FIRST AID - PARAMEDICAL - EMERGENCY
METAL CABINET FOR DEFIBRILLATORS -
INDOOR OR OUTDOOR
CU-SP2 is the last generation of intelligent public access
defibrillators with innovative features:
- Auto volume adjustment
It detects the ambient noise and automatically adjusts the volume
of its prompts to make them audible over the background noise.
- Smart pads - intelligent storage
The pre-connected "Smart" electrode pads are stored in an easy
access compartment on the underside of the unit ensuring use in
the shortest possible time. In addition, the visual frontal indicator
shows if the connected pads are within their life expectancy.
The indicator will change when the pads have only 3 months
life left before their expiry date giving you time to arrange
for replacements. It will change again when the expiry date is
reached.
- CPR detection
CPR is vital to ensure that the casualty has the best chances of
survival. iPAD CU-SP2 detects if CPR is being performed with
appropriate prompts, if not it encourages the responder to
perform it.
- Easy communication with CU-EX1 software
It allows to see and analyze information such as time of "power
on", the casualty's heart rhythm and shocks delivered. iPAD CU-
SP2 saves 3 events on the internal memory (up to 17 hours per
event).
- Wireless ECG transmission device (CU-EM1) - optional
In monitor mode, iPAD CU-SP2 uses Bluetooth to receive ECG data
from CU-EM1 and displays it on the LCD screen.
- Printer - optional
iPAD CU-SP2 supports connection to an external Bluetooth printer.
- 16 languages available (to be indicated with order)
Selectable software languages: US, GB, FR, IT, ES, DE, PT, NL, SE, PL,
DK, NO, CZ, GR, AE, KR, IL.
Supplied with adult SAVE PADS, carrying bag, disposable lithium
battery pack, paper manual (GB, IT) and CD manual in above
languages excluding PL and GR.
METAL CABINETS FOR DEFIBRILLATORS - INDOOR USE
• 35330 METAL CABINET - INDOOR USE - white
• 35331 METAL CABINET WITH ALARM - INDOOR USE - white
Magnetic sound alarm 100 dB.
• 35333 POLE for cabinet - white
METAL CABINETS FOR DEFIBRILLATORS - OUTDOOR USE
• 35334 METAL CABINET - OUTDOOR USE - yellow
Water tight welding on the sides, water and dust proof gaskets.
Made in carbon steel, thickness 15/10. Adjustable internal shelf.
• 35335 METAL CABINET WITH THERMO REGULATION SYSTEM
AND ALARM - OUTDOOR USE - yellow
Same as 35334, with radio alarm, magnetic sensor and remote
control to activate/disactivate alarm. Sound alarm 105 dB.
• 35337 POLE for cabinet - yellow
35351
35341
TECHNICAL SPECIFICATIONS
Defibrillator
Operating mode:
Semi-automatic
Waveform:
e-cube biphasic (Truncated exponential type)
Energy:
AED mode: 150/200J fixed or 150-150-200J energy escalating
Manual mode: 2-200J, R-Sync
Charging time:
within 10 seconds
Charging time after CPR finished: at least 6 seconds
Sealing:
waterjet proof IPX5 per IEC60529 (IP55)
dust protected IP5X per IEC60529
User interface
User support:
detailed voice and text prompts
CPR guidance:
voice prompts for how to perform CPR for adult and child
Controls:
on/off button, ”i“ button, shock button, soft keys
Indicator:
graphic LCD display (Device status, user's guide, ECG,
heart rate, .....)
Sensing:
pads expiry date, pads connection status
CPR Monitoring, ECG Monitoring, Automatic Volume adjustment
Data recording and transmission
IrDA port:
wireless transmission of event data to PC, SD Card
Internal Memory (Nand-flash): ECG, Event
Storage capacity:
multi recording 3 events / Max 17 hours for each event
Bluetooth:
communication with the printer
Data review PC Programme: CU-EX1
Patient analysis system
Patient Analysis:
Shockable Rhythms (Ventricular Fibrillation, Tachycardia)
Sensitivity/Specificity meets AAMI DF80 Guideline
Rechargeable battery
Standard
Type: DC 11.1 Volt 1.9 Ah, Li-ion rechargeable
Capacity: Minimum 60 shocks or 3 hours of operation
iPAD CU-SP2
AED AND MANUAL DEFIBRILLATOR
Graphic LCD
Defibrillator
pads connector
Power button
i-Button
IrDA port and SD card port
Wireless ECG
Wireless printer
Shock
button
Soft keys
16 languages selectable
as iPAD CU-SP1
iPad CU-SP2 is sup-
plied with adult PADS,
rechargeable battery,
battery charger and
multilanguage CD
manual (14 languages)
35350
INDOOR USE
OUTDOOR USE
Both cabinets
are suitable
for walls
mounting
or use with
pole
9V battery
for alarm.
Low charger
indicator
Power 230V
for thermore-
gulation.
Supplied
without
plug.
IP 44
PROTECTION
GIMA
code
iPAD CU-SP2 DEFIBRILLATOR
35341
iPad CU-SP2 defibrillator - manual and AED
ACCESSORIES FOR CU-SP2
35344
Adult PADS - kit of 2 pcs - disposable
35345
Pediatric PADS - kit of 2 pcs - disposable
35347
Rechargeable 12 V, 1.9 Ah Li-ion battery
35349
SD card+ software for event recording download
35350
Wireless ECG for CU-SP2
35351
Wireless printer for CU-SP2
External size: 42.5x16xh 42.5 cm
Internal size: 40x13xh 40 cm
External size: 43x21xh 48 cm
Internal size: 42x20xh 45 cm
