LOUPES, VISION & ENDOSCOPY
166
93/42
• 31130 GIMA 6 AC/DC TRANSFORMER
This is a real transformer for Clar and Storz mirrors, Nystagmus glasses and any
instrument which requires from 1.2V to 10V dc 500 mA power. Made in Italy.
GIMA AC/DC TRANSFORMER
These new generation quality head mirrors Ø 55 or 100 mm
perfectly illuminate the examination area in every situation.
Long life 6V lamp provides bright and natural light, quality
silver coated mirror allows optimum light reflection.
Mirror and light beam can be easily and precisely adjusted.
Ergonomic and comfortable head band fits any head size.
Supplied in a cordura bag.
GIMA
code
LUX ENT MIRRORS
31108
LUX-55 battery head mirror - Ø 55 mm - 6V
31109
LUX-100 battery head mirror - Ø 100 mm - 6V
31110
LUX-55 AC/DC transformer head mirror - Ø 55 mm - 6V
31111
LUX-100 AC/DC transformer head mirror - Ø 100 mm - 6V
31114
Mirror for LUX-55 - spare
31115
Mirror for LUX-100 - spare
31116
Bulb for LUX mirrors - spare
31117
Battery case - with extension cable 80 cm for 31112/3
31119
Carrying bag for LUX mirrors - black
Comfortable, padded head band
easy to remove for cleaning
31109
31111
31110
Simple adjustment
using rotating knob
Simple adjustment
using rotating knob
Supplied with plug-in transformer for direct power.
Can be used with GIMA 6 AC/DC transformer for
perfect light intensity adjustment.
Silver coated
mirror produces
extremely
bright light
Silver coated mirror produces
extremely bright light
Storz type
head mirror
31130
TECHNICAL SPECIFICATIONS
Absorption: 6.6 Watt
Power supply: 230 V - 50 Hz
Size: 163x105x60 mm
Norms: 93/42/EEC
User manual: English, Spanish, French, Italian, Greek, Portuguese.
• 31142 ZIEGLER MIRROR -
Ø 90 mm
Concave back-silvered mirror,
90 mm diameter with 13 mm
diameter hole, on adjustable
band. Special mount permits
replacement of glass mirror in
event of breakage.
Made in Germany.
31170
30848
HEAD LOUPE AND MAGNIFYING GLASSES
Visual field
8.5x3 cm
GIMA ENT HEAD MIRRORS
FOR BATTERY OR AC/DC TRANSFORMER USE
Clar type head mirror
USE WITH
TRANSFORMER
Supplied with head band mounted
CR-123A battery box 6V (2 x 3V)
USE WITH BATTERY
31108
STANDARD ACCESSORIES
LUX AC/DC TRANSFORMER LUX BATTERY*
31110-31111
31108-31109
Mirror with head band
•
•
Long life bulb
•
•
Extension cable 2 m (to transformer)
•
Extension cable with on/off switch 30 cm
•
Head band mounted battery case for 2 x 3V CR-123A
•
Plug in transformer 100/240V - 50/60 Hz with cable •
*Battery not included
• 30858 LED HEADLIGHT
Run time: High mode: 3 hours - Low mode: 15 hours
Luminous intensity: 100 lumens (high) or 36 lumens (low)
30 feet drop test
Super bright CREE cool white LED
MCU control push switch
(High/Low/Off)
60° pivoting head
Passed extreme
temperature shock test,
IPX4 water resistant
10,000 switch cycle life
Lighting leakage design
when forget to turn off
switch.
• 32200 "AAA" ALKALINE BATTERIES - blister of 4 pcs.
• 31170 HEAD LOUPE
two magnifying systems
(2.2X and 3.3X)
The system is mounted on
an adjustable webbing head
band and provided with two
separate lenses. The first lens
provides a 2.2X magnification,
moving down the second
lens, we reach a total 3.3X
magnification. The superior
quality of this lens permits
high precision examinations.
The HEAD LOUPE magnifying
system can be used in combination with any kind of glasses.
Working distance: 30 cm. Made in Japan.
• 30861 DANAE MAGNIFYING
GLASSES
• 30848 SMART MAGNIFYING
GLASSES
Spectacle frame with
magnifying glasses useful
to physician whenever it is
necessary to have a magnified
view of the visual field and
be able to use both hands.
Lightweight, it folds up, and
can be worn over spectacles.
2.5X zoom lens which can be
tilted to achieve optimum
focus.
Adjustable
0-4.5 cm
1 W LED HEADLIGHTS
ZIEGLER MIRROR
Compact and lightweight
headlight only 65 g
Light, only 83 g
- optical system with 3
magnifying glasses (2X, 2.5X, 3X)
- can fit over your glasses
- adjustable to any face shape
Compatible with TETI
protective shield (see page 128)
