254
FIRST AID - PARAMEDICAL - EMERGENCY
NONINGO2OXIMETER
Back light display
2400 tests perfor-
med with one AAA
battery (21 hours
continued use)
Lead (PB) free
and latex free
Lead (PB) free
and latex free
TECHNICAL SPECIFICATIONS
Saturation range: 0-100% ±2 digit (70-100%)
Pulse rate range:18-321 bpm ±3 digit (20-250 bpm)
0123
• 35079 NONIN GO2 -
9570 - IT, FR, DE, NL
• 35080 NONIN GO2 -
9570 - GB, FR, ES, PT
GO2 are
manufactured to
the same technical
specifications and
technology used in
NONIN professional
oximeters, but are dedicated to consumers
for people suffering from shortness of breath,
fatigue or limited activities.
- highly resistant: it is tested to resist 25 times
to fall down from 1 meter, to liquids and to
continuative use
- patient oriented display
- finger size range from pediatrics to adult
- easy to read perfusion indicator
- suitable for low perfusion patient
Other manuals for download: GR, PL, DK, NO, SE, FI.
Large Bright LED Display
SpO
2
and pulse rate can
be read from any angle,
day or night
The original all-in one
digital fingertip pulse oximeter
™
NONIN ONYX
®
VANTAGE 9590
TECHNICAL SPECIFICATIONS
Pulse rate range:
18-321 bpm
±3 digit (20-250 bpm)
SpO
2
range:
0-100%
±2 digit (70-100%)
Low perfusion SpO
2
:
70-100%
±2 digit
Low perfusion pulse rate:
40-240 bpm
±3 digit
0123
• 35085 NONIN ONYX
®
VANTAGE 9590 PULSE
OXIMETER
The Onyx is the only finger pulse oximeter with
scientifically proven accuracy in motion and
low perfusion,
and it is tested for use on fingers,
thumbs, or toes.
- Accurate
- Scientifically proven performance in the
widest range of patient populations and settings
- Durable
- Protects against dropping and water spills;
allows for thousands of uses in the most demanding
environments and exceed IP32 water ingress testing
- Efficient
- Up to 6000 spot checks or 36 hours of continual operation on two
AAA batteries
- Safe
- Built in the USA with lead-free and latex-free construction
- Versatile
- One unit works on the widest range of patients from pediatric to larger
adult patients. Accomodates a wide range of digit thicknesses from 8 mm to 25.4 mm
- Warranted
- Industry-leading 4-year warranty
- Cost Effective
- Proven accuracy, quality and durability make the Onyx
Vantage a smart purchase for the long term
Supplied with multilanguage CD-rom manual: GB, FR, IT, DE, ES, PT, GR, NL, PL,
NO, FI, DK, SE.
OXY-PED
TECHNICAL SPECIFICATIONS
• 34266 OXY-PED PEDIATRIC OXIMETER
Similar to OXY-6 but expecially studied for
pediatric use. Input shaped to fit children's fingers
Ø 8-12 mm. It is supplied with two rechargeable
batteries and USB battery recharger. All other
specifications are like OXY-6 model.
• 34270 RECHARGEABLE BATTERY - spare
Pulse rate:
SpO
2
:
Perfusion index:
RANGE
30-240 bpm
35%-99%
0-20%
ACCURACY
± 2 bpm (2%)
± 2% (75-99%)
± 3% (50-75%)
± 0.1% (0-20%)
± 0.2% (20-25%)
RESOLUTION
1bpm
1%
0-1%
Alarm: SpO
2
: low limit 90%
Pulse rate: low: < 50 bpm - high > 120 bpm
Power: 3.6V rechargeable batteries
Norms: IEC 60601-1-2 Class II
TECHNICAL SPECIFICATIONS
Pulse rate:
SpO
2
:
Perfusion index (PI):
RANGE
30-240 bpm
70%-100%
0.2-20%
ACCURACY
± 2 bpm or 2%
± 3%
Alarm: SpO
2
: 85-99%
Pulse rate: high 100-240 bpm
low 30-60 bpm
Power: 2xLR03 (AAA) Alkaline batteries 3.0 VDC
Size: 60x33x30 mm
Weigth: 35 g
PEDIATRIC
34266
4 direction OLED colour display
Visual and audible alarms
• 35095 OXY-10 FINGERTIP
MULTIFUNCTION OXIMETER
Professional oximeter to monitor
pulse oxygen saturation and
pulse rate through patient's finger
(adult, child, neonate).
- wireless Bluetooth technology for
transmission to PC Windows (XP and
Seven) and software for data management
- external pediatric SpO
2
probes available in
3 sizes for pediatric and neonatal use
- large true colour OLED display
- SpO
2
, PR, Pulse bar, P.I. and plethysmogram
- audible and visible alarms with high and low alarm
limits adjustable by user
- patient oriented display with automatic change of 4 directions
- accuracy from the first reading in a few seconds
- extra stability against motion during measurement
- 9 languages manual (English, French,
Italian, German, Spanish, Greek,
Portuguese, Polish, Arabic)
Supplied in nylon bag with batteries
• 35096 PEDIATRIC CLIP PROBE - reusable
• 35097 PEDIATRIC RUBBER PROBE - reusable
• 35098 NEONATAL PROBE - disposable
OXY-10 OXIMETER -
WIRELESS
OLED
COLOUR
DISPLAY
Neonatal disposable probe
35098
35096
External pediatric SpO
2
probes
with 1 m cable
Pediatric rubber
reusable probe
35097
Pediatric clip
reusable probe
35096
EXTERNAL PEDIATRIC - NEONATAL PROBES
0123
