ECG, MONITORS & ULTRASOUND
243
ACCESSORIES AND SPARES
35135
35136
35137
35140
31542
35139
31543
35126
35141
35150
GIMA
code
ECG and TEMP
Heart rate range: 20bpm~300bpm
TEMP measurement range: 25°C~45°C
Accuracy:
±2bpm or 1% whichever is
greater (ECG) ±0.2°C (TEMP)
CO
2
Technology:
Infrared absorption method
Sampling Mode:
Sidestream or Mainstream
CO
2
Response Time: - Sidestream: <3seconds
(includestransporttimeandrisetime)
- Mainstream: <60ms (rise time)
Power
AC power supply voltage: 100~250V, 50/60Hz
International power supply: 12VDC (rechargeable)
Batteryspecification:12V2,3AH (sealed lead-acidbattery)
NIBP
Technology: Oscillometric method
Standard measurement range:
SystoIic: Adult: 50-240mmHg
Diastolic: Adult: 15-180mmHg
MAP: Adult: 25-200mmHg
Measurement mode: Manual, Auto, STAT
SpO
2
SpO
2
measurement range: 0%- 99%
SpO
2
measurement accuracy: 75%-99% ±2%
50%-74% ±3%
Low perfusion performance: 0.4%
Pulse rate measurement range: 30bpm~240bpm
Pulse rate measurement accuracy:
± 2bpm or 2% whichever is greater
TECHNICAL SPECIFICATIONS
GIMA VITAL SIGNS MONITORS
"Vital Signs" is a line of small multi-parameter patient monitors, which
can monitor the vital physiological parameters: non-invasive blood
pressure (NIBP), pulse oxygen saturation (SpO
2
), electrocardiogram
(ECG), temperature (TEMP) and capnography (EtCO
2
).
Features:
- small size, clear and bright display for remote view
- up to 400 groups of NIBP measurements can be stored and listed
- up to 90 hours of EtCO
2
, SpO
2
and HR trend curve can be displayed
- built-in rechargeable battery, optional built-in thermal printer
SpO
2
+NIBP+
ECG+TEMP
Optional
printer
35120
35121 35122 35123
- Adult SpO
2
probe
•
•
•
•
- NIBP adult cuff
•
•
- Temperature probe - skin type
•
•
- ECG cable + 10 ECG electrodes
•
- Sidestream sensor and line kit
•
- Battery
•
•
•
•
- Manual (English)
•
•
•
•
STANDARD ACCESSORIES
GIMA
code
MONITOR SpO
2
NIBP ECG CO
2
TEMP
35120
VITAL-S
•
35121
VITAL-SNT
•
•
•
35122
VITAL-SNET
•
•
•
•
35123
VITAL-C
•
•
35125
Printer
*
- optional
35141
Paper 5.1 cm x 12 m - box of 5
35126
Lead acid re-chargeable battery - spare
35135
Adult SpO
2
probe - spare
35136
Pediatric SpO
2
probe
35137
ECG cable - spare
35140
NIBP cuff - 10-19 cm - pediatric
35142
NIBP cuff - 18-26 cm - pediatric XL
35139
NIBP cuff - 25-35 cm - adult
35143
NIBP cuff - 33-47 cm - adult XL
35127
Trolley - adjustable 73 to 113 cm
35128
Rail clamp
35120
+
35128
Rail clamp
*
Installation done by Gima if ordered with monitor.
Need service if ordered later.
UP 7000 MULTI-PARAMETER PATIENT MONITOR
ECG+RESP+SpO
2
+
2 TEMP+PR
• 35145 MULTI-PARAMETER PATIENT MONITOR
ECG, RESP, SpO
2
, 2 TEMP, PR
- 12.1'' high resolution colour TFT display
- 3 channel ECG amplification
- arrhythmia analysis and ST segment analysis
- up to 800 groups parameter data & 24-hour ECG waveform
storage and recall
- 480-hour graphic and tabular trends for all parameters
- 7 trace ECG waveforms simultaneous display
- protection against interference from defibrillator
- adult/pediatric measurement modes
- visual and audible alarms
- built-in rechargeable battery
- built-in thermal printer
TECHNICAL SPECIFICATIONS
NIBP Monitoring
Measuring method:
Oscillometric
Measuring range:
Systolic pressure: Diastolic pressure: Mean arterial pressure:
adult:
40~255mmHg 10~220mmHg 20~215mmHg
pediatric:
40~200mmHg 10~110mmHg 20~165mmHg
TEMP Monitoring
Measuring range:
25.0°C~45.0°C ±0.2°C
Response time:
≤ 150 sec
SpO
2
& Pulse Rate Monitoring
SpO
2
measuring range:
35%~100%
PR measuring range:
30bpm~240bpm ±2bpm
ECG Monitoring
Heart rate measurement: ±0.4mVp~±5mVp
Heart rate display range: 20bpm~250bpm
RESP Monitoring
Measuring method:
Thoracic impedance
Monitoring range
0rpm~120rpm,
Monitoring accuracy:
±5% or ±2rpm whichever is greater
Other Technical Specifications
Power supply
100~250Vac, 50/60Hz
Power consumption:
<80 VA
Display mode
12.1 inches TFT color LCD
Alarming mode
Audible-visual alarm
Networking port
Ethernet port
STANDARD ACCESSORIES
35122
35127
SpO
2
SpO
2
+
EtCO
2
SpO
2
+
NIBP+
TEMP
35123
35121
35120
35150
Adult SpO
2
probe
Pediatric SpO
2
probe
ECG cable
NIBP cuff - arm circumf. 10-19 cm - pediatric
NIBP cuff - arm circumf. 18-26 cm - pediatric XL
NIBP cuff - arm circumf. 25-35 cm - adult
NIBP cuff - arm circumf. 33-47 cm - adult XL
Lead acid rechargeable battery - spare
Paper 5.1 cm x 12 m - box of 5
Trolley - adjustable 73 to 113 cm
- Adult SpO
2
probe
- NIBP adult cuff
- Temperature probe - skin
- Temperature probe - rectal
- Re-chargeable battery
- Printer
- Power supply cable
- ECG cable
- Disposable electrode
- Dust-protective mantle
- Manual (English, Italian)
