LOUPES, VISION & ENDOSCOPY
167
TECHNICAL SPECIFICATIONS
Distance:
400 mm
200 mm
Lux max:
10,000
23,000
Circle of light max Ø: 200 mm
120 mm
Circle of light min Ø:
40 mm
30 mm
• 30890 GIMA LED HEADLIGHT - 5W
• 30891 BATTERY PACK - for 30890 up to LOT 000009 (Aug. 2013) - spare
• 30889 BATTERY PACK - for 30890 from LOT 000010 (Sept. 2013) - spare
Led lamp without the heat of traditional halogen headlight.
With a colour temperature of 5,500 °Kelvin, it provides bright, white,
shadow-free light allowing the doctor to see tissue characteristics without
distortion. Flexibility of operation using the rechargeable lithium battery,
instead of direct power source. Comfortable lightweight headlights suitable
for all kinds of surgery, ENT or dental applications. The headlight can be
used when it is charging, it also has low-battery indicator light. Adapts
to GIMA binocular loupes (codes 30892-98). Smart design, convenient
for mobile diagnosis. Supplied in aluminium box with rechargeable
7.2V/4,600mAH lithium battery and recharger.
• 30881 RI-FOCUS LED HEADLIGHT - with rechargeable batteries
High performance LED headlight with battery compartment
for fast and easy change of battery. Flexible hinge for a
comfortable one-hand use of the LED illumination body.
- more efficient diagnosis due to white and high performance
LED with up to 100,000 LUX and 50,000 hours lifetime
- wireless headband with built-in battery compartment
- particularly comfortable with balanced headband and one-hand
operation
- focusable LED lamp at a distance of 40 cm approx Ø 40 mm to 200 mm infinitely focusable
- white LED with 6,000 °Kelvin, 140 lumen
- significantly less heating and energy loss
- rechargeable battery operation: approx 90 min with fully
charged batteries
Rechargeable AAA batteries and plug in 230V charger included
30892
Binocular Loupe
2.5X
340 mm
80 mm
30894
Binocular Loupe
2.5X
420 mm
100 mm
30897
Binocular Loupe
3.5X
340 mm
60 mm
30898
Binocular Loupe
3.5X
420 mm
72 mm
30910
Style binocular Loupe
2.5X 340 mm 80 mm
30911
Style binocular Loupe
2.5X 420 mm 100 mm
30914
Style binocular Loupe
3.5X 340 mm 60 mm
30915
Style binocular Loupe
3.5X 420 mm 72 mm
Magnification
Magnification
Working
distance
Working
distance
Field of
view Ø
Field of
view Ø
BINOCULAR LOUPES:
Light weight, ergonomically superior Galilean-style flip-up
loupes. Can be used independently or mounted on 30890.
Multi-coated and high grade glass lenses provide clean and
sharp image. Eyepiece with wide field of view.
Deep focus to see object stereoscopically.
Loupes angles can be easily adjusted between 0° and 40° to
minimize fatigue even after prolongued use.
6 mm up and down displacement.
Adjustable pupil distance to fit different face types.
STYLE BINOCULAR LOUPES:
Line of binocular loupes with same features of traditional line
but mounted on a extra light, fashionable frame.
BINOCULAR LOUPES
STYLE BINOCULAR LOUPES
GIMA LED HEADLIGHT
GIMA BINOCULAR LOUPES
Adjustable light
intensity
Lightweight:
70 g
Adjustable light spot at
420 mm with iris
diaphragm: 20-80 mm
User manual in English, French, German,
Italian, Spanish, Portuguese, Greek, Arabic
7 hours continuous
run-time on a fully
charged battery
85,000 LUX
at 200 mm
5,500° KELVIN
GIMA
code
GIMA
code
30890
TECHNICAL SPECIFICATIONS
Illumination light spot at 420 mm: 20-80 mm
Illumination in 200 mm working distance: ≥ 85,000 lux
Adjustable range
Fluctuation distance: 12.5 mm
Angle range: vertical ± 25° adjustable
Weight of headlight (excluding head band): 69 g
Illumination source: extremely bright light, 5 W LED, life
20,000 hours
Battery: 7.2 V/4,600mAH lithium battery
Battery run-time: not less than 7 hours continuous run-
time on a fully charged battery (charging time: 5 h)
Voltage: 100-240 VAC, 50-60 Hz
Maximum input power: 15 W
Power adapter output: DC 12 ±0.5 V, 1.5 A
Electrical safety standard: IEC60601.1, class II type BF equipment
RIESTER RI-FOCUS LED HEADLIGHT
Weight 210 g
without batteries
Made in Germany
On/off switch on the
battery compartment
30881
30910
30897
All binocular loupes
are supplied in a case
Removable and
washable
inner padding
