MEDICAL LIGHTS
171
TECHNICAL SPECIFICATIONS
Light intensity at 1 m distance
Colour temperature adjustable
9 LEDs
Average LED life
CRI (chromatic rendering Index)
Light field where the illumination reaches 10% of Ec (d10)
Light field where the illumination reaches 50% of Ec (d50)
Depth of illumination IEC 60601-2-41 (L1+L2) at 20% of Ec
Depth of illumination IEC 60601-2-41 (L1+L2) at 60% of Ec
Total radiated energy Ec
Diameter of the reflector
Useful lighting surface of the cupola
Weight (ceiling, mobile, wall)
Power requirements
Minimum height of the room (ceiling version)
Standards: IEC 60601-1 IEC 60601-2-41, MDD 93/42 CEE, medical device of Class I
Warranty 12 months - mechanical components warranty 10 years
Lux
K°
W
hours
Ra
Ø cm
Ø cm
cm
cm
W/m
2
cm
cm
2
kg
V, Hz
cm
30,000
4,500/5,000 ± 5%
2.5 each
50,000
96
25
12.5
228
136
105
19.5
65
12 - 14 - 13
100-240, 50-60
240
Made in Italy
SHADOWLESS THEATRE LED LIGHT
Shadowless lamp with exceptional technical performance and
flexibility of use. Suggested for small surgery, gynaecological
and first aid surgeries. Cupola with four inner modules, each
with 7 LEDs (total of 28 LEDs) displayed in a radial layout with
lenses allowing shadowless and deep light.
LEDs modules guarantee continuous light, even in the unlikely
event that a LED should fail. Extremely easy to handle and
stable in position. Focusing and adjusting the diameter of the
illuminated area takes place by rotating the sterilizable handle
at the centre of the reflector.
Battery group with charger:
3 hours autonomy, 6 hours recharging.
4 antistatic
rubber castors
(2 with brakes)
93/42 EEC
TECHNICAL SPECIFICATIONS
Light intensity: 100,000 lux at 1 m distance
Diameter of the reflector: 40 cm
Adjustable diameter of illuminated field: 26-38 cm
Light field where illumination reaches 10% of Ec (d10): 24 cm
Light field where illumination reaches 50% of Ec (d50): 12 cm
Depth of illumination IEC 60601-2-41 (L1+L2) at 20%: 148 cm
Depth of illumination IEC 60601-2-41 (L1+L2) at 60%: 82 cm
28 LEDs 1 W each - life 50,000 hours
Colour temperature: 4,500° K ± 5%
CRI 96 (Chromatic Rendering Index)
Power supply: 100-240V - 50/60 Hz
Total radiated energy Ec 280 W/m
2
Weight (ceiling, mobile, wall) kg: 35 - 32 - 27
Minimum height of the rooom (ceiling version): 280 cm
Norms: IEC 60601-1, IEC 60601-2-41 - MDD 93/42/EEC
Made in Italy Warranty: 12 months - mechanical components warranty: 10 years
49110
49111
49112
49113
49218
30738
Scialytic light - mobile stand
Scialytic light -mobilewithbatterygroupandautomatic charger
Scialytic light - wall
Scialytic light - ceiling
Special structure for low ceiling (2.5-2.8 m)
Spare autoclavable handle - for scialytic 3 bulbs
Battery group available on request for all models
*
*
to be ordered with light
TRIS LED LIGHTS - 100,000 LUX
GIMA
code
TRIS SCIALYTIC LED LIGHTS
SATURNO LED MINOR SURGERY LAMP
SATURNO is a shadow-less type lamp suitable for small surgery,
gynaecology and examination.
Available in three versions: mobile with castors, wall and ceiling.
- light beams are generated from 9 LEDs - 2.5 W each
- heat is dissipated through aluminium cover reflector.
- selection of 2 different white light temperatures: 5,000 °K and 4,500 °K
- light intensity adjustable at 6 different levels by a key on front membrane
- luminous intensity 30,000 LUX at 1 m. Diameter of illuminated field 28 cm
- adjustable friction bearing are mounted on every articulation of the lamp
- thanks to optical concept, no need to be focus adjusted
Battery group with charger:
3 hours autonomy, 6 hours recharging.
Saturno LED light - mobile stand
Saturno LED light - mobile stand with battery group
Saturno LED light - wall
Saturno LED light - ceiling
Battery group with automatic charge available on request for
all models (to be installed at order)
Spare autoclavable handle for Saturno
49100
49101
49102
49103
30797
GIMA
code
SATURNO LED LIGHTS
SATURNO LED LIGHTS - 30,000 LUX
Sterilizable handle
On-off
switch
49110
49110
49113
49112
P
4 antistatic
rubber castors
(2 with brake)
Autoclavable handle
30705
49100
Load bearing
“Light structure”
in aluminium with tubing
Ø 45 mm facilitates installation
for any type of ceiling or wall
49102
49100
360° rotation
without stopping
Vertical
movement
49103
Same for 49102
and 49103
Adjustable friction bearings are
mounted on every articulation of the
lamp.
49113
