257
FIRST AID - PARAMEDICAL - EMERGENCY
Operating mode:
Semi-automatic
Waveform:
e-cube biphasic (Truncated exponential type);
impedance compensated
Energy:
200J fixed
Adult: nominal 150 J into a 50 ohm load
Infant/child: nominal 50 joules into a 50 ohm load
Shock energy accuracy: Within ±3% (200 J into 50 Ω)
Shock to shock cycle time: Typically less than 20 seconds
Protocol:
Voice prompts and indicators guide through protocol
Charge control:
Automatic by Software (Arrhythmia Detection
System and Charging Control)
TECHNICAL SPECIFICATIONS
Charge time from “Shock advised”: < 10 seconds, typical
Voice instruction:
Voice messages guide through use of defibrillator
Controls:
Shock Button, i-Button, On/Off Button
Indicators:
7 LEDs ( different colors), i-Button
Patient isolation:
Type BF, defibrillation protected
Battery:
12 Volt DC, 4.2 Ah, lithium manganese dioxide,
disposable long-life primary cell
Battery capacity:
Min. 200 Shocks or 10 hours of operating time
Data recording:
Data Stored: First 40 minutes of ECG and the entire
incident’s events and analysis decision
Size - Weight:
220x260x70 mm - 2.2 kg (4.84 lbs) with battery pack
SPECIALLY DESIGNED
FOR PUBLIC USAGE
Pads
connector guide
IrDA port used
for data com-
munication
Battery
pack
Information button
State LED
Shock
button
Size: 32.5x34x18 cm
Voice version
and manual
Spanish
French Portuguese Italian
English
Other
languages*
33408 33409
33413 33414
33416 33417
-
-
-
33424
33405 33406
*
Voice languages: DE, DK, KR, JP, NL, SE, with same language manual, updated to ERC guidelines 2010
*
Voice languages: CZ, GR, HU, IL, IR, NO, TR, with English manual, updated to ERC guidelines 2005
The i-PAD NF 1200 is a semi-automatic external defibrillator designed for
minimally trained individuals. It provides simple and direct voice prompts
and indications for a straightforward rescue operation. It is lightweight
and battery powered for maximum portability. It is designed to treat Ventricular
Fibrillation (VF) and Fast Ventricular Tachycardia. These two are the most common
causes of sudden cardiac arrest (SCA). In SCA, the heart of the victim suddenly stops
pumping. The only effective treatment for VF is the application of a defibrillating
shock. It may be used on children 1-8 years old (less than 25 kg) with pediatric
reduced energy pads, over with adult pads. Supplied with a set of adult
pads, lithium battery (200 Shocks or 10 hours operating time), manual.
According to ERC Guidelines 2010.
TRAINER:
simulates all the functions of i-PAD, with 8 rescue scenarios.
33423
33405
33422
i-PAD PUBLIC ACCESS DEFIBRILLATOR
i-PAD DEFIBRILLATOR AND TRAINER
GIMA code
Original accessories for I-PAD
DEFIBRILLATOR
TRAINER
33418
Lithium battery pack
33441
Disposable pads - kit of 2 pcs
33443
Disposable pediatric pads - kit of 2 pcs
33422
Carrying bag
33423
Wall cabinet with alarm sound
33403
IrDa connector for data communication + software
for event recording download with key file
0470
RESCUE SAM AED DEFIBRILLATOR
Rescue Sam is a semi automatic external defibrillator designed for
public use by minimally trained people. It provides easy and simple
indications for rescue operations. Supplied with lithium battery
(200 shocks or 4 hours operating time), set of adult pads and
manual. According to AHA/ERC Guidelines 2010. Made in Italy.
GIMA
code
RESCUE SAM DEFIBRILLATOR
TECHNICAL SPECIFICATIONS
Operating mode:
Semi-automatic (DAE)
Waveform:
BTE (Biphasic Exponential Truncated)
impedance compensated
Energy:
200 J fixed
Charge control:
Automatic by software (Arrhythmia Detection
System and charging control)
Charge time:
< 8 seconds
Time between discharges:
< 20 seconds
ECG data acquisition:
Derivation II, by defibrillation pads.
Band from 1 Hz to 35 Hz
Impedance:
25 Ω to 200 Ω
ECG analisis system:
Voice instructions:
Vocal and optical message guide
Autotest:
automatic, battery insertion,
daily/weekly/monthly
Long life battery:
12 Volt DC, 42 Ah, LiMnO
2
disposable
Battery capacity:
200 shocks or 4 hours of operating time
Data recording, stored:
first 60 minutes of ECG and the entire
incident's event
Size-weight:
30x28x9 h cm - 2.3 kg with battery
33420
33425
33419
Disposable adult
pads with cable
0068
5 YEARS WARRANTY
MADE IN ITALY
JFDA
33425
Rescue Sam defibrillator - English
33426
Rescue Sam defibrillator - Italian
33427
Rescue Sam defibrillator - French
33430
Rescue Sam defibrillator - Spanish
33559
Rescue Sam defibrillator - other languages
*
*
Other languages available in 20 days: DE, PL, NL, CZ, SE, TR, FI, RU
33419
Lithium battery pack
33458
Disposable pediatric pads (kit of 2)
33448
Disposable adult pads (kit of 2)
33420
Disposable adult pads (kit of 2) and cable
33421
Carrying bag
33421
