FIRST AID - PARAMEDICAL - EMERGENCY
Lithium battery, 3 years stand-by (100 shocks @360J), (PAD only)
Lithium battery, 6 years stand-by (200 shocks @360J), (AED, AED-M)
AkuPack Lite, rechargeable battery with clip charger, (AED-M, HS6(S))
SpO
2
probe (HeartSave 6S only)
ECG cable 3 leads (HeartSave 6 and 6S only)
Savepads
Data and voice recording
Manual
STANDARD ACCESSORIES
WITH LITHIUM BATTERY
100 DISCHARGES @360J
3 YEARS STANDBY
Italian English French
Other
languages
**
HS PAD
33393 33395 33398 33402
WITH LITHIUM BATTERY
200 DISCHARGES @360J
6 YEARS STANDBY
English
Italian
Spanish
English
Spanish
Greek
Portuguese
Italian
French
German
Polish
Other
languages
***
HS AED
HS AED-M with monitor
33384
*
33385
*
33391
33396
33392
33397
33394
33399
*
For use only on patients >8 years or 25 kg, need SAVE PADS 33386/88
WITH AKUPAK LITE
RECHARGEABLE BATTERY
AND CLIP CHARGER
English
Italian
Spanish
French
English
Spanish
Greek
Portuguese
Italian
French
German
Polish
Other
languages
***
HS AED-M with monitor
HS 6 with monitor
HS 6S with monitor - SpO
2
33440
-
-
-
33452
33462
-
33453
33463
33446
33456
33466
High resolution LCD monitor gives
important information for resuscitation
Connection socket for save
pads and ECG cable
Trigger button for real single-button
operation. You can save a life with
only one button.
Status display
AHA/ERC GUIDELINES
2010 CONFORMITY
EN 1789
IP55 WATER-
CLASS-PROTECTED
MADE IN GERMANY
33396
PRIMEDIC
™
EXTERNAL DEFIBRILLATORS - AED
PRIMEDIC
™
EXTERNAL DEFIBRILLATOR - AED
The convincing feature of the PRIMEDIC
™
HeartSave product line is its easy, safe and speedy
operation. With the new biphasic "Current Controlled Defibrillation" pulse, we are setting
new standards in defibrillation technology. The device performs an automatic ECG analysis
within 12 seconds and decides whether a defibrillation is necessary. Then a touch of a button
is enough to trigger the life-saving electric pulse that eliminates the ventricular fibrillation.
Thus, valuable seconds and minutes are used to save life.
Main features:
- one-button operation
- intuitive and easy handling
- status indicator
- can be operated either by Lithium-Battery or Lithium-ion rechargeable Akupak Lite
- no energy selection required
- current controlled defibrillation
- SaveCard, at least 24 hours, for internal ECG and voice recording
- periodic self-test (daily, monthly, yearly)
- dim. approx. 26x26x8.5 cm, weight approx. 2 kg
- compliance with environment tests for fixed wing aircrafts and
helicopters (excluding PAD)
- German Lloyd certification (for use in maritime environments)
A range of 4 models is available for use on patients > 1 year
PRIMEDIC™ HEART SAVE PAD and HEART SAVE AED
Automatic external defibrillator with integrated one-channel ECG,
acoustic and optical user guidance, data backup and 3 years (PAD)
or 6 years (AED) non rechargeable lithium battery life.
Vocal guidance in 1 language (PAD), or 4 languages (AED and HS6).
PRIMEDIC™ HEART SAVE AED-M with monitor
Besides the features of AED, AED-M includes a monitor
indicating operation duration ECG, heart rate, identified VF/VT.
0123
TECHNICAL SPECIFICATIONS
Defibrillation
Wave: biphasic, current controlled pulse
Energy 140-360J
Charging time:
< 12 sec @ 360J
Operating modes: asynchronous
ECG
Lead: II
I, II, III, aVr, aVf, aVI
Patient's impedance range:
20-200 Ohm
Heart rate:
30-300 per min
VF:VT Detection
VF/VT Detection
Manual override
Analysis time
6-12 sec
VF threshold
0.2 mV
Asystole threshold <0.2mV
Artefact-Pacemaker detection
Pulse Oxymeter
Nellcor
Electrodes
Non polarized electrodes, 3 years storage
Cable length 1.5 m
LCD Monitor
95x72 mm (diagonal 4.7"/120 mm)
320x240 (pixel size 0.36x0.36 mm)
Storage battery status display
Speed 25 mm/s
Heart rate, number of defibrillation, number of
VF/VT, total resuscitation time
Data backup
Removable memory
Voice recording
Power supply
Lithium battery or Rechargeable (clip charge 100-240V, 50/60 Hz)
Battery:
**
Lithium battery only
***
Lithium battery or rechargeable AkuPak Lite
****
Rechargeable AkuPak Lite only
PAD+AED AED-M HS6 HS6S
PAD+AED AED-M HS6 HS6S
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
**
•
**
•
•
•
•
•
•
•
•
•
***
•
•
•
•
•
•
•
•
•
***
•
•
•
•
•
•
•
•
•
****
Battery storage
Discharges
Monitoring
Voltage
Rechargeable
Lithium-ion
6 Years (all others)
95 (at 360J) or
150 (at 200J)
5 h
14.4 V
Lithium
or
LiMnO
2
3 Years (PAD)
110 (PAD),
200 (AED)
20 h (AED-M)
6h (HS 6)
6 V
PAEDIATRIC SAVE PADS for 1-8 years max 25 kg
SAVE PADS for over 8 years, 25 kg
SAVE PADS for over 8 years 25 kg
Only for 33384/5
and AED sold before April 2014
Lithium BATTERY - not rechargeable
life 6 years
AkuPak Lite Rechargeable battery
PowerPak Battery charger for code 33400
Flashcard ERC guidelines
update (2005 to 2010)
****
****
For defibrillators sold up to december 2010 - Specify serial
number with order
GB, IT,
FR, ES
** We can provide following languages (voice + manual): ES, PT, FR, GR, DK, FI, CZ, PL, NL, TR, AE, IR, BR, HU, TH,
JP, LT, RO, SI, IL. Only voice: MK, HR.
***We can provide following languages (voice + manual): BG, CZ,DK, FI, HR, HU, MK, NL, NO, RO, RU, SE, SI, TR,
AE, CN IR, TH. Please specify with order. Available in 40/60 days.
Voice version and manual
SAVE PADS
Self-adhesive electrode, cable, razor and
gloves - shelf life 3 years
HEART SAVE EXTERNAL DEFIBRILLATORS
PRIMEDIC™ HEART SAVE 6 with monitor (cardio version)
In addition to the AED-M features, Heart Save 6 includes
semi-automatic mode, 6-channel ECG leads and the manual mode for professional users.
PRIMEDIC™ HEART SAVE 6S with monitor (cardio version) and SpO
2
AC-and AkuPak-powered manual external biphasic current controlled defibrillators, synchronous/asynchronous, high contrast
bluemode LCD monitor, 3/6 channel-ECG, 3/6 channel-ECG printer, adult/pediatric paddles.
Other
languages
AED
CURRENTCONTROLLED
DEFIBRILLATION
Menu
button
35390 35391
35392 35393
33388 33386
33387 33387
33400 33400
33407 33407
33401 33401
ACCESSORIES - SPARES
