LOUPES, VISION & ENDOSCOPY
168
• 30885 HEINE 3S LED HEAD LIGHT - J.008.31.313
Ultra bright and compact HEINE 3S LED
HeadLight for powerful, coaxing illumination.
-
50,000 Lux of bright, white light:
With a reference colour temperature of 5,600 Kelvin
and an extraordinary 50,000 Lux of illumination, the 3S LED
HeadLight is more than twice as bright as conventional Headlights
-
Compact and Light-Weight:
The compact design ensures clear, unobstructed coaxial
illumination. The 3S LED HeadLight weighs only 70 grams
ensuring user comfort even during prolongued use.
-
Flexibility:
Continuously adjustable spot size and brightness control.
Mains or 10 hours operating time with mPack
®
power supply.
Rechargeable battery pack and direct mains transformer included.
• 30886 HEINE BINOCULAR LOUPE 2.5X-340mm - J.000.31.370
• 30887 HEINE BINOCULAR LOUPE 2.5X-420mm - J.000.31.371
TECHNICAL SPECIFICATIONS
Power supply:
mPack
®
Rechargeable Battery Pack with NiMH battery and
direct mains transformer
Illumination:
50,000 lux at a working distance of 250 mm
LED operating life: 20,000 hours
Spot adjustment: 20 mm to 130 mm illuminated field diameter (at 500 mm)
Colour temperature: 5,600°K Made in Germany
30885
HEINE LED HEAD LIGHT HEINE BINOCULAR LOUPES
POWERFUL LED
ILLUMINATION
50,000 LUX
at 250 mm
TELESCOPE + PROJECTOR
IUKO VISION MODULAR SYSTEM
ADJUSTABLE PROJECTOR
• adjustable LED light projector
• 2 different brightness intensity
(30,000 and 50,000 lux at 25 cm,
autonomy 6 and 4 hours)
• 6,500°K temperature
• autonomy 4 hours at maximum power
• battery pack placeable on the head band
• compatible with TETI
This system includes Galileian
telescope (CALLIOPE) and
LED light projector
(IRIDE)
PROTECTIVE SHIELD
• provide protection from squirts and spray
• extremely light 130 g and confortable
• folding shield behind the nape
• can fit over your glasses
TETI - 30860
MAGNIFYING GLASSES
• optical system with magnifying
glasses
• can fit over your glasses
• light, only 83 g
• adjustable to any face shape
• compatible with TETI
DANAE - 30861
NIKE 30870/1
GALILEIAN TELESCOPES
• magnifying optical
system with Galilean
telescopes
• waterproof telescope
• compatible with TETI
CALLIOPE
30864/5/6
IRIDE 30867
You can create below system adding protective
shield (TETI) to telescope+projector (NIKE)
TELESCOPE + PROJECTOR
+ SHIELD
GIMA
code
TETI - protective shield (2 shields included)
DANAE - magnifying glasses with 3 lens (2, 2.5, 3 X)
CALLIOPE - Galilean telescope 3X - dental (working distant 35 cm)
CALLIOPE - Galilean telescope 3X - surgical (working distant 45 cm)
CALLIOPE - Personalized Galileian telescope: magnification from 2X
to 3X, working distance from 28 to 60 cm - specify with order
IRIDE - LED light projector
NIKE - Galileian telescope 3X (35cm) + projector
NIKE - Galileian telescope 3X (45cm) + projector
Set of 5 transparent face shields - spare
Battery pack - spare
30860
30861
30864
*
30865
*
30866
*
30867
*
30870
*
30871
*
30875
30876
VISION MODULAR SYSTEM
A unique modular system for all your needs. You can combine elements to protect, magnify,
light up, ... Any component can be used indipendently or combined with one or more.
30870/1
+ 30860
VISION MODULAR SYSTEM
30930
Heine binocular loupes 2.5X 340 mm C-000.32.355
30931
Heine binocular loupes 2.5X 420 mm C-000.32.356
30932
Heine binocular loupes 4X
340 mm C-000.32.431
GIMA
code
BINOCULAR LOUPES
HEINE code
Magnification Working
distance
4.0X magnification:
4.0X loupes
provide magnification for most advanced
micro-surgical and dental applications yet still
offer a large 50mm field of view. The 340mm
working distance is ideal for applications where
the user is in a sitting position.
Super-Wide, Super-deep field of view.
2.5X loupes
offer an excellent balan-
ce between high magnification, field
of view, depth of field, and ease of use,
ideal for a wide range of applications
such as dental, ophthalmic,
cosmetic and reconstructive
surgery.
Only 42 g
Only 78 g
Eyepieces individually
adjustable
Adjustable
0-4.5 cm
HEINE binocular loupes
set standards for
innovative optics combined with high-tech
materials and production techniques.
A wide range of applications: general
medicine, dermatology, minor and
some major surgery, plastic surgery,
neuro-surgery, ENT, ophthalmology,
veterinary medicine, dentistry etc. The
use of magnifying loupes will increase
your visual acuity and reduce eye strain.
Careful selection of working distance
and correct viewing angle will avoid
back and neck strain by allowing a
comfortable working position.
Set content: optics, S-frame with i-View loupe
mount, detachable protective lenses, 2 sterilisa-
ble swivel levers, retaining cord, cleaning fluid,
carrying case.
*
Supplied in a case with accessories
30930
30931
30932
30870/71
