ECG, MONITORS & ULTRASOUND
239
DIGITAL PORTABLE ULTRASOUND
CHISON 600M (2012 VERSION) PORTABLE ULTRASOUND
3.5
7.5
6.0
3.0
7.5
33904
33905
33906
33907
33908
CONVEX
LINEAR
MICRO-CONVEX
(TRANSVAGINAL)
CARDIAC
TRANSRECTAL
2.5/3.5/4.0/5.0
5.0/6.0/7.5/10
4.5/6.0/7.0/8.0
2.0/3.0/3.5/4.5
5.0/6.0/7.5/10
• 33900 CHISON 8300 DIGITAL PORTABLE ULTRASOUND - 2 probe connector
Both are supplied with 10" SVGA monitor, CINE memory, 2 USB ports, software packages.
Without probes.
Professional portable ecograph with wide range of probes and high
quality of images suitable in many specialistic fields.
:
- B, B/B, 4B, M, B/M
- harmonic imaging
- 256 gray scales
- scanning depth: max 246 mm (depending on probe)
Probes:
supplied with 2 probe connector
- selection of 5 probes: Electronic Convex / Linear
/ Transvaginal / Transrectal / Cardiac
- wideband multi-frequency 2-10 MHz
Image processing:
- fully digital beamforming technology
- real-time dynamic imaging: RDF, RDA, DFS, DRA
- frame averaging: 8 steps
- linear averaging: 8 steps
- 6 STC slides for near far and overall gain control
- image reversing: left/right, up/down
- zoom: intelligent zoom, 4 steps
Measurement and report
- B mode: Distance, circumference, area, volume,ratio, angle, %stenosis, histogram, profile
- cardiology package: LV, mitral and aortic valve, CO, LVET, MVCF, SV, EF, cardiac index
- software package: Abdomen, OB/GYN, Cardiac, Urology
- M mode: distance, time, velocity, heart rate
- EDD tables, gestational age: BPD, GS, CRL, FL, HC, AC
- fetal weight, fetal heart measurement, growth analysis, LMP, BBT
Others
- CINE: 256 frames, play back selectable
- 10 inch, SVGA high resolution monitor
- image permanent storage: hard disk, USB (2 ports)
- can use PC printer (A4) or video printer
- operating voltage: 230V - 50Hz, 110V - 60Hz on request
• 33901 HEIGHT ADJUSTABLE TROLLEY
• 33903 CARRYING BAG
• 33967 SONY PRINTER UP-897MD
33900+33901+33967
ISO9001
Fully portable,
ergonomic
design
Report
templates:
NORMAL, OB,
GYN, UROLOGY,
CARDIAC reports
Powerfull software
Back-light key-
board for better
visibility in dark
room
Two USB ports
Two probe
connectors
Optional
printer
2
ND
HARMONIC IMAGING
Transmitted
frequency
3.5 MHz
Received
frequency
7.0 MHz
Internal organ or tissue
Ignore founda-
mental signal
from received
signal
Only for code 33904
33930
Lightweight: only 7 kg
(size: 42x27x25 cm)
Ergonomic keyboard
33932
33933
33934
CONVEX
LINEAR
MICRO-CONVEX
(TRANSVAGINAL)
3.5
7.5
6.0
2.5/3.5/4.0/5.0
5.0/6.0/7.5/9.0
4.5/6.0/7.0/8.0
O
O
O
P
O
O
P
O
Two probes connector
included with 33930
• 33930 CHISON 600M PORTABLE ULTRASOUND 10" SVGA
monitor with two probe connectors, 256 frames cine memory,
USB port, VGA port, without probes
- zooming andmeasurement functions (max scanning depth: 252mm)
- wide applications: GYN, urology, abdominal, small parts
- easy to use, just one day to learn all functions
- 4-steps sweep speeds for cardiac study: 2s, 4s, 6s, 8s
- 4-steps zoom with depth control: x0.8, x1.0, x1.5, x2.0
- various measurements: Distance, Circumference, Area, Volume
- full Ob/Gyn software included: 7 EDD tables (BPD, GS, FL, AD,
HC, AC, CRL), G.A. (fetal age) from 4-43 weeks
- fetal weight, fetal heart rate measurement
- imaging reversing: up/down, left/right, positive/negative
- power supply: 110-230V, 50-60 Hz
• 33967 SONY PRINTER UP-897 MD
You can use any other printer for ecograph on the market
• 33901 TROLLEY FOR 33930
0197
ISO9001
GIMA
code
PROBES
FREQUENCY (MHZ)
O
Main application
P
Alternative application
Outlook
Scanning
Method
Main freq.
4-Step
Multi-
frequency
ABDOMINAL
OB/GYN
UROLOGY
SMALL PARTS
BREAST
CARDIOLOGY
PROCTOLOGY
PEDIATRICS
VESSELS
O
O
O
O
P
O
P
O
O
P P
O
GIMA
code
PROBES
FREQUENCY (MHZ)
O
Main application
P
Alternative application
Outlook
Scanning
Method
Main
freq.
4-Step
Multi-
frequency
ABDOMINAL
OB/GYN
UROLOGY
SMALL PARTS
BREAST
VESSELS
Modern design, height
adjustable trolley,
provided of 4 wheels
with brake.
33900
