ECG, MONITORS & ULTRASOUND
235
HOLTER ECG SYSTEM -
24 HOURS MONITORING
• 35130 ECG HOLTER + SOFTWARE
ECG Holter system includes ECG recorder and software connectable
to a computer system or laser printer. The recorder has built-in
flash storage media to increase memory capacity. The sampling
rate of 1,000 sampling/sec has improved the quality of waveform.
Accuracy of the system is ensured by AHA and MIT data.
Features:
- windows software interface (GB, IT, PL)
- quick and accurate analyzing system
- special editing system of R point
- perfect analysis function of ST segment
- analysis function of T wave of all channels and T wave trend graph
- review of ECG trend graph
- analysis system of HR variability, providing regular SDNN,
SDANN, RMSSD, LF, HF, time domain and frequency domain
- QT analysis and QT trend graph
- acquire pacing ECG directly without separate channel;
Also have the functions of VCG, VLP, TVCG, HRT, TWA
Recorder:
- 12 channel Synchronized ECG Acquisition
- small ECG recorder with OLED colour screen to display real
time ECG waveform and review storage data.
- capacity up to 2G
- selectable sampling rate, 200, 500, 1,000 sampling/sec
- sampling accuracy: 12 bit
- built-in FLASH storage media, to prevent
the flash card from damage due to
repeated insertion and pull out
- USB interface
- operating system: Windows 98, 2000, XP, 7
• 35131 ECG CABLE - spare
Scale voltage:
1mV±5%
Standard sensitivity:
10mm/mV ±5%
Noise level:
≤30μV
CMRR:
≥60dB
Frequency response:
10Hz as benchmark, 0.5Hz~55Hz; -3dB
Time constant:
>3.2s
Scan speed:
25mm/s ±5%
Enduring polarization voltage:
±300mV
Least measurence signal:
50μV p-p
Interference between channels:
scan track deflection (result from inter-
ference between channels) <0.5mm
Product safety type:
type B (internally
powered)
Size:
111 (L) x60 (W) x25 (H) mm
Net weight:
105g (without battery)
STANDARD ACCESSORIES
TECHNICAL SPECIFICATIONS
1 Holter recorder
1 CD with software
10 leads patient cable
10 disposable ECG sensor
1 pouch for hanging recorder
1 USB cable for data downloads
1 USB security key
Instruction Manual (English, Italian)
Monitor
not Included
Electrode for long
time monitoring
with Micropore
™
foam support
33324
Ø 30 mm
33367
33376+33378
33344
33375
33376
33342
33341
33325
33327
33297
33369
Ø 30 mm
33365
Ø 24 mm
33368
Ø 15 mm
33363
33364
Conform to EN 60601-2-25
ELECTRODES AND ADAPTORS
FOR MOST ECG
33363
33364
33368
33365
33369
33323
33324
33325
33327
33344
33367
33341
33375
33376
33342
33378
33297
GIMA
code
UNIVERSAL REUSABLE ECG ELECTRODES
Minimum
order
1 set
1 set
1 set
1 set
1 set
1 set
1 set
1,250 pcs.
1,200 pcs.
1,200 pcs.
10 pcs.
100 pcs.
10 pcs.
10 pcs.
10 pcs.
100 pcs.
1,000 pcs.
Set of 4 limb clamp electrodes (4 colours) pediatric
Set of 4 limb clamp electrodes (4 colours) adult
Set of 6 chest electrodes Ø 15 mm- silver coated
Set of 6 chest electrodes Ø 24 mm- silver coated
Set of 6 chest electrodes Ø 30 mm- silver coated
Set of 6 chest electr. Ultra Ø 24 mm - silver coated
Set of 6 chest electr. Ultra Ø 30 mm - silver coated
Disposable FOAM electrodes Ø 36-45 mm - solid gel
Disposable TNT electrodes Ø 55 mm - solid gel
Disposable FOAM electrodes Ø 48-50 mm - liquid gel
Adaptors Ø 4 mm to connect ECG cable to code 33325/27/44
Disposable pre-gelled tab electrodes 34x22 mm
Adapter for ECG cables (pin) - veterinary
Adapters for ECG cables with 4 mm banana plug
To be used with GIMAPLAY and CARDIOGIMA ECG
Universal adapter with 4 mm socket
for snap and alligator connection
3M Red Dot™ 2330 - 3.2 x 2.2 cm
single use electrode with conductor adhesive gel
3M Red Dot
TM
2239 - Ø 6 cm - 20 bags box of 50 pcs
UNIVERSAL DISPOSABLE ECG ELECTRODES AND ADAPTERS
3M RED DOT
TM
ELECTRODES
