ECG, MONITORS & ULTRASOUND
238
Lightweight
only 350 g
2 MHz
5 MHz
8 MHz
33126
33127
33128
33123
TECHNICAL SPECIFICATIONS
Ultrasound
Frequency: 2, 5 or 8MHz continuous wave
Transducer: 2 crystal narrow beam
Output power: <15mW/cm
2
SATA
Audio Response: 300Hz - 4 KHz
Unit Controls
Keys: 1 Key (for unit on/off)
Controls: rotary volume
Indicators: Yellow battery low LED
Power supply
Battery 9V Alkaline (not included)
Expected battery life: >9 hours
Output
Headset: Audio output to optional
headset (not included)
Material:ABS / Noryl
Size: 150 mm by 75 mm
Weight: 299 g (with transducer)
Classification: Class I Type B - IEC 60601-I
Warranty: 2 years (probe and cable
included)
Made in UK
GIMA POCKET DOPPLERS
Small, lightweight, high sensitivity pocket Doppler. Its probes
are ideal for use by a General Practitioner, vascular specialist
for routine vascular examination in ER for vessel location, or by
specialists in diabetes, urology and gynaecology. Vascular flow
signals and FHR are easily located using the transducer while
internal signal processing minimises noise artefacts. The flow
signal is also available to the user via the built-in loudspeaker
with output level controlled by rotary volume control.
DOPPLER V2005 with 5 MHz fixed vascular probe
DOPPLER V2008 with 8 MHz fixed vascular probe
DOPPLER V2000 (without probe)
2 MHz interchangeable probe - foetal for V2000
5 MHz interchangeable probe - vascular for V2000
8 MHz interchangeable probe - vascular for V2000
ON/OFF membrane switch spare for 33120/3
33120
33121
33123
33126
33127
33128
29511
Supplied in a nice bag with 7 languages user
manual: English French German Italian Spanish,
Greek, Portuguese and gel tube.
• 33230 GIMA BIDIRECTIONAL DOPPLER NON STEREO with
two probes: 4 and 8 MHz
Continuous wave (CW) bidirectional doppler equipped with
electronic probes for high sensitivity and low background noise.
- Bidirectional graphic separation of flow (forward and reverse)
- LCD graphic display for real time display of forward and
reverse flow in bidirectional or separate mode
- Selectable amplitude scale: 1, 2, 4, 8 kHz. during the test and
before printing. Preset zero line.
- 5 minutes (300 sec.) continuous and reviewable memorized
test. Operator can select the most meaningful exam and print it.
- Calculation of: heart rate, peak flow and mean flow.
- Simultaneous connection of high sensitivity probes
- Internal rechargeable large capacity battery (Ni-Cd 1.8 Ah);
the system can be operated during charging. Autonomy 8
hours use or 1 hour print.
- Footswitch for freezing or memorizing the graphs
- Hardcopy may or may not include the parameter calculation
- Printing time scale: 25 mm/s.
- Hi-fi audio output for correct acoustic diagnosis
• 33240 GIMA BIDIRECTIONAL PROBE 4 MHz - spare for 33230
• 33241 GIMA BIDIRECTIONAL PROBE 8 MHz - spare for 33230
• 33250 THERMAL PAPER 58 mm x 25m (pack of 5 rolls)
TOP QUALITY: MADE IN UK
POCKET DOPPLER
WITH INTERCHANGEABLE OR FIXED PROBES
GIMA
code
GIMA POCKET DOPPLERS
GIMA PORTABLE, BIDIRECTIONAL, VASCULAR DOPPLER
High definition
thermal printer:
192 dots
Main functions are available
from footswitch or Key-pad
Probe selection
33230
Light, only 1.8 kg,
and compact
(24 x 23 x 8 cm)
0120
Size:
154x240xh 88 mm
33967
33993
SONY VIDEO PRINTER
SONY
AND
MITSUBISHI PAPER
• 33967 SONY PRINTER UP-897 MD - black/white
Produces A6 size printings in about 2 seconds, with superb
print quality with 325 dpi and grey level of 256 steps.
110-240 V AC, 50/60 Hz.
• 33993 SONY COLOUR PRINTER UP-25 MD
High quality analogue A6 Dye.
Sublimation Printer for use in
medical applications.
An ideal technology for
making high quality, accurate
photographic prints.
SONY VIDEOPRINTER PAPERS
• 72730 SONY PAPER - UPP-110 HD - box of 5 rolls
High density printing paper - 110mm x 20 m
• 72731 SONY PAPER - UPP-110 HG - box of 5 rolls
High glossy printing paper- 110mm x 18 m
• 72732 SONY PAPER UPP-110S - box of 5 rolls
• 72733 SONY PAPER UPP-110HA - box of 5 rolls
• 72735 SONY COLOUR PAPER UPC-21L
(4 ink rolls + 200 supports 144x100 mm)
MITSUBISHI VIDEOPRINTER PAPER.
• 72740 MITSUBISHI PAPER LX65HM-CE
