FIRST AID - PARAMEDICAL - EMERGENCY
The convincing advantages: PRIMEDIC DEFI-B is immediately
ready for application and is not depending on the main power
supply due to large accumulator capacity. After switching on,
the defibrillator carry out an internal self-test. In order to
ensure a functional optimal handling, the user is supported
by clear instructions and pictograms. A shock-resistant plastic
casing protects the device, especially under rough conditions.
• 33381 SPARE BATTERY
TECHNICAL SPECIFICATIONS
Mode: Asynchronous, external defibrillator
Energy step: 20, 50, 100, 160, 250, 360 Joule
Discharges: 45 shocks with 360 Joule,
(10 reserve after signal "battery low")
Charging time:
2 sec (33380-2) and 4 sec (33383) up to 100 Joule,
4.5 sec (33380-2) and 7.6 sec (33383) up to 360 Joule
Paddles for children integrated
Accumulator: 14.4 V / 1.4 Ah (33380-2 only)
Charging time: 3.5 hours (33380-2 only)
Safety: Internal discharge of energy after 15 sec.
Internal self-testing and fault recognition
Protection class II, type BF
Mains voltage: 200-240 V 50/60 Hz or 110 V
Dimensions: 40x48x12 cm (W x D x H)
Weight: 8.5 kg
Made in Germany
0123
Compact and handy: PRIMEDIC
DEFI-B is easily transportable
and immediately ready to use
everywhere
Suitable for adult and
children (reference norms
ERC 2005 use of joule
depending on kg).
In emergency situation the
well structured and logical
operator guidance may
save a life
33380
DEFIMONITOR XD
The sophisticated high performance instrument with
multifunctional features.
It combines a compact product design, proved and tested in
practice with the highest possible degree of safety and user
friendly handling.
Range of 8 manual (XD1, XD3, XD10, XD30) or manual + AED
(XD100, XD300, XD110, XD330) defibrillators with or without
SpO
2
and external pacer.
Supplied with adult/pediatric paddles, disposable adult Save
Pads, connect cable, ECG cable, power cable, 1 tube gel, 1
paper roll.
Standard software: GB, FR, DE, IT, ES, PT, TR, CN.
Manual: GB, IT (on request DE, ES, PT, FR, TR, CN).
Other softwares and manuals available on request: CZ, FI, HU,
RO, NL, NO, PL, RU, SE, SL, AE, BR, CN, IR, JP, KR, TH, US.
35370
DefiMonitor XD1 manual
35371
DefiMonitor XD3 manual with SpO
2
35372
DefiMonitor XD10 manual with pacer
35373
DefiMonitor XD30 manual with SpO
2
+ pacer
35374
DefiMonitor XD100 manual + AED
35375
DefiMonitor XD300 manual + AED with SpO
2
35376
DefiMonitor XD110 manual + AED with pacer
35377
DefiMonitor XD330 manual + AED with SpO
2
+ pacer
GIMA
code
DefiMonitors XD
TECHNICAL SPECIFICATIONS
XD1 XD3 XD10 XD30 XD100 XD300 XD110 XD330
Defibrillation
Wave:
biphasic, current controlled impulse
• • •
•
•
•
•
•
Energy (automatic mode)
140-360 J
• • •
•
•
•
•
•
Manual energy stages:
5J, 10J, 20J, 30J, 50J, 100J, 200J, 300J, 360J
Charging time:
< 6 sec for 200 J • • •
•
•
•
•
•
Cardio version: manual activation, QRS marker
• • •
•
•
•
•
•
ECG
Derivation: Eindhoven I, II, III
• • •
•
•
•
•
•
Goldberger, aVR, aVF, aVL
• • •
•
•
•
•
•
Patient's resistance:
23-200 Ohm
• • •
•
•
•
•
•
Heart rate:
30-300 per min
• • •
•
•
•
•
•
VF: recogniton
VF recogniton
•
•
•
•
Analysis time
7-12 sec
•
•
•
•
VF threshold
200 μV
•
•
•
•
Asystole threshold
< 200 μV
•
•
•
•
Artefact, Pacemaker detection
•
•
•
•
Pulse Oximeter
Nellcor Oximax
•
•
•
Pacer
Transthoracic heart pacemaker
•
•
•
•
Modes:
fix, demand, overdrive
•
•
•
•
Thermal printer
Resolution: 200 dpi
• • •
•
•
•
•
•
Advance: 25 mm/s, 50 mm/s
• • •
•
•
•
•
•
XD1 XD3 XD10 XD30 XD100 XD300 XD110 XD330
TFT LCD blue-mode monitor
115x86 mm (diagonal 4.7"/120 mm)
• • •
•
•
•
•
•
320x240 pixels
• • •
•
•
•
•
•
Electrodes
Adhesive electrodes, 3 years shelf life
• • •
•
•
•
•
•
Cable length 3.5 m Save pads connect
• • •
•
•
•
•
•
Data backup
Removable memory 512 MB
• • •
•
•
•
•
•
Data/Voice recording > 90 h
•
•
•
•
Data/Voice recording > 75 h
•
•
•
•
Power supply
Voltage 90-264 V, 50/60 Hz
• • •
•
•
•
•
•
Rechargeable Lithium-ion battery (LiFePO
4
):
Capacity 2.5 Ah Voltage: 14.4 V
• • •
•
•
•
•
•
Discharges 150-200 J
• • •
•
•
•
•
•
Monitoring 5 h Charging time: 2.5 h
• • •
•
•
•
•
•
Resuscitation guidelines
Selectable AHA/ERC
• • •
•
•
•
•
•
Standards
IEC60601-1:1988+A1:1991+A2:1995
(Electrical Safety of Med. Electrical Devices)
IEC60601-1-2:2001 (Electromagnetic compatibility) • • •
•
•
•
•
•
IEC60601-1-4:1996+A1:1999
(Programmable electrical medical systems)
IEC60601-2-4:2002 (Defibrillators)
• • •
•
•
•
•
•
EN1789:2003 (Ambulance standard)
• • •
•
•
•
•
•
Protection class IP33
• • •
•
•
•
•
•
• • •
•
•
•
•
•
• • •
•
•
•
•
•
• • •
•
•
•
•
•
DEFI-B BATTERY DEFIBRILLATOR
Accessories for DefiMonitors
35380
SAVE PADS GB, IT, ES (require connecting cable 35384)
35383
SAVE PADS other languages (require connecting cable 35384)
35384
Connect cable for SAVE PADS 35380/3 - spare
33400
AKuPak LITE rechargeable battery
35386
Charge base for 33400 for DefiMonitor XD
35387
Paper roll 58 mm x25 m - box of 10
35388
DefiMonitor carrying bag with shoulder strap
GIMA
code
• 33380 DEFI-B DEFIBRILLATOR - 220 V
The mobile security: PRIMEDIC DEFI-B is a
state-of-the-art accumulator-driven defibrillator.
It was designed in accordance with strict requirements of
emergency medical science. Fully developed and reliable
technique, world-wide in use since years. PRIMEDIC DEFI-B is
a battery supplied version and has proved successful in daily
use in ambulances, with cardio sport groups and in hospitals.
Size: 25x28x9 cm
EN 1789
MADE IN
GERMANY
PRIMEDIC
™
DefiMonitor XD -
PROFESSIONAL DEFIBRILLATORS
