258
FIRST AID - PARAMEDICAL - EMERGENCY
33570-33575
CU-ER2
33565
Disposable pads - kit of 2 pcs
33569
Pediatric disposable pads - kit of 2 pcs
33567
ECG cable - 3 leads
33404
Communication connector + software for event
recording download with key file
33568
Car cigar lighter jack
33730
Nellcor compatible SpO
2
probe (only for CU-ER3)
33562
Rechargeable battery 2 pins - new models
33563
Rechargeable battery 4 pins - old models
33564
Battery charger
English
Italian
Spanish
French
Other
languages
*
33570
33571
33572
33573
***
33575
33580
33581
33582
***
33583
***
33585
Voice version
and manual
GIMA code
CU-ER 2
CU-ER 3
ACCESSORIES FOR CU-ER1, CU-ER2 AND CU-ER3
CU-ER2, CU-ER3 dual mode defibrillators can be used both in
automatic (AED) and manual mode.
Main features:
- synchronized cardioversion
- ECG monitoring mode (3 lead ECG cable)
- SpO
2
monitoring with Nellcor SpO
2
module (only CU-ER3)
- heart rate and SpO
2
alarm system (only CU-ER3)
- CPR coaching in AED
- efficient e-cube biphasic
truncated exponential shock waveform
- versatile power supply
- intelligent data management system
ECG of patient is recorded all throughout the rescue operation,
relevant events (e.g. shock advised, charging, shock delivery) are
recorded together with timestamp. Recorded data may be transferred
to a PC for storage and review or may be reviewed in the device
- lightweight 2.7 kg (CU-ER2) 2.8 kg (CU-ER3) and portable.
Supplied with rechargeable battery,
battery charger, adult pads with cable,
SpO
2
module (CU-ER3 only), user
manual and carrying bag.
*Voice and manual: DE, KR. Voice: CZ, NL, PL, JP, TH, CN. with English manual
***
English manual
• ECG Monitor
- Patient connection: defibrillation pads, ECG electrodes
- Bandwidth: monitoring mode: 0.3 to 40Hz (-3 dB)
- EMS Mode: 1-30Hz
- Heart rate: digital 30 to 300 bpm (±3bpm)
• Defibrillator
- Waveform: e-cube biphasic (biphasic truncated exponential type)
- Charging time: less than 10 seconds
- Sensitivity & specificity: meets AAMI guidelines
- Defibrillation electrodes: multifunctional electrodes (disposable, pre-gelled)
• Voice & text prompts
- Voice prompts guide the user through the rescue protocol
• Data storage & management
- Internal flash memory: 12 hours of event and ECG recording
- Review the patient ECG. incident details and device information
- Transmit multi patient data to PC
• Display
- High resolution display (graphic LCD). 4 inches (10.16 cm), 320x240 pixels
- Sweep speed: 25 mm / sec. nominal
- Viewing time: 3.2 seconds
• Automatic self-test
- Power on / run time / manual self-test
- Periodic self-test (daily/weekly/monthly)
• AC adapter
- Input: 100 - 240V AC 50/ 60Hz - 170VA - Output: +12V DC 3.6A
• Battery pack
- 12V 4.5Ah nickel-metal hydride battery pack (rechargeable)
- Charging time: minimum of 4 hours for full charging
- Capacity: when new, minimum of 200 shock deliveries (fully charged)
TECHNICAL SPECIFICATIONS CU-ER1, CU-ER2, CU-ER3
COMPARISON CHART
LCD Screen displays
- the ECG of patient
- energy of the shock
to be delivered
- shock count
- heart rate
- battery stauts
- elapsed time
0470
Voice version
and manual
English
Italian
Spanish
French Portuguese Other
***
languages
*
33550 33454
33552 33553
33554 33555
33560 33561
-
-
-
-
CU-ER1 AUTOMATED EXTERNAL DEFIBRILLATOR
DEFIBRILLATOR
TRAINER
CU-ER1 is an automated external defibrillator with monitor and
ECG functions.
Main features:
• Intelligent Arrhythmia Detector
• Efficient and effective e-cube Biphasic Truncated Exponential
shock waveform
• Lightweight and highly portable
• Versatile Power Supply
Rechargeable battery pack, AC/DC adapter, car cigar lighter jack
(optional)
• Intelligent data management system
ECG of the patient and relevant events are recorded all
throughout the rescue operation. Recorded data may be
transferred to a PC or reviewed in the device.
Supplied with rechargeable battery (minimum 4 hours for
full charge), battery charger, adult pads with cable,
user manual and carrying bag. According to ERC guidelines 2010.
PARAMEDIC DEFIBRILLATORS CU-ER1, CU-ER2, CU-ER3
*Voice and manual: DE, JP, KR, RU. Voice: CZ, PT, PL, GR, IR, CN, TH with English manual
AUTOMATED
EXTERNAL
AED
+
MANUAL
AED +
MANUAL
WITH SpO
2
ECG Monitor
CU-ER1CU-ER2CU-ER3
ECG Size
auto-scaled
•
•
•
S, 10, 20 mm/mV
•
•
Defribillator
Operating mode Semi automatic
•
•
•
Manual
•
•
Waveform
e-cube biphasic (BTE Type)
•
•
•
Energy
AED Mode 150J (default setting)
•
•
•
Manual Mode: Variable energy
levels selection (12 steps escalating, 2, 3, 5,
•
•
7, 10, 20, 30, 50, 70, 100, 150, 200J)
Synchronous Cardioversion Energy
delivery begins within 60 ms of the QRS peak
•
•
Control
Manual mode: CHARGE, SYNC (R-wave), DISARM •
•
AED mode. ANALYZE, PAUSE
•
•
SpO
2
Pulse rate
20~250 bpm (±3 bpm)
•
Saturation
70~100 bpm (±3 digits)
•
Perfusion
0.20%
•
Physical
Patient isolation Type BF
•
•
•
33550-33555
CU-ER1
Size: 254x309x93 mm
33580-33585
CU-ER3
