MEDICAL LIGHTS
172
PENTALED 12 - 50,000 LUX
PENTALED 12
Pentaled 12 is a perfect combination of technological
developments, innovation, ergonomy and compact design,
ultra-light and handy structure. Five versions available (trolley,
ceiling, ceiling double, trolley with battery group and wall)
and technical performances make Pentaled 12 suitable for
precision operations, diagnostic use, pre-operating theatres
and test laboratories. Battery group available on request also
for wall and ceiling models.
LED light
5,000K bright and cold light reproduces colours faithfully,
assuring excellent definition of details.
Indirect light
The physical principle of reflection is applied through a system
of ellipses. They reflect the light rays emitted by the LED on
the lighting surface, obtaining a high light intensity with a
reduced number of LED: over 50,000 lux at a distance of 1
metre with just 12 LEDs.
The indirect light does not dazzle and does not strain the eyes
and helps concentration.
Ergonomic
The ultra-flat lighting body is equipped with ultra-resistant
polycarbonate screen which guarantees protection against
accidental collisions.
PENTALED 12 can be easily positioned by rotation on 4 axes:
- the structure has a side full-circle handling without any stops
- the arm moves vertically thanks to a spring balancing system
- the reflector can be rotated on the vertical and
horizontal axis.
Movements are possible through the sterilizable handle.
The lower part of the reflector incorporates the switch and
a digital control to adjust the light with visual signal of the
intensity setup.
TECHNICAL SPECIFICATIONS
Light intensity at 1 m distance
Lux
50,000
Colour temperature
K°
5,000
LED
No.
12
Average LED life
hours 50,000
CRI (Chromatic rendering Index)
Ra
92
Light field where the illumination reaches 50%of Ec (d50) Ø mm 85
Light field where the illumination reaches 10%of Ec (d10) Ø mm 140
Depth of illumination (L1+L2) at 60%
cm
87
Depth of illumination (L1+L2) at 20%
cm
150
Total radiated energy Ec
W/m
2
119
Weight (ceiling, mobile, wall, double)
kg
18-13-12-20
Power supply
V/Hz
100-230V, 50-60Hz
Minimum height of the room (ceiling version)
mm
2,200
Standards: IEC 60601-2-41, MDD 93/42 CEE, medical device of Class I
Pentaled 12 - trolley
Pentaled 12 - ceiling
Pentaled 12 - wall
Pentaled 12 - trolley with battery group and automatic charger
Pentaled 12 - ceiling double
Autoclavable handle - spare
30787
30789
30790
30791
30792
30793
GIMA
code
PENTALED LIGHTS
30789
PENTALED 12
30792
30787
30789
30787
30787
30790
§
§
30792
§
§
30787
RI-MAGIC
®
LED LIGHT
TECHNICAL SPECIFICATIONS
Distance:
1,000 mm 800 mm 600 mm 400 mm 200 mm
Lux max:
15,000
20,000
30,000
45,000
55,000
Circle of light max Ø: 340 mm
270 mm 215 mm 155 mm 90 mm
Circle of light min Ø: 40 mm
35 mm 30 mm
25 mm
20 mm
Operating voltage: 100-240 V, 50-60 Hz
Ø 53 cm
mobile base
Low friction
antistatic
castors
with brake
Sturdy mobile
base made of
fiber glass and
chrome plated
pole.
Ri-magic desk can be fixed also on
bed-head with thickness 0.62 mm
49050
49051
• 49050 RI-MAGIC
®
- desk type
• 49051 RI-MAGIC
®
- trolley type
• 49052 RI-MAGIC
®
- wall type
High performance medical LED light for
examination and procedures.
- high performance LED, 6,500 Kelvin
- lifetime of the lamp up to 50,000 hours
- significantly reduced heating and energy loss
- focusing device at the front of the light head
- highly flexible, long special arm can be bent
in all directions
- rheostat handle for infinitely variable
regulation of light intensity
Supplied with manual in:
GB, FR, IT, ES, DE, RU.
Made in Germany
