FIRST AID - PARAMEDICAL - EMERGENCY
• 34038 AMBU
®
SAM MANIKIN
The Ambu SAM is a low-priced,
simple, yet effective, compact
training manikin. With its
anatomical correct landmarks
the manikin enables students
to learn the complete
algorithm of Basic Life support
including the use of Automatic
External Defibrillators (AED)
and the placement of the AED
Pads. It is designed to store the
head inside the manikin while
storage or transport. Lightweight
can be easily assembled for the training without the need of
additional tools. Ambu SAM has the unique patented hygienic
system that eliminates the risk of cross infections. It enables
training with a face piece and a disposable head bag. Just as
in real life, ventilation can be seen and exhalation through the
nose and mouth can be felt and heard. The shape of the body
has all human characteristics for a realistic training.
The compression indicator confirms correct procedure.
Supplied in a soft carrying bag with 25 disposable head bags.
Total manikin size 70x33x20 cm, weight 2 kg.
• 34039 HEAD BAG - box of 100 pcs
AMBU TRAINING MANIKINS
Size: 80x35 cm
Weight: 13 kg
• 34042 AMBU AIRWAY MAN I
• 34049 AMBU AIRWAYMANWwith CPR
The Ambu Airway Man is an
adult-sized training manikin that
provides an exceptionally lifelike
representation of the human
anatomy.
Mechanical instrument
gives you
instant feedback on ventilation volume,
stomach inflation, chest compression
depth in mm and wrong hand position.
Easy change of scale plates on the
mechanical monitor instrument.
PC connection
(34049 only) is possible, allowing
connection of Ambu CPR Software Kit, Ambu CPR Printer
or USB Interface.
Make intubation
possible with ET tube, Guedel,
Laryngeal Mask and combi-tube.
Ambu Airway man includes torso with hooks for
arms, computer interface with CPR software kit
(34049 only), supplied in track suit jacket and training mat.
CPR SOFTWARE KIT Selectable languages:
GB, FR, IT, ES, DE, PT, PL, DK, HU, NL, RU, JP, KR
• 34043 COMPLETE SET: ARMS, LEGS, TROUSERS
AND BAG
Jaw thrust possible
Adjustable stiffness
of the chest
iPAD CU-SP1
INTELLIGENT PUBLIC ACCESS DEFIBRILLATOR
CU-SP1 is the last generation of intelligent public access
defibrillators with innovative features:
- Auto volume adjustment
It detects the ambient noise and automatically adjusts
the volume of its prompts to make them audible over the
background noise.
- Smart pads - intelligent storage
The pre-connected "Smart" electrode pads are stored in an
easy access compartment on the underside of the unit.
This ensures that the iPAD SP1 is always ready to be used in the
shortest time possible. In addition, the visual frontal indicator
shows if the connected pads are within their life expectancy.
The indicator will change when the pads have only 3 months
life left before their expiry date giving you time to arrange for
replacements. It will change again when the expiry date is reached.
- CPR detection
CPR ensures that the casualty has the best chances of survival.
The CU-SP1 detects if CPR is being performed with appropriate
prompts, if not it encourages the responder to perform it.
- Easy communication with CU-EX1 software
Installing CU-EX1 software onto a computer allows you to see
and analyze the usage history of the unit. Information such as
time of "power on", the casualty's heart rhythm and shocks
delivered are all clearly presented.
The iPAD CU-SP1 can store up to 5 events with up to 3 hours of
ECG analysis on an SD memory card.
- 16 languages available (to be indicated with order)
Selectable software languages: US, GB, FR, IT, ES, DE, PT, NL, PL,
SE, DK, NO, CZ, GR, AE, KR, IL.
Supplied with adult SAVE PADS, carrying bag, disposable
lithium battery pack, paper manual (GB, IT) and CD manual in
above languages excluding PL and GR.
35340
35339
35342
35343
35344
35345
35346
33423
35349
GIMA
code
iPAD CU-SP1 AED DEFIBRILLATOR
ACCESSORIES FOR CU-SP1
TECHNICAL SPECIFICATIONS
Defibrillator
Operating mode:
Semi-automatic
Waveform:
e-cube biphasic (Truncated exponential type)
Energy:
150J fixed
Adult: nominal 150J at 50 ohm load
Infant/child: nominal 50 joules at 50 ohm
Charge control:
controlled by automated patient analysis system
Charging time:
within 10 seconds since voice instruction "an electric
shock is needed"
Sealing:
waterjet proof IPX5 per IEC60529 (IP55)
dust protected IP5X per IEC60529
User interface
User support:
detailed voice prompts and flashing indicators
CPR guidance:
voice prompts for how to perform CPR for adult and child
Controls:
on/off button, ”i“ button, shock button
Indicator:
LCD display (Device status, Battery status, Pads status)
Sensing:
pads expiry date, Pads connection status
CPR Monitoring
Automatic Volume adjustment
Data recording and transmission
IrDA port:
wireless transmission of event data to PC, SD Card
Internal Memory (Nand-flash): ECG, Event
Storage capacity:
multi recording 5 events / Max 3 hours
Data review PC Programme: CU-EX1
Patient analysis system
Patient Analysis:
Shockable Rhythms - Ventricular Fibrillation, Tachycardia
Sensitivity/Specificity Meets AAMI DF80 Guideline
Disposable high capacity battery
Standard
Type: DC 12 Volt 4.2 Ah, Lithium manganese dioxide
Capacity: Minimum 200 shocks (150J)
AHA/ERC 2010
GUIDELINES
34038
iPad CU-SP1 defibrillator - semiautomatic
iPad CU-SP1 defribillator - automatic
(available sept. 2014)
Trainer Defi Pads - kit of 2
Trainer - 16 selectable software languages
Adult PADS - kit of 2 pcs - disposable
Pediatric PADS - kit of 2 pcs - disposable
Disposable lithium battery LiMnO
2
high capacity 4.2 Ah
Wall cabinet with sound alarm
SD card+ software for event recording download
