MEDICAL LIGHTS
170
D400 SINGLE-BULB THEATRE LIGHT
Modern theatre light with innovative design. Its single bulb
system focuses the light deeply inside tissues and not only
around them. A sterilizable handle enables the user to adjust
light field size. Uniform parabola shape for easy cleaning.
Theatre light with battery group.
On request battery group and automatic charger, lead acid battery,
maintenance free, 1 hour autonomy, 6 hours recharging.
DLE - Lamp switch automatic system
- available on request
Light can be equipped with 2 electronically controlled halogen
lamps. In case the main lamp does not work, the second lamp
automatically takes over and a LED flashes to warn.
LED LIGHT INNOVATIVE TECHNOLOGY
Pentaled 30E is a compact size hi-tech product to guarantee
great performance levels. It has 30 elliptical reflectors split into
6 modules each containing 5 LEDs, providing 130,000 LUX
- selectable 5,000 °K - 4,500 °K
. By simply pressing the digital key,
the surgeon can choose two different white light temperatures
- E-view
. Innovative lens allows the surgeon to expand/narrow
the illuminated operating field electronically, without altering
intensity of light.
- E-comfort
. The indirect light creates 3D shadowless
illumination of the operating field, no risk of dazzling
- E-white
. Only white light to avoid risk of perception
of colour temperature variations or coloured shadows
- E-deep.
Centre of light is fitted with extra LEDs module
specifically designed to reflect deep light. This means that
surgeon can work with perfect 3D lighting.
Battery and high definition camera on request.
Optional battery
group with automatic charger (2.5 hours autonomy) and high
definition integrated camera (for ceiling and wall model only).
TECHNICAL SPECIFICATIONS
Halogen bulb 100 W 24V G 6.35
Bulb life: 2,000 h at 22.8 V
Light intensity: 100,000 lux from the distance of 1 m
Colour temperature: 4,200 °K ± 5%
Diameter illuminated field: from 100 to 180 mm
External diameter of the reflector: 400 mm
Regulations: IEC 60601-2-41 93/42/EEC
Weight: 38 kg (mobile stand version)
Power supply: 230/24 V - 50/60 Hz (110 V on request) Made in Italy
Regulation system
The position of the light and the
focus are adjustable by the central
autoclavable handle.
93/42 EEC
Elliptic
reflector
D 400: 100,000 LUX
4 antistatic rubber
castors (2 with brake)
PENTALED 30E SURGERY LAMP 130,000 LUX
30701
Easy access
adjustable luminosity
Adjustable light intensity at 1 m distance (Ec)
Klx 60 to 130
Colour temperature - switchable
°K 4,500 to 5,000
Colour rendering index (CRI)
Ra 96
Light field (electronically adjustable)
16-28 cm
Light field diameter where the illuminance reaches 10%of Ec (d10) mm 160
Light field diameter where the illuminance reaches 50%of Ec
mm 80
Total radiated energy Ee where
the illumination reaches max level W/m
2
299
Average LED life
hours 50,000
Power supply:
100-240 V - 50-60 Hz
Regulations: IEC 60601-2-41 - 2007/47/EC
Made in Italy
30780
30779
30781
30782
30783
30785
30738
49205
49218
49219
Pentaled-mobile
Pentaled-mobilewith battery group and automatic charger
Battery group available on request for all models
Pentaled - wall
Pentaled - ceiling
Pentaled - ceiling - double
Autoclavable handle - up to serial number 12071
Autoclavable handle - since serial number 12072
Monitor holding arm - stand alone
Special structure for low ceiling (< 2.8 m)- single lamp
Special structure for low ceiling (< 2.8 m)- double lamp
GIMA
code
PENTALED 30E
30701
30702
30711
30721
30731
30738
30728
Scialytic light - mobile
Scialytic light - mobile with battery group and
automatic charger
Battery group available on request for all models
Scialytic light - wall
Scialytic light - ceiling
Spare halogen bulb 100 W, 24 V
Spare autoclavable handle - new
DLE - Lamp switch automatic system
GIMA
code
D400 SINGLE BULB THEATRE LIGHTS
Rotation at 10°
on the vertical stand
30783
30781
30782
30711
30721
30701
Aluminium structure
has been subjected to
mechanical testing involving
over 40,000 movements
TECHNICAL SPECIFICATIONS
SINGLE BULB THEATRE LIGHT 100,000 LUX
An aluminium ring runs around
the dome for easier positioning
30780
Structure in aluminium
(tubing Ø 45 mm)
to facilitate
installation
