ECG, MONITORS & ULTRASOUND
229
4 pins lead ECG cable
PALM ECG'S
are designed for general practitioners or for domestic
users who suffer from cardiovascular diseases such as hypertension,
coronary disorders, giving the possibility of a daily ECG test.
Records can be saved and used as a reference for clinical applications.
4 measurement modes: palm, leg, chest or lead wire traditional
measurement.
Main features:
- small, portable and easy to use
- 30 second ECG waveform and measurement results
- 600 (CARDIO-A) or 1200 (CARDIO-B) ECG waveform can be saved
- 5 hours (CARDIO-A) or 10 hours (CARDIO-B) ECG continuous
measurement data storage
- analysis and report of 8 types (CARDIO-A) and 17 types
(CARDIO-B) of ECG waveform
- USB 2.0 interface with option data cable and ECG viewer software
- traditional measurement with optional ECG cable
CARDIO B with bluetooth module for wireless data
transmission.
To download data on your smartphone or tablet, compatible
with Android.
Methods of ECG measurements: direct or with lead wires
TECHNICAL SPECIFICATIONS
CARDIO A
CARDIO B
ECG bandwidth:
0.5 Hz - 40 Hz
1 Hz - 40 Hz
Heart rate measuring range:
30 - 240 bpm ± 2 bpm
LCD back light display: 128x64 dot matrix
240x160 dot matrix
Display size:
49x25 mm
57.6x40 mm
Power:
2xAAA batteries
Dimensions
115x58x18 mm
125x70x21.5 mm
Weight
65 g
106 g
TECHNICAL SPECIFICATIONS
Heart rate measuring range:
30 bpm ~ 240 bpm
Heart rate measuring accuracy:
± 2 bpm or ±2%whichever is greater
ECG bandwidth:
0.5 Hz ~ 40 Hz
Internal noise level:
≤ 30μVp-p
Display scale:
5.0 mm/mV ±10%
Common-mode rejection ratio (CMRR): ≥ 60 dB
Waveform sweeping speed:
20 mm/s ±10%
Input loop current:
≤ 0.1 μA
Input impedance:
≥ 5 mΩ
Power
Power:
4 AA alkaline batteries
Supply voltage range:
4.4 ~ 6 VDC
Max average working current:
≤ 160 mA
Auto power-off:
can be adjustable between 1-5 mins
Low battery indication:
4.4 VDC ±0.2 VDC
SINGLE CHANNEL PALM ECG:
CARDIO-A AND CARDIO-B
CARDIO-C: 3 CHANNEL POCKET ECG
True colour 3.5"
TFT display
Direct on leg Direct on chest Direct on palm
or wrist
With lead wires,
need limb
electrodes 33364
With lead wires,
need chest
electrodes 33327
• 33245 CARDIO-C POCKET
ECG 3 channel
- small size, light-weight and easy to carry
- one-key measurement
- clear ECG waveform and interpretation of results on colour
dot-matrix TFT 3.5" screen
- up to 19 types of measurement results
- high capacity built-in memory: 24 hours records storage
and review for single channel waveform and 8 hours record
storage and review for 3-channel waveforms
- quick measurement:
by built-in metal electrodes
, on palm,
chest or leg or
by external lead wires
(needs optional limb and
chest electrodes)
- data management to review or delete data records locally or
to upload to PC
Supplied with ECG viewer software, USB cable, power
transformer, ECG 4 pins lead wire, 25 disposable electrodes.
Other accessories see at page 235.
• 33364 SET OF 4 LIMB CLAMP ELECTRODES (4 COLOURS) - adult
• 33327 DISPOSABLE TNT ELECTRODES Ø 55 mm
0123
0476
0476
510 (K)
4 MEASUREMENT MODES:
PALM, LEG, CHEST,
TRADITIONAL
33259
33260
Pocket size:
13x9.5x3.2 cm
32 MB memory
inside
ECG
see page 4
GIMA
code
PALM ECG
33260
CARDIO-A palm ECG
33261
CARDIO-B palm ECG - colour display
33259
CARDIO-B Bluetooth palm ECG+viewer software
ACCESSORIES
33265
ECG viewer software+USB 2.0 cable - for 33260, old 33261
33249
ECG viewer software + USB 2.0 cable for new 33261
since SN: XXS02JL01044 - Jan 2014
33248
New ECG 3 pin lead cable - 3 leads - optional - 2012
from SN: XXQ00HJ03925 for 33260
from SN: XXS02HL01709 for 33261
33264
Old ECG banana lead cable - 3 leads - optional
