antistatic wheels (2 with brake) and carrying
telescopic handle.
Developed to run continuously
Made in highly heat resistant, electrically insulated plastic
material in conformity with latest European safety standards.
Vacuum regulator with BAR/PSI vacuometer and automatic
flow direction regulator to easily switch from a jar to the
other.
Supplied with 2 autoclavable polycarbonate jars with
safety valve (overflow protection), set of atoxic sterilizable
silicone tubes, 99% antibacterial hydrophobic filters (2) and
multilanguage manual (GB, FR, IT, DE, ES). Made in Italy.
Four antistatic castors, two of which with brake, allow a
perfect mobility. User manual in English, French, German,
Italian, Spanish. See spare accessories at page 133, 138.
Made in Italy.
Size: 460x850x420 mm
Weight: 20 kg
Standard Clinic Plus and Hospi Plus
GIMA
code
Jar
Power
Foot
switch
Flow
direction
regulator
MAXI ASPEED
28285
Maxi Aspeed 60 l
2x2 l 230 V
-
yes
28286
Maxi Aspeed 60 l
2x2 l 230 V
yes
yes
28289
Maxi Aspeed 90 l
2x2 l 230 V
-
yes
28291
Maxi Aspeed 90 l
2x4 l 230 V
-
yes
28292
Maxi Aspeed 90 l
2x4 l 230 V
yes
yes
28294
Autoclavable jar 2 l with safety valve
28295
Autoclavable jar 4 l with safety valve
28297
Hydrophobic 99% antibacterial filter
25482
Silicone tube - 8x14 mm - roll of 30m
ACCESSORIES
Telescopic
handle
0476
